Keypad Mode (P-12 = 1 Or 2) - Invertek Drives Optidrive ODE-2-11005-1H01 Series User Manual

Terminal Mode P-12=0, P-15=3
+24 Volt
Run (Enable)
Analog / Preset 1
External Trip
+ 10 Volts
Reference
0 Volts
Analog speed input with 1 preset speed
and motor thermistor trip
7.2.

Keypad Mode (P-12 = 1 or 2)

P-15 Digital input 1 (T2)
0, 5, Open: Stop (disable)
8..12 Closed: Run (enable)
Open: Stop (disable)
1
Closed: Run (enable)
Open: Stop (disable)
2
Closed: Run (enable)
Open: Stop (disable)
3 1)
Closed: Run (enable)
Open: Stop (disable)
4
Closed: Run (enable)
Open: Stop (disable)
6 1)
Closed: Run (enable)
Open: Forward Stop
7
Closed: Forward Run
Example Wiring
Keypad Mode P-12=1 or 2, P-15=0
+24 Volt
Run (Enable)
Increase Speed
Reduce Speed
+ 10 Volts
Forward / Reverse
0 Volts
Remote push button speed control with
fwd/rev
By default if the enable signal is present the drive will not Enable until the START button is pressed. To automatically enable the drive when the
NOTE
enable signal is present set P-31 = 2 or 3. This then disables the use of the START & STOP buttons
Optidrive ODE-2 User Guide Revision 3.20
Terminal Mode P-12=0, P-15=4
Local or remote analog speeds
(2 analog inputs)
Digital input 2 (T3) Digital input 3 (T4)
Closed : remote UP push- Closed : remote DOWN
button push-button
No effect No effect
Closed : remote UP push- Closed : remote DOWN
button push-button
Closed : remote UP push- External trip input :
button Open: Trip, Closed: Run
Closed : remote UP push- Open : Keypad speed ref
button Closed : Analog input 1
Open : Forward run External trip input :
Closed : Reverse run Open: Trip, Closed: Run
Open: Reverse Stop External trip input :
Closed: Reverse Run Open: Trip, Closed: Run
www.invertekdrives.com
Terminal Mode P-12=0, P-15=11
+24 Volt
Run (Enable)
Local / Remote
(Hand / Auto)
Remote (Auto)
Reference
+ 10 Volts
Local (Hand)
Reference
0 Volts
Push button fwd/rev/stop with fast stop
using 2
Analog input (T6)
Open : Forward
+24V : Reverse
No effect
Open : Keypad speed ref
+24V : Preset speed 1
Closed : remote DOWN
push-button
Analog input 1
Open : Keypad speed ref
+24V : Preset speed 1
Open : Keypad speed ref
+24V : Preset speed 1
+24 Volt
Run Forward
Stop
Run Reverse
+ 10 Volts
Reference
0 Volts
nd
deceleration ramp
Comments
Speed reference = PI
Controller Output
Connect external motor
thermistor PTC type or
similar to digital input 3
Connect external motor
thermistor PTC type or
similar to digital input 3
Closing digital inputs 1 and 2
together carries out a fast
stop (P-24)
23
