CARDIO STRONG EX80 Plus Touch Assembly And Operating Instructions Manual page 24

(4) When no value is set, the default setting is counting up from 0 (after 99.9 it returns to 0.0).
(5) When a value is set, the default setting is counting down from the value to 0.0. At 0.0 the console
pauses and saves training data.
5. CALORIES:
(1) Display range: 0 ~ 999
(2) Setting range: 0 ~ 990?? (The value can be directly entered with the numerical pad)
(3) Display bar:: Cell amount - 10 cells (MAX= 150 CAL, display full cells).
When no settings are set: 150 CAL / 10 cells = 15 CAL / cell
When settings are set: Setting value / 10 cells
(4) When no value is set, the default setting is counting up from 0 (after 999 it returns to 0).
(5) When a value is set, the default setting is counting down from the value to 0:00. At 0:00 the
console pauses and saves training data.
6. PULSE:
(1) Display range: 0 ~ 230
(2) Setting range: 0 ~ 230 (The value can be directly entered with the numerical pad)
(3) Display bar: Cell amount - 10 cells (MAX= 120, display full cells, = 12 / cell)
(4) Displays detected heartbeat when no value is set.
(5) When a value is set, the detected heartbeat is displayed and when the heartbeat exceeds the set
value, the console will beep.
(6) The beep is 2 times within 1 second.
7. WATT:
(1) Display range: 0~999
(2) Setting range: not settable
(3) Display bar: Cell amount - 10 cells (MAX = 350, display full cells, 35 / cell)
(4) Cells will display RPM & LOAD accordingly (WATT console)
8. LOAD:
(1) Display range: 1 ~ 16
(2) Setting range: 1 ~ 16
(3) Display Bar: Cell amount - 16 cells (MAX = 16, display full cells)
9. USER:
(1) Users: U0~U4
(2) U0 guest profile and is not saved.
(3) Profiles U1~U4 can be saved after being set.
(4) AGE, HEIGHT, WEIGHT, USER NAME, GENDER can be set and stored.
AGE: Setting range: 1 ~ 99 (Default: 25)
HEIGHT: Setting range: 100 ~ 250 cm (Default 160 cm)
40 ~ 99 inches (Default 60 inches)
WEIGHT: Setting range: 20 ~ 150 kg (Default 50 kg)
40 ~ 350 pounds (Default 100 pounds)
DEFAULT USER NAME: XXXXXXXXXX
GENDER: MALE / FEMALE
EX80 Plus Touch
24
