Table B-4 lists the configuration options using jumpers.
Table B-4. Prototyping Board Jumper Configurations
Header Description
Stepper Motor Power-Supply
JP1
Options (U2)
Stepper Motor Power-Supply
JP2
Options (U3)
JP3 PF0 Option
RCM3305/RCM3315 Power
JP4
Supply
RS-485 Bias and Termination
JP5
Resistors
User's Manual
Pins Connected
1–2
Onboard power supply
9–10
3–4
External power supply
7–8
1–2
Onboard power supply
9–10
3–4
External power supply
7–8
1–2 Quadrature decoder inputs enabled
RabbitNet/Serial Flash interface
2–3
enabled
RCM3305/RCM3315 powered via
2–3
Prototyping Board
1–2 Bias and termination resistors
5–6 connected
Bias and termination resistors not
1–3
connected (parking position for
4–6
jumpers)
Factory
Default
×
×
×
×
×
