Table A-8 lists the configuration options.
Table A-8. RCM3305/RCM3315 Jumper Configurations
Header
Description
JP1
Flash Memory Size
JP2
Flash Memory Bank Select
JP3
Data SRAM Size
Ethernet or I/O Output
JP4
on Header J3
Ethernet or I/O Output
JP5
on Header J3
Ethernet or I/O Output
JP6
on Header J3
Ethernet or I/O Output
JP7
on Header J3
Ethernet or I/O Output
JP8
on Header J3
NOTE: The jumper connections are made using 0 Ω surface-mounted resistors.
User's Manual
Pins Connected
1–2 128K/256K
2–3 512K
1–2 Reserved for future use
2–3 Normal Mode
1–2 128K/256K
2–3 512K
1–2 TPO+
2–3 PD3
1–2 TPO–
2–3 PD2
1–2 ENET_INT
2–3 PE0
1–2 TPI+
2–3 PD7
1–2 TPI–
2–3 PD6
Factory
Default
×
×
×
×
×
×
×
×
77
