- Page 1 Assembly and Operating Instructions max. 150 kg ~ 90 Min. 130 kg L 161 | W 85 | H 164 CSTEX80PLUST.02.03 Art. No. CST-EX80-2-PLUS-T Crosstrainer EX80 TOUCH...
- Page 2 EX80 TOUCH...
- Page 3 Dear customer, thank you for choosing fitness equipment from cardiostrong®. cardiostrong offers high-quality home fitness equipment that is optimally adapted to the conditions at home. Train at home no matter what the weather or time of the day. cardiostrong fitness equipment offers training programmes and a variety of equipment for all training levels and all training goals.
- Page 4 This notice indicates potentially hazardous situations which, if not avoided, will result in death or serious injuries! NOTICE This notice indicates further useful information. Retain these instructions in a safe place for future reference, maintenance or when ordering replacement parts. EX80 TOUCH...
-
Page 5: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Switching On and Initial Settings Programmes 3.4.1 Quick-Start Programme 3.4.2 Manual Programme 3.4.3 Pre-Set Programmes 3.4.4 Watt Programme 3.4.5 Heart Rate Controlled Programs Recovery Function Multimedia... - Page 6 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT EX80 TOUCH...
-
Page 7: General Information
GENERAL INFORMATION Technical Data TFT display of speed in km/h training time in min training distance in km cadence (rotations per minute) calories burnt in kcal heart rate (when using the hand sensors or a chest strap) Watt resistance level Resistance system: electronic magnetic brake system Resistance level:... -
Page 8: Personal Safety
Make sure that nobody is within the range of motion of the equipment during training so as not to endanger you or other persons. ࣑ ATTENTION Do not insert any objects of any kind into the openings of the device. EX80 TOUCH... -
Page 9: Electrical Safety
Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠... -
Page 10: Set-Up Place
(over 70%) like swimming pools. A floor protective mat/equipment underlay can help to protect high-quality floor coverings (parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight unevenness. EX80 TOUCH... -
Page 11: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 12: Scope Of Delivery
In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠ If parts of the scope of delivery are missing or damaged, the assembly must not be carried out. EX80 TOUCH... -
Page 13: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Unpacking Place the box flat on the floor and remove the lid of the box. - Page 14 Remove the two pre-assembled screws (F5) from the main frame (A). Remove the two pre-assembled screws (F5) from the central supporting tube (F1). Mount the central supporting tube (F1) to the main frame (A) using the previously removed screws (F5) Loosely tighten the screws. EX80 TOUCH...
- Page 15 Step 3: Assembly of the right side connecting tube Mount the right side connecting tube (C2) to the main frame (A) using a screw (J8), see view A. Mount the right side connecting tube (C2) along with the iron bracket (F2) to the bottom of the main frame (A) using two screws (J2), see view B.
- Page 16 Tighten all screws from the steps before. Remove the two pre-assembled screws (F6) from the central supporting tube (F1). Mount the joint covers (F3 & F4) to the central supporting tube (F1) using the previously removed screws (F6). EX80 TOUCH...
- Page 17 Step 5: Assembly of the pedal supporting tubes Mount the right pedal supporting tube (B2) to the top of the main frame (A) using one screw (J3), one washer (J9) and one nut (J4), see view C. Mount the right pedal supporting tube (B2) to the bottom of the main frame (A) using one screw (J5), one washer (J9) and one nut (J4), see view D.
- Page 18 Remove the three pre-assembled screws (J10 & J11) from the left handle bar (E1) , see view F. Mount the left handle bar (E1) to the main frame (A) using the previously removed screws (J10 & J11). Repeat the steps for the other side. 6m/m*2 J11*6 View F Ansicht F J10*6 J11*6 J10*6 EX80 TOUCH...
- Page 19 Step 7: Assembly of the console supporting tube and the bottle holder ࣑ ATTENTION Pay attention to not pinch the cables during the next step. Connect the cable (D1) of the console supporting tube (D) to the cable (A1) of the main frame (A) until you hear a click sound.
- Page 20 Lift the equipment on the desired side and rotate the setting screws under the main frame. Rotate the screws clockwise in order to remove them and to raise the equipment. Rotate them counterclockwise in order to lower the equipment. EX80 TOUCH...
- Page 21 Step 10: Connecting the equipment to the mains supply ࣑ ATTENTION The equipment must not be connected to a multiple socket, otherwise it cannot be guaranteed that the equipment will be supplied with sufficient power. Technical errors can result. Plug the cable into the socket on the main frame. Plug the power plug into a wall outlet that complies with the instructions in the chapter on electrical safety.
- Page 22 Do not adjust the stride length while standing on the device. Loosen and pull the pin out and adjust the desired stride length. Release the pin at the desired height and retighten the pin. Repeat the steps for the other side. 45 cm 65 cm EX80 TOUCH...
-
Page 23: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console Display USB Port 3.5 mm audio jack Display range: 0:00–99:59 TIME Setting range: 0–99 (Minuten) SPEED... -
Page 24: Button Functions
The device must not be used or switched off during the update. Check at regular intervals whether another update is available and perform it as described above. As soon as a new version is available, the icon is white. Otherwise, the icon is grayed out. EX80 TOUCH... - Page 25 Open the factory settings. Here you can set the following functions: WIFI Screen brightness Volume Language Unit (metric or imperial) Update software and app updates ࣑ ATTENTION The console of this fitness device uses software that is perfectly adapted to the equipment. Please do not make any unauthorised modifications, such as the installation of external apps.
-
Page 26: Programmes
The values for time, distance and calories are incremented. Tap the arrow buttons to increase or decrease resistance. Tap Pause to pause the program. Tap Continue to resume the workout. Tap Home to return to the main menu. EX80 TOUCH... -
Page 27: Manual Programme
3.4.2 Manual Programme There are several setting options for the manual program. You can decide whether you want to train on one or more values. Values that have been set are counted down and the remaining values are counted up accordingly. As soon as a set target value is reached, the programme is automatically terminated. -
Page 28: Watt Programme
Set the desired training time. Tap Start to start the program. Tap the arrow buttons to increase or decrease the resistance. Tap Pause to pause the program. Tap Continue to resume the workout. Tap Home to return to the main menu. EX80 TOUCH... -
Page 29: Heart Rate Controlled Programs
3.4.5 Heart Rate Controlled Programs ⚠ WARNING Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. There are four heart rate programmes available. -
Page 30: Multimedia
Tap Continue and the app will open. To continue your workout, tap the arrow on the left side of the screen and tap Quick Start. The selected app now runs in parallel with the running program. EX80 TOUCH... -
Page 31: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 32: Troubleshooting, Care And Maintenance
Batteries empty work Contact your contract partner Check whether there is an update for the software (TFT) and carry it out. Software version not up to Software problems date If the problems persist, contact your contract partner. EX80 TOUCH... -
Page 33: Maintenance And Inspection Calendar
Eliminate sources of interference (e.g. Sources of interference in mobile phone, WLAN, lawn mower the room and vacuum cleaner robot, etc..) unsuitable chest strap Use a suitable chest strap (see RECOMMENDED ACCESSORIES). Wrong position of chest No pulse display Reposition chest strap... -
Page 34: Recommended Accessories
Alternatively, you can use the QR code provided. Of course, you can also contact our customer service: by telephone, e-mail, in one of our branches or via our social media channels. We will be happy to advise you! chest strap floor mat chest strap contact gel silicone spray towels EX80 TOUCH... - Page 35 ORDERING SPARE PARTS Serial Number and Model Name In order to provide you with the best possible service, please have the model name, article number, serial number, exploded drawing and parts list ready. The corresponding contact options can be found in chapter 10 of this operating manual. NOTICE The serial number of your equipment is unique.
- Page 36 Screw M8 X 25 Push Rod Bracket ( L ) Nut M8 Push Rod Bracket ( R ) Bush Knob Bearing 6005Zz Nylon Sleeve Bush Bolt M8 X 20 Bearing Nut Nut M8 Belt Washer M8 Crank Bolt M12 X 53 EX80 TOUCH...
- Page 37 Washer M12 Pedal Supporting Tube ( R ) Nut M12 Pedal Housing ( L ) Led Display Pedal Housing ( R ) Bearing Sleeve Lower Pedal Supporing Tube Bush Screw M12 X 109 Bearing 6201Zz Washer M12 Screw M12 X 73 Nut M12 Washer M12 Pedal Bracket ( L )
- Page 38 Handle Pulse Ring Bolt M12 X 73 Foam Spacer Ring Nut M12 Spong Hdr Bolt M12 X 109 Spong Hdr Screw M5 Screw M3 X 8 Screw M8 X 20 End Cap Washer M12 Handle Bar ( L ) Adaptor EX80 TOUCH...
- Page 39 Exploded Drawing...
- Page 40 EX80 TOUCH...
- Page 41 WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. Error Descriptions Your fitness equipment is developed for long-term, high-quality training.
- Page 42 For that reason, we also want to resolve your queries quickly and in a straightforward manner. Thus, please always keep your customer number and the serial number of the faulty equipment handy. EX80 TOUCH...
- Page 43 CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��...
- Page 44 The company employs numerous sports scientists, fitness trainers and competitive athletes. Visit us also on our social media platforms or our blog! EX80 TOUCH...
- Page 45 Notes...
- Page 46 Notes EX80 TOUCH...
- Page 48 Crosstrainer EX90 TOUCH...
