- Page 1 Rack Mount Panel PC 17”/ 19”/ 24” Touchscreen Intel® Celeron N2930 2.16 GHz Military Grade R17IB3S-RKA1ML Model No: R19IB3S-RKA3ML W24IB3S-RKS1ML User Manual Version 1.0 Document Part Number: 9152111I102D...
-
Page 2: Preface
USER MANUAL PREFACE PREFACE Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 3 USER MANUAL PREFACE Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
- Page 4 USER MANUAL PREFACE Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
- Page 5 USER MANUAL PREFACE Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
- Page 6 USER MANUAL PREFACE Safety Precautions For your safety carefully read all the safety instructions before using the device. All cautions and warnings on the equipment should be noted. Keep this user manual for future reference. CAUTION/ATTENTION Do not cover the openings! Ne pas couvrir les ouvertures! *Let service personnel to check the equipment in case any of the following problems appear:...
- Page 7 USER MANUAL PREFACE Important Information Countries/ Symbol This equipment complies with essential requirements of: Area European Electromagnetic Compatibility Directive(2014/30/EU) Union Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules.
- Page 8 USER MANUAL PREFACE European Union This equipment is in conformity with the requirement of the following EU legislations and harmonized standards. Product also complies with the Council directions. Electromagnetic Compatibility Directive (2014/30/EU) EN55024: 2010 EN 55022: 2010 Class B o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012...
-
Page 9: About This User Manual
ABOUT THIS USER MANUAL ABOUT THIS USER MANUAL This User Manual provides information about using the Winmate® Military Grade Panel PC (IB32). The documentation set for the Military Grade Panel PC (IB32) provides information for specific user needs, and includes: ... -
Page 11: Table Of Contents
USER MANUAL CONTENTS CONTENTS PREFACE ..........................ii ABOUT THIS USER MANUAL ..................... i CHAPTER 1: INTRODUCTION ....................2 1.1 Product Features ......................2 1.2 Hardware Specifications ....................3 1.3 Software Support ......................4 1.4 Package Contents ......................5 1.5 Appearance ........................6 1.5.1 Appearance ...................... - Page 12 USER MANUAL CONTENTS 3.2 Safety Precautions ......................24 3.3 Mounting Guide ......................24 3.3.1 Console / Rack Mounting ................... 24 3.3.2 VESA Mounting ....................26 CHAPTER 4: MAINTENANCE ....................28 4.1 Cleaning the Display Screen ..................28 4.2 Cleaning the Casing ....................... 28 CHAPTER 5: DRIVER INSTALLATION ..................
- Page 13 USER MANUAL CHAPTER 1 INTRODUCTION INTRODUCTION This chapter gives you product overview, describes features and hardware specifications. You will find all accessories that come with the Panel PC in the packing list. MILITARY RACK MOUNT PANEL PC...
-
Page 14: Chapter 1: Introduction
CHAPTER 1 INTRODUCTION CHAPTER 1: INTRODUCTION Thank you for choosing Winmate® Military Grade Panel PC. This series feature low power high performance CPU with fanless design. Anti-corrosive coating with aluminum alloy housing withstands the harshest military environments. Armored connectors MIL- DTL-38999 (type I and III) initially developed for aerospace industry perfectly fit in our Military grade product line. -
Page 15: Hardware Specifications
USER MANUAL CHAPTER 1 INTRODUCTION 1.2 Hardware Specifications Model Name R17IB3S-RKA1ML R19IB3S-RKA3ML W24IB3S-RKS1ML Display: Size 17” 19” 24” Resolution 1280 x 1024 1280 x 1024 1920 x 1200 Brightness 350 cd/ (typ.) 350 cd/ (typ.) 300 cd/ (typ.) Contrast Ratio 1000:1 (typ.) -
Page 16: Software Support
INTRODUCTION Windows 10 IoT Enterprise Windows Embedded 8.1 Industry Windows Embedded 8 Standard Windows Embedded Standard 7 1.3 Software Support Winmate provide all necessary Drivers and Software Development Kit (SDK). Drivers: Chipset Driver Graphics Driver Audio Driver Ethernet Driver Intel ® Management Engine Software USB 3.0 Driver (for Windows 7) -
Page 17: Package Contents
USER MANUAL CHAPTER 1 INTRODUCTION 1.4 Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: CD-ROM with Driver Panel PC... -
Page 18: Appearance
USER MANUAL CHAPTER 1 INTRODUCTION 1.5 Appearance This section includes appearance and input/ output connectors’ layout. 1.5.1 Appearance MILITARY RACK MOUNT PANEL PC... -
Page 19: On-Screen Display Control
USER MANUAL CHAPTER 1 INTRODUCTION 1.5.2 On-Screen Display Control On-Screen Display (OSD) is a user-friendly interface to remote the display function and to adjust the display’s image properties. It also supports special Hot Keys for easy control, such as auto-adjustment and brightness control for backlight. 1.5.2.1 Control Keys Button Function... - Page 20 USER MANUAL CHAPTER 1 INTRODUCTION 1.5.2.2 LED Indicators Indicator Color Definition Green Power is ON and the device functions normally Orange Panel PC is suspended Green HDD is active HDD is inactive LOCK The function of OSD buttons is locked Lock function disabled MILITARY RACK MOUNT PANEL PC...
-
Page 21: Dimensions
USER MANUAL CHAPTER 1 INTRODUCTION 1.6 Dimensions This section includes mechanical drawing and dimensions of Panel PCs. 1.6.1 Dimensions 17” *Measurements shown in mm. **Tolerance of all dimensions is shown as follow 0~30 mm ± 0.1 mm, 30~50 mm ± 0.15 mm, 50~120 mm ±... -
Page 22: Dimensions 19
USER MANUAL CHAPTER 1 INTRODUCTION 1.6.2 Dimensions 19” *Measurements shown in mm. **Tolerance of all dimensions is shown as follow 0~30 mm ± 0.1 mm, 30~50 mm ± 0.15 mm, 50~120 mm ± 0.2 mm, above 120 mm ± 0.25 mm. ***Note: this is a simplified drawing and some components are not marked in detail. -
Page 23: Dimensions 24
USER MANUAL CHAPTER 1 INTRODUCTION 1.6.3 Dimensions 24” *Measurements shown in mm. **Tolerance of all dimensions is shown as follow 0~30 mm ± 0.1 mm, 30~50 mm ± 0.15 mm, 50~120 mm ± 0.2 mm, above 120 mm ± 0.25 mm. ***Note: this is a simplified drawing and some components are not marked in detail. - Page 24 USER MANUAL CHAPTER 2 GETTING STARTED GETTING STARTED This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. MILITARY RACK MOUNT PANEL PC...
-
Page 25: Chapter 2: Gettings Started
USER MANUAL CHAPTER 2 GETTING STARTED CHAPTER 2: GETTINGS STARTED This chapter provides information on how to connect the device to the source of power, connector pinouts and the guideline to turn on/off the Panel PC. 2.1 Powering On 2.1.1 Power Considerations The device operates on external DC power. -
Page 26: Connecting The Power
USER MANUAL CHAPTER 2 GETTING STARTED 2.1.2 Connecting the Power 2.1.2.1 Connecting to AC Input Power Source (Default) 1. Connect one end of the Military Grade power connector MIL-DTL-38999/1 to the Panel PC. 2. Plug the other end of the power connector in to a working AC outlet. AC Power Requirements: AC Input 115~230V AC 50-60Hz... - Page 27 USER MANUAL CHAPTER 2 GETTING STARTED 2.1.2.2 Connecting to DC Input Power Source (Optional) 1. Insert the exposed wires of the DC Power Cable to the appropriate connectors on the terminal block plug. 2. Plug the terminal block plug firmly to the DC IN Jack. 3.
-
Page 28: Connecting Other Devices
USER MANUAL CHAPTER 2 GETTING STARTED 2.2 Connecting Other Devices Note that all the connectors are military grade and comply with military standard. The pin assignment of the cables are as follows. WARNING!/ AVERTISSEMENT! Make sure the power is off when connecting and disconnecting the connectors. -
Page 29: Vga Connector
USER MANUAL CHAPTER 2 GETTING STARTED 2.2.2 VGA Connector Plug one end of the 15-pin D-Sub signal cable. Pin № Signal Name Pin № Name GREEN BLUE ID2/RES RED_RTN GREEN_RTN BLUE_RTN KEY/PWR ID0/RES ID1/SDA HSync VSync ID3/SCL 2.2.3 RS232/422/485 Connector Serial Port is a D-Sub 9 connector that can be configured to RS-232/422/485 by jumper Connect one side of the serial port cable to the RS-232 connector on the Panel PC and the other side to Serial COM interface. -
Page 30: Lan Connector
USER MANUAL CHAPTER 2 GETTING STARTED Connect USB 2.0/ USB3.0 connector to the external USB 2.0/ USB3.0 compatible device, for example mouse or keyboard. Pin № Signal Name Pin № Signal Name USB_D- USB_D+ STDA_SSRX- STDA_SSRX+ GND_DRAIN STDA_SSTX- STDA_SSTX+ USB_D- USB_D+ 2.2.5 LAN Connector Connect Ethernet connector to Ethernet interface. - Page 31 USER MANUAL CHAPTER 2 GETTING STARTED Pin № RS-232 MILITARY RACK MOUNT PANEL PC...
-
Page 32: Configuring Serial Port Settings
USER MANUAL CHAPTER 2 GETTING STARTED 2.3 Configuring Serial Port Settings Jumpers are located on the motherboard. It is required to open the unit to access the jumpers. Follow instructions in this section to configure serial port settings. A pair of needle nose pliers may be helpful when working with jumpers. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. -
Page 33: Turning On And Off
USER MANUAL CHAPTER 2 GETTING STARTED 2.4 Turning ON and OFF To Turn ON the Panel PC: 1. Tap the power button to turn the Panel PC on. 2. Press “DEL” to enter the CMOS setting and check the BIOS setup. The Power Switch is located on the front side OSD panel. - Page 34 USER MANUAL CHAPTER 3 MOUNTING MOUNTING This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. MILITARY RACK MOUNT PANEL PC...
-
Page 35: Chapter 3: Mounting
USER MANUAL CHAPTER 3 MOUNTING CHAPTER 3: MOUNTING This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. CAUTION/ ATTENTION Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. Suivez les instructions de montage et d'utilisation recommandé... -
Page 36: Safety Precautions
USER MANUAL CHAPTER 3 MOUNTING 3.2 Safety Precautions Observe the following common safety precautions before installing any electronic device: •Use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must be crossed make sure the wires are perpendicular at the intersection point. - Page 37 USER MANUAL CHAPTER 3 MOUNTING Mounting Steps: 1. Prepare a fixture for the specific dimensions of the device. 2. Cut a hole on a sub frame or panel according to the cutout dimensions. 3. Install the device properly onto the cutout area of the sub frame or panel with the sides of the front bezel.
-
Page 38: Vesa Mounting
USER MANUAL CHAPTER 3 MOUNTING 3.3.2 VESA Mounting Military Rack Mount Panel PC supports VESA Mount installation. Notice that VESA Plate is not included in Winmate’s standard accessories package. Tools Needed VESA Plate 100 x 100 mm *with customer’s bracket Mounting Steps: 1. - Page 39 USER MANUAL CHAPTER 4 MAINTENANCE MAINTENANCE This chapter provides information on regular cleaning and maintenance procedures. Follow all the recommendations included in this chapter in order to ensure long product lifecycle. MILITARY RACK MOUNT PANEL PC...
-
Page 40: Chapter 4: Maintenance
USER MANUAL CHAPTER 4 MAINTENANCE CHAPTER 4: MAINTENANCE This chapter includes regular cleaning and maintenance procedures. Follow all the recommendations in this chapter in order to ensure long product lifecycle. This equipment is extremely rugged and does not require a lot of maintenance. Remember that electrical equipment should be handled with care and used accordingly to its specifications. - Page 41 USER MANUAL CHAPTER 5 DRIVER INSTALLATION DRIVER INSTALLATION This chapter describes how to install all necessary drivers. MILITARY RACK MOUNT PANEL PC...
-
Page 42: Chapter 5: Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION CHAPTER 5: DRIVER INSTALLATION This chapter provides guideline to driver installation. 4.1 Installing Chipset Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. MILITARY RACK MOUNT PANEL PC... - Page 43 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 2 Click Next to continue. Step 3 Click Yes to agree the license terms. MILITARY RACK MOUNT PANEL PC...
- Page 44 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 4 Click Next to install the driver. Step 5 Software setup progress window will appear, click Next to continue. Step 6 Click “Yes, I want to restart this computer now” to finish the installation. MILITARY RACK MOUNT PANEL PC...
-
Page 45: Installing Graphics Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 4.2 Installing Graphics Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. Step 2 Setup Welcome Window will appear, click Next to continue the process. Step 3 Carefully read the license terms and click Yes to agree. -
Page 46: Installing Intel Sideband Fabric Device (Intel Mbi) Driver (Windows 8)
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 4.3 Installing Intel Sideband Fabric Device (Intel MBI) Driver (Windows 8) Step 1 Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 47: Installing Intel Trusted Engine Interface (Intel Txe) Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 4.4 Installing Intel Trusted Engine Interface (Intel TXE) Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 48: Installing Intel Network Connections
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 4.5 Installing Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Step 1 Click “PROWin64.exe” Step 2 Click Yes to start the installation. Step 3 Welcome window will appear, click Next to install the driver. -
Page 49: Installing Audio Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 4.6 Installing Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. -
Page 50: Installing Usb 3.0 Driver (Windows 7)
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 4.7 Installing USB 3.0 Driver (Windows 7) NOTE: If your operation system is Windows Embedded 8.1 Industry or Windows Embedded 8 Standard, you should skip the USB 3.0 driver installation. This HMI features Intel Celeron Trail-M N2930CPU with the Intel®... - Page 51 USER MANUAL CHAPTER 6 BIOS SETUP BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the Panel PC for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. MILITARY RACK MOUNT PANEL PC...
-
Page 52: Chapter 6: Bios Setup
USER MANUAL CHAPTER 6 BIOS SETUP CHAPTER 6: BIOS SETUP 6.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press <Del> key when the prompt appears on the screen during start up. The prompt screen shows only few seconds, you need to press <Del>... - Page 53 USER MANUAL CHAPTER 6 BIOS SETUP The following Keys can be used after entering the BIOS Setup. Function General Help Previous Values Optimized Defaults Save & Exit Exit Change Opt. Enter Select or execute command Cursor ↑ Moves to the previous item Cursor ↓...
-
Page 54: Main Menu
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.1 Main Menu When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date. Immediately after the [DEL] key is pressed during startup, the main BIOS setup menu appears: BIOS Setting... -
Page 55: Advanced Menu
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. IMPORTANT: Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer. - Page 56 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Option Effect ACPI Settings Configures ACPI Enter Opens submenu settings F81866 Super IO Configures IO Enter Opens submenu Configuration settings Hardware Monitor Configures Enter Opens submenu Hardware Monitor settings S5 RTC Wake Configures RTC Enter Opens submenu...
- Page 57 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.1 ACPI Settings Advanced Configuration and Power Interface (ACPI) settings allow to control how the power switch operates. The power supply can be adjusted for power requirements. You can use the screen to select options of ACPI configuration. A description of the selected items will appear on the right side of the screen.
- Page 58 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.2 F81866 Super IO Configuration You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen.
- Page 59 USER MANUAL CHAPTER 6 BIOS SETUP Watch Dog Time Select You can either disable Watch Dog Timer or set up the time.Use <Arrow> keys to navigate and please press <Enter>to select the item. GPI0 Port Configuration You can use the screen to change GPI0 Port setting. Use these items to set parameters related to PIN3-PIN14 Control.
- Page 60 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.3 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc. 6.2.2.4 S5 RTC Wake Settings Wake system from S5 enables or disables system wake on alarm event. It allows you to wake up the system in a certain time.
- Page 61 USER MANUAL CHAPTER 6 BIOS SETUP Select Fixed Time to set the system to wake on the specified time. Use Navigation Keys to switch among the items: Day, Hour, Minute and Second. Type the desired value in the selected item. or example: If you want the system to start up automatically at 15:30:30, the 10th day of each month, then you should enter 10, 15, 30, and 30 from top to bottom.
- Page 62 USER MANUAL CHAPTER 6 BIOS SETUP Wake system from S5 after dynamic time setting Select Dynamic Time to set the system to wake on the current time + increase minute (s). 6.2.2.5 CPU Configuration MILITARY RACK MOUNT PANEL PC...
- Page 63 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Option Effect Socket CPU This item contains Enter Open sub-menu Information socket specific CPU information. CPU Thermal Thermal control Enter Open sub-menu Configuration Limit CPUID Limits CPIID Disabled/Enabled Enable/Disable this Maximum Maximum function...
- Page 64 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Option Effect CPU C State Report Shows CPU C State Enabled/ Enable or Disable Report Disabled CPU C state report to OS Max CPU C-State Allows to enter C1E, C3, C6, C7, Enable or Disable power-saving Auto...
- Page 65 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Option Effect Critical Trip Point Specifies the 90C, 87C, 85C, 79C, Select the disable temperature at 71C, 63C,55C,47C, temperature for the which the OS will 39C, 31C, 23C, 15C system to shut shut down the down system...
- Page 66 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Effect Option Serial- ATA Responsible for supporting Enabled/ Enable or disable (SATA) chipset drives with SATA Disabled this function interface. SATA Speed Allows forcing the speed limit Gen1 The maximum Support SATA II ports standard IDE / speed will be...
- Page 67 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.9 Miscellaneous Configuration OS Selection This item allows users to select the proper Operating System. BIOS Setting Description Setting Option Effect Windows 8.X Allows user to Enter Use Windows 8.X choose the proper Windows 7 Allows user to Enter Use Windows 7...
- Page 68 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.10 CSM Configuration BIOS Setting Description Setting Option Effect CSM Support The Compatibility Enabled/ Enable or disable Support Module Disabled the Compatibility (CSM) is a Support Module component of the UEFI firmware that provides legacy BIOS compatibility by emulating a BIOS environment,...
- Page 69 USER MANUAL CHAPTER 6 BIOS SETUP ROM is booted Legacy Storage Specifies which UEFI Only UEFI option Storage option ROM ROMs are booted is booted Legacy Only Legacy option ROMs are booted Video Specifies which UEFI Only UEFI option Video option ROM ROMs are booted is booted Legacy...
- Page 70 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Option Effect Legacy USB User can enable or Disable Will keep USB Support disable USB port. devices available only for EFI applications. Enable Enable all the USB devices USB 3.0 Support User can enable or Enable Enable USB 3.0 is...
- Page 71 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.12 Platform Trust Technology BIOS Setting Description Setting Option Effect fTPM Trusted Platform Enabled/Disabled Enables or disables Module parameters this function MILITARY RACK MOUNT PANEL PC...
- Page 72 USER MANUAL CHAPTER 6 BIOS SETUP 6.2.2.13 Security Configuration BIOS Setting Description Setting Option Effect Trusted Execution Enabled/Disabled Enables or Technology disables this parameters function TXE HMRFPO TXE HMRFPO Enabled/Disabled Enables or parameters disables this function TXE Firmware TXE Firmware Enabled/Disabled Enables or Update...
-
Page 73: Chipset Menu
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.3 Chipset Menu For items marked with ►, please press <Enter> for more options. BIOS Description Setting Effect Setting Option High Allow to set up High Precious Timer Enabled/ Enables/Disable Precious settings Disabled s this function Timer Restore AC This function allows to set up... -
Page 74: Security Menu
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.4 Security Menu In the Security menu, users can set administrator password, user password, and HDD security configuration. BIOS Setting Description Setting Effect Option Administrator Displays whether or not an Enter Enter Password administrator password has been password set. -
Page 75: Boot Configuration
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.5 Boot Configuration The Boot menu sets the sequence of the devices to be searched for the operating system.The bootable devices will be automatically detected during POST and shown here,allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system. - Page 76 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Option Effect Setup Prompt Allows user to Enter Set the prompt Timeout configure the timeout number of seconds to stay in BIOS setup prompt screen. Boot NumLock Enables or disables Remains On State NumLock feature on...
-
Page 77: Save& Exit
USER MANUAL CHAPTER 6 BIOS SETUP 6.2.6 Save& Exit The Exit menu displays a way how to exit BIOS Setup utility. After finishing your settings, you must save and exit for changes to be applied. MILITARY RACK MOUNT PANEL PC... - Page 78 USER MANUAL CHAPTER 6 BIOS SETUP BIOS Setting Description Setting Option Effect Save Changes and This saves the Enter <YES> Save changes Exit changes to the CMOS and exits the BIOS Setup program. Discard Changes This exits the BIOS Enter <YES> Saves the changes and Exit Setup without...
-
Page 79: Using Recovery Wizard To Restore Computer
USER MANUAL CHAPTER 6 BIOS SETUP 5.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: ... - Page 80 USER MANUAL CHAPTER 6 BIOS SETUP MILITARY RACK MOUNT PANEL PC...
- Page 81 USER MANUAL CHAPTER 7 TECHNICAL SUPPORT Technical Support This chapter includes directory for technical support and Software Development Kit (SDK). MILITARY RACK MOUNT PANEL PC...
-
Page 82: Chapter 7: Technical Support
2_Graphics 3_Audio 4_LAN 5_KMDF 5_TXE 6_USB3.0 Winmate provide the following SDK for Military Grade Rack Mount Panel PC with Intel® Celeron N2930 2.16GHz processor: Item File Type Description Watchdog SDK To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. - Page 83 USER MANUAL CHAPTER 7 TECHNICAL SUPPORT 7.1.1 Winmate Download Center Go to www.winmate.com > Support > Download Center > Military Panel PC (IB32) > Drivers / Development Kit Or follow the link: http://www.winmate.com/DownCenter/DownLoadCenter.asp?DownType=2303&OnlyCo ntent= 7.1.2 Winmate File Share Go to http://www.winmate.com/...
-
Page 84: Problem Report Form
USER MANUAL CHAPTER 7 TECHNICAL SUPPORT 7.2 Problem Report Form Military Grade Rack Mount Panel PC Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: _____________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible. - Page 85 USER MANUAL APPENDIX A MIL-STD-810F/G COMPLIANCE MIL-STD-810F/G COMPLIANCE This section includes information on testing methods and procedures in compliance with military standard MIL-STD-810 F/G. Appendix MILITARY RACK MOUNT PANEL PC...
-
Page 86: Appendix A: Mil-Std-810F/G Compliance
USER MANUAL APPENDIX A MIL-STD-810F/G COMPLIANCE APPENDIX A: MIL-STD-810F/G COMPLIANCE This section includes information on testing methods and procedures in compliance with military standard MIL-STD-810 F/G. MIL-STD-810F/G Compliance Test Reference Condition * High Storage Method 501.5, Basic Hot 30 to 63°C ± 2°C Temperature Procedure I Operation... - Page 87 USER MANUAL APPENDIX B MIL-STD-810E/F COMPLIANCE MIL-STD-461E/F COMPLIANCE This section includes information on testing methods and procedures in compliance with military standard MIL-STD-461E/F Appendix MILITARY RACK MOUNT PANEL PC...
-
Page 88: Appendix B: Mil-Std-461E/F Compliance
USER MANUAL APPENDIX B MIL-STD-810E/F COMPLIANCE APPENDIX B: MIL-STD-461E/F COMPLIANCE This section includes information on testing methods and procedures in compliance with military standard MIL-STD-461 E/F. MIL-STD-461E/F Compliance Test Description Type Frequency Range CE101 Power Leads Conducted Emission 30 Hz ~ 10 kHz *CE102 Power Leads Conducted Emission 10 kHz ~ 10... - Page 89 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, Taipei 241, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
