3.6. Mechanical Dimensions – IP66 (Nema 4X) Enclosed Units
Drive Size A
mm in mm
1 232.0 9.13 207.0
2 257.0 10.12 220.0
3 310.0 12.20 276.5
Mounting Bolts All Frame Sizes
Tightening Torques
All Frame Sizes
3.7.

Guidelines for mounting (IP66 Units)


Before mounting the drive, ensure that the chosen location meets the environmental condition requirements for the drive shown in
section 9.1

The drive must be mounted vertically, on a suitable flat surface

The minimum mounting clearances as shown in the table below must be observed

The mounting site and chosen mountings should be sufficient to support the weight of the drives

Using the drive as a template, or the dimensions shown above, mark the locations required for drilling

Suitable cable glands to maintain the ingress protection of the drive are required. Gland holes for power and motor cables are pre-
moulded into the drive enclosure, recommended gland sizes are shown above. Gland holes for control cables may be cut as required.
10
Optidrive ODE-2 User Guide Revision 3.20
B D E
in mm in mm
8.15 189.0 7.44 25.0
8.67 200.0 7.87 28.5
10.89 251.5 9.90 33.4
4 x M4 (#8)
Control Terminals
Power Terminals
www.invertekdrives.com
Drive X
Size Above &
Below
mm in mm
1 50 1.97
2 75 2.95
3 100 3.94
Note :
Dimension Z assumes that the drives are mounted side-by-side with
no clearance.
Typical drive heat losses are 3% of operating load conditions.
Above are guidelines only and the operating ambient temperature of
the drive MUST be maintained at all times.
F G
in mm In mm in
0.98 179.0 7.05 161.0 6.34
1.12 187.0 7.36 188.0 7.40
1.31 245.0 9.64 211.0 8.30
0.5 Nm (4.5 lb-in)
1 Nm (8.85 lb-in)
Drive Size X Above & Below
mm
2 200
3 200
Typical drive heat losses are approximately 3% of operating load
conditions.
Above are guidelines only and the operating ambient temperature of the
drive MUST be maintained at all times.
Frame Power Cable
2 M25 (PG21)
3 M25 (PG21)
Y Z
Recommended
Either
Between airflow
Side
in mm in
50 1.97 33 1.30
50 1.97 46 1.81
50 1.97 52 2.05
H I
mm in mm in
148.5 5.85 4.0 0.16
176.0 6.93 4.2 0.17
197.5 7.78 4.2 0.17
Y Either Side
in mm
7.87 10
7.87 10
Note :
Cable Gland Sizes
Motor Cable Control Cables
M25 (PG21) M20 (PG13.5)
M25 (PG21) M20 (PG13.5)
CFM (ft 3 /min)
11
11
26
J Weight
mm in kg lb
8.0 0.31 3.1 6.8
8.5 0.33 4.1 9.0
8.5 0.33 7.6 16.7
in
0.39
0.39
