Function
VDC or VAC
VDC or VAC 200mV range
mA AC/DC
A AC/DC
Resistance, Continuity
Controls and Jacks
1. LCD display
2. Rotary function switch
3. 10 ampere test lead jack
4. Test lead jack for voltage, milliamp,
resistance/continuity, diode and temperature functions
5. COM test lead jack
6. Battery compartment (rear)
SYMBOLS
•)))
Continuity
AC
6
M
megga (10
) (ohms)
3
k
kilo (10
) (ohms)
A
Amps
BAT
Battery test
°F
Degrees Fahrenheit
Input Protection Limits
Maximum Input
600VAC and VDC
200Vrms
200mA 250V fast acting fuse
10A 250V fast acting fuse
(for 30 seconds max. every 15 minutes.)
250Vrms for 15 sec. max.
m
V
Ω
°C
3
Diode
DC
-3
milli (10
) (volts, amps)
Volts
Ohms
Degrees Celsius
Low battery indicator
MN15-EU V1.2 7/08
