Table A-1. RCM3305/RCM3315 Specifications (continued)
Parameter
Watchdog/
Supervisor
Pulse-Width
Modulators
Input Capture
Quadrature
Decoder
Power
Operating
Temperature
Humidity
Connectors
Board Size
User's Manual
RCM3305
4 PWM registers with 10-bit free-running counter
and priority interrupts
2-channel input capture can be used to time input signals from
various port pins
2-channel quadrature decoder accepts inputs from external
incremental encoder modules
390 mA @ 44.2 MHz, 3.3 V
-40°C to +70°C (boards manufactured up to May, 2008)
0°C to +70°C (boards manufactured after May, 2008)
5% to 95%, noncondensing
Two 2 × 17, 2 mm pitch
one 2 × 5 for programming with 1.27 mm pitch
1.850" × 2.725" × 0.86"
(47 mm × 69 mm × 22 mm)
RCM3315
Yes
3.15–3.45 V DC
69
