5.2
PCB Layout
Figure 20
through
SBAU342A – February 2020 – Revised June 2020
Submit Documentation Feedback
Figure 22
illustrate the EVM PCB layouts.
Figure 20. ADS7066 EVM PCB Top Layer
Figure 21. ADS7066 EVM PCB Ground Layer
Figure 22. ADS7066 EVM PCB Power Plane Layer
Figure 23. ADS7066 EVM PCB Bottom Layer
Copyright © 2020, Texas Instruments Incorporated
Bill of Materials, Printed Circuit Board Layout, and Schematics
ADS7066EVM-PDK Evaluation Module
