Configuration with QuickSET

Advanced IP Routing Settings

This section describes the Advanced IP Routing Settings for Advanced Routing configuration.
Displays the active interface number.
Interface # —
Local WAN IP Address — Set this value only if you are going to use Numbered Mode. In
numbered mode, the Local WAN IP address is the IP address of the WAN link leading into the
Telco central office. A Subnet Mask is required for this IP address before you can use this link.
Displays the subnet mask for the Local WAN IP address.
Subnet Mask —
Use this button to change an entry in the Advanced IP Routing Settings box.
Modify —

Advanced IP Routing Options

This section describes the available selections for the Advanced IP Routing Options of the
Advanced Routing configuration window.
RIP Settings — The RIP Settings Window, shown below in Figure 45, lets you enable, or disable
the receiving of Routing Information Packets.
Figure 45 RIP Settings Window
46 QuickSET Configuration Guide
