- Page 1 Assembly and Operating Instructions max. 150 kg ~ 90 Min. 33 kg L 70 | W 183 | H 171 FSCSTFX50.01.02 Art. No. CST-FX50 Crosstrainer FX50...
- Page 2 FX50...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly Folding Mechanism OPERATING INSTRUCTIONS Console display Button functions Programmes 3.3.1 Quick-Start and Manual Mode Wireless Connection and Fitness Apps STORAGE AND TRANSPORT General Instructions Transportation Wheels TROUBLESHOOTING, CARE AND MAINTENANCE... - Page 4 WARRANTY CONTACT FX50...
- Page 5 Dear customer, thank you for choosing fi tness equipment from cardiostrong®. cardiostrong off ers high-quality home fi tness equipment that is optimally adapted to the conditions at home. Train at home no matter what the weather or time of the day. cardiostrong fi tness equipment off ers training programmes and a variety of equipment for all training levels and all training goals.
- Page 6 (person with legal responsibility). Class H (home use): use at home. These stationary training devices are intended for the use in private homes where access to the training device is regulated by the owner (person with legal responsibility). FX50...
- Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.
-
Page 8: General Information
Packaging dimensions (L x W x H) approx.: 186 cm x 46 cm x 87 cm Set-up dimensions (L x W x H) approx.: 70 cm x 183 cm x 171 cm Maximum user weight: 150 kg Use class: FX50... -
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 10: Electrical Safety
The software systems on gym equipment with TFT consoles are set up only for the pre- installed apps. Do not install any additional apps. NOTICE The pre-installed apps on TFT consoles are produced and provided by external manufacturers. Fitshop does not take any responsibility for the availability, functionality or contents of these apps. FX50... -
Page 11: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 12: Assembly
To prevent damage to the equipment and the fl oor, assemble the equipment on a mat or packaging board. NOTICE In order to make the assembly as simple as possible, some screws and nuts to be used can already be pre-assembled. Ideally, assemble the equipment at its later set-up place. FX50... -
Page 13: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. ⚠... - Page 14 FX50...
-
Page 16: Assembly
Use the packaging styrofoam to appropriately raise the main frame (J) and make the assembly easier. Remove the two screws (J-55). ⚠ RISK OF INJURY The appliance folds up when the securing screws are released. Make sure you keep your hands away from the folding parts! styrofoam FX50... - Page 17 Step 2 Remove the four screws (J-42/J-54), the tube (J-41) and joint plate for main frame (J-53).
- Page 18 Step 3 Assemble the front stabilizer (L) and the middle stabilizer (M) with two screws (R-1) each. FX50...
- Page 19 Step 4 Connect the two console cables (J-27 & L6). Assemble the handlebar post (L) with four screws (J-1). Assemble the left cap of the handlebar post (S-7) and the right cap of handlebar post (S-8) with one screw (R-9) each. Assemble the cover for rear stablizer (S-9) with two screws (R-9).
- Page 20 Step 5 Assemble the left and right lower handlebar (P & Q) to the axle of the handlebar post (K) using the bushing (R-10), two fl at washers (R-4) and two hex. screws (R-5) in total. FX50...
- Page 21 Step 6 Assemble the two pedal arms (E & F) to the left and right lower handlebar (P & Q) with two hex. screws (R-5), two fl at washers (R-6) and one fi xed axle (R-7) each. Assemble the two pedal arms (E & F) to the main frame (J) with one hex. screw (R-12) and one washer (R-11) each.
- Page 22 Assemble the covers (S-1 & S-2, S3 & S4) to the left and right upper handlebar (N & O) with four screws (R-9). NOTICE Ensure that the screws are fi tted from diff erent sides. Please refer to the illustration. FX50...
- Page 23 Step 8 Remove the four screws (A-1). Connect the sensor wire (K-5) and the connecting wire (K-6) with their respective counterparts of the console (A). Assemble the console to the handlebar post (L) with four screws (A-1).
- Page 24 To get off , grip the handles with both hands and place one foot next to the equipment and then the other foot. FX50...
-
Page 25: Folding Mechanism
Folding Mechanism Lift until it engages audibly Grab the end of the slider and push it upward to make the slider to rotate upward. Pull the red button and release the folding mechanism. Lower it slowly to the Rotate until the support sha fl oor. -
Page 26: Operating Instructions
Console display SYMBOL DISPLAY SETTING RANGE TIME 00:00~99:59 00:00 ~ 99:00 SPEED 0.0~99.9K/M DISTANCE 0 / 15~999 CALORIES 0.00~99.99Km 0.0 ~99.0 0~9999 0 ~ 9990 LOAD 1 ~ 16 / 1 ~ 32 1 ~ 16 / 1 ~ 32 FX50... -
Page 27: Button Functions
WATTS 0 ~ 999 PULSE ⚠ WARNING Your training equipment is not a medical device. The heart rate measurement of 30 ~ 230 30 ~ 230 this equipment may be inaccurate. Various factors can aff ect the accuracy of the heart rate measurement. -
Page 28: Programmes
In manual mode, you can carry out your training depending on one or more parameters. All the parameters you set are counted up during the training programme, the others are counted down accordingly. To start the programme, step on the pedals. FX50... -
Page 29: Wireless Connection And Fitness Apps
Wireless Connection and Fitness Apps This console is equipped with a wireless interface. Please take note that your mobile device needs to be compatible with the wireless interface of the crosstrainer. To use training apps you will have to activate the wireless connection function on your mobile device (tablet or smart phone) and start the fi tness app. -
Page 30: Storage And Transport
After that, you easily can move the equipment to a new position. For long transport distances the equipment should be disassembled and safely packed. Select the new location by following the instructions in the section 1.4 of this manual. FX50... -
Page 31: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may aff ect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 32: Error Codes And Troubleshooting
Error Codes and Troubleshooting The electronics of the equipment continuously carries out tests. In case of deviations, an error code appears on the display and normal operation is stopped for your safety. Please contact the contract partner for technical support. FX50... -
Page 33: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specifi ed intervals: Part Weekly Monthly Quarterly Display console Slide rails* Lubrication of slide rails and moving parts*... -
Page 34: Recommended Accessories
Of course, you can also contact our customer service: by telephone, e-mail, in one of our branches or via our social media channels. We will be happy to advise you! chest strap chest strap contact gel fl oor mat silicone spray FX50... -
Page 35: Ordering Spare Parts
The serial number of your equipment is unique. It’s located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate fi eld. service sticker Serial number: Brand / Category: cardiostrong / Elliptical cross trainer Model Name: cardiostrong Crosstrainer FX50 Article Number: CST-FX50... -
Page 36: Parts List
IDLER LEVER IDLER WHEEL BEARING C RING WAVE WASHER CRANK ASSEMBLY CRANK CRANK COVER,INNER SCREW HEX. SCREW NYLON NUT PEDAL TUBE (LEFT) ASSEMBLY PEDAL TUBE (LEFT) BUSHING BEARING PEDAL (LEFT) SCREW SUPPORT PAD SCREW END CAP WASHER E-10 SCREW FX50... - Page 37 PEDAL TUBE (RIGHT) ASSEMBLY PEDAL TUBE (RIGHT) BUSHING BEARING PEDAL (RIGHT) SCREW SUPPORT PAD SCREW END CAP WASHER F-10 SCREW PEDAL ARM ASSEMBLY (LEFT) PEDAL ARM (LEFT) JOINT OF PEDAL ARM BEARING SCREW FLAT WASHER NYLON NUT FLAT WASHER BUSHING BUSHING G-10 CAP FOR PEDAL ARM...
- Page 38 COVER FOR REAR STABILIZER SCREW I-10 LIMIT PIN I-11 FOAM PAD I-12 BUTTON I-13 BUTTON HOLDER I-14 SPRING I-15 CONNECTING PIN I-16 SCREW I-17 ADJUSTING LEVER I-18 BUSHING I-19 LOCATING SHAFT I-20 SUPPORT SHAFT I-21 SCREW I-22 PLASTIC WASHER FX50...
- Page 39 I-23 NYLON NUT I-24 FLAT WASHER I-25 CYLINDER I-26 SCREW I-27 FLAT WASHER I-28 NYLON NUT I-29 BUSHING MAIN FRAME SET SCREW SCREW SCREW SCREW FLAT WASHER PARALLEL KEY FLAT WASHER SCREW BUSHING J-10 BUSHING J-11 FLYWHEEL J-12 TENSION WIRE J-13 DRIVE BELT J-14...
- Page 40 SCREW J-50 FRONT COVER FOR PEDAL ARM (RIGHT) J-51 FRONT COVER FOR PEDAL ARM (LEFT) J-52 SCREW J-53 JOINT PLATE FOR MAIN FRAME J-54 SCREW J-55 SCREW HANDLEBAR POST ASSEMBLY HANDLEBAR POST HAND PULSE SENSOR HAND PLUSE PLATE SCREW FX50...
- Page 41 SENSOR WIRE CONNECTING WIRE "COVER FOR WATER BOTTLE HOLDER(UNDERNEATH)" COVER FOR HANDLEBAR POST (UPPER) FRONT STABILIZER ASSEMBLY FRONT STABILIZER END CAP MIDDLE STABILIZER ASSEMBLY MIDDLE STABILIZER TRANSPORTATION WHEEL NYLON NUT SCREW FLAT WASHER END CAP UPPER HANDLEBAR ASSEMBLY (LEFT) UPPER HANDLEBAR, LEFT FOAM GRIP END CAP FOR UPPER HANDLEBAR UPPER HANDLEBAR ASSEMBLY (RIGHT)
- Page 42 REAR CAP OF UPPER LEFT HANDLEBAR FRONT CAP OF UPPER RIGHT HANDLEBAR REAR CAP OF UPPER RIGHT HANDLEBAR LEFT CAP OF LOWER HANDLEBAR RIGHT CAP OF LOWER HANDLEBAR LEFT CAP OF HANDLEBAR POST RIGHT CAP OF HANDLEBAR POST COVER FOR REAR STABLIZER ADAPTER FX50...
-
Page 43: Exploded Drawing
Exploded Drawing... - Page 44 FX50...
- Page 45 WARRANTY Products from cardiostrong® are subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. Error Descriptions Your fi tness equipment is developed for long-term, high-quality training.
- Page 46 For that reason, we also want to resolve your queries quickly and in a straightforward manner. Thus, please always keep your customer number and the serial number of the faulty equipment handy. FX50...
- Page 47 CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER SUPPORT �� �� �� +49 4621 4210-900 80 90 16 50 00800 2020 2772 +494621 4210 944 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fi tshop.dk info@fi tshop.co.uk �� technik@fi tshop.de �� ��...
- Page 48 Visit us also on our social media platforms or our blog! FX50...
- Page 49 Notes...
- Page 50 Notes FX50...
- Page 52 Crosstrainer FX50...
