HSIM-W6
Installation Guide
HSIM-W6
WIDE AREA1
WIDE AREA2
ASYNC
LNK
CPU
LNK
LNK
STS
STS
STS
TELCO
TELCO
9032694

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSIM-W6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cabletron Systems HSIM-W6

Summary of Contents for Cabletron Systems HSIM-W6

  • Page 1 HSIM-W6 Installation Guide HSIM-W6 WIDE AREA1 WIDE AREA2 ASYNC TELCO TELCO 9032694...

  • Page 3: Fcc Notice

    WARNING: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. HSIM-W6 Installation Guide...

  • Page 4: Industry Canada Notice

    OTHER RESTRICTIONS. You may not reverse engineer, decompile, or disassemble the Program. APPLICABLE LAW. This License Agreement shall be interpreted and governed under the laws and in the state and federal courts of New Hampshire. You accept the personal jurisdiction and venue of the New Hampshire courts. HSIM-W6 Installation Guide...

  • Page 5: United States Government Restricted Rights

    Acquisition Regulations, Section 52.227-7013 (c) (1) (ii) and its successors, and use, duplication, disclosure by the Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at 252.227-7013. Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03867-0505. HSIM-W6 Installation Guide Notice...

  • Page 6: Declaration Of Conformity

    EN 55022 EN 50082-1 EN 60950 Networking Equipment, for use in a Commercial or Light Industrial Environment. Legal Representative in Europe Mr. J. Solari ___________________________________ Full Name Managing Director - E.M.E.A. ___________________________________ Title Newbury, Berkshire, England ___________________________________ Location HSIM-W6 Installation Guide...

  • Page 7: Table Of Contents

    ABOUT THE HSIM-W6 HSIM-W6 Hardware...2-1 WAN Connection...2-1 Additional Features ...2-3 Remote Management Capabilities ...2-3 Optional Feature ...2-4 HSIM-W6 Firmware Support ...2-4 WAN Protocols ...2-4 Inverse Multiplexing ...2-6 Firmware Data Compression ...2-6 HDLC ...2-7 DHCP and NAT ...2-7 Frame Relay Protocol ...2-8 Point-to-Point Protocol...2-9...
  • Page 8 System Passwords ...2-17 Simple Network Management Protocol (SNMP)...2-18 Software and Firmware Upgrades ...2-21 CHAPTER 3 INSTALLATION Unpacking the HSIM-W6 ...3-1 Guidelines for Installations ...3-1 Installing Interface Modules ...3-2 Installing WAN Port Interface Modules (WPIMs) ...3-2 CSX-COMP/ENCR Installation ...3-4 Installing an HSIM...3-6 Installing an HSIM in an Interface Module ...3-6...
  • Page 9 WPIM-HDSL... A-15 WPIM-S/T ... A-16 APPENDIX B SPECIFICATIONS AND STANDARDS COMPLIANCE Regulatory Compliance ... B-1 Individual WPIM Regulatory Compliance... B-2 WPIM-TI ... B-2 WPIM-SY ... B-2 WPIM-DDS... B-3 WPIM-E1... B-3 WPIM-DI... B-3 WPIM-S/T... B-4 WPIM-HDSL ... B-4 HSIM-W6 Installation Guide Contents...
  • Page 10 Contents APPENDIX C NETWORK INFORMATION WORKSHEETS APPENDIX D FCC PART 68 - USER’S INFORMATION FOR HSIM-W6 APPENDIX E GLOSSARY INDEX viii HSIM-W6 Installation Guide...

  • Page 11: Chapter 1 Introduction

    Introduction Welcome to the Cabletron Systems HSIM-W6 Installation Guide. This guide provides basic configuration information, hardware specifications and troubleshooting tips for the HSIM-W6. This document also provides guidelines for routing and bridging over Wide Area Networks (WANs). Structure of this Guide...

  • Page 12: Related Documents

    Chapter 1: Introduction Related Documents Use the READ ME FIRST! document included with the HSIM-W6 to set up a computer before beginning configuration. Use the Cabletron Systems QuickSET Configuration Guide to configure the HSIM-W6. Use the Cabletron Systems CyberMONITOR User’s Guide to monitor the WAN using the CyberMONITOR graphical user interface.

  • Page 13: Getting Help

    The serial and revision numbers of all involved Cabletron Systems products in the network • The device history (i.e., have you returned the device before, is this a recurring problem, etc.) • Any previous Return Material Authorization (RMA) numbers HSIM-W6 Installation Guide (603) 332-9400 support@ctron.com ctron.com (134.141.197.25) anonymous...
  • Page 14 Chapter 1: Introduction HSIM-W6 Installation Guide...

  • Page 15: About The Hsim-W6

    WAN Port Interface Modules (WPIMs) to the device into which it is installed. The HSIM-W6 supports IEEE 802.1d transparent bridging, IP routing, IPX routing between the host device and the two WAN connections, ISDN, Dynamic Host Configuration Protocol (DHCP), Network Address Translation (NAT), and Inverse Multiplexing (IMUX) between Ethernet LANs across a WAN resource.
  • Page 16 The WPIM-S/T provides an Integrated Services Digital Network (ISDN) 128 Kbps Basic Rate Interface (BRI) for the HSIM-W6. The WPIM-S/T provides an ISDN back-up link for a remote site or branch office when the main WPIM for a frame relay or leased line loses a connection or becomes disabled.

  • Page 17: Additional Features

    The LANVIEW LEDs are located on the HSIM-W6 front panel. Remote Management Capabilities The HSIM-W6 can be remotely managed with any SNMP network management system including the following: •...

  • Page 18: Optional Feature

    HSIM-W6 over Nailed-up PPP or ISDN and Frame Relay. Depending on the packet type and size, hardware data compression provides a minimum of 2:1 data compression, giving 3 Mbps throughput on each T-1 WPIM interface.
  • Page 19 ISDN BRI is a switched Data Link layer control protocol which uses digital signaling to place a call into an ISDN network. Once the call is made, PPP is then used to transfer data. HSIM-W6 Installation Guide HSIM-W6 Firmware Support...

  • Page 20: Inverse Multiplexing

    The IMUX function evenly distributes a data packet stream from the LAN interface through the two WAN interfaces on the HSIM-W6. Since the data traffic is equally shared between the two Full T1 interfaces, each with 1.5 Mbps throughput, the total throughput over the logical link is 3 Mbps, or 6 Mbps full-duplex operation with the optional hardware compression module (CSX-COMP/ENCR) installed in the HSIM-W6.

  • Page 21: Hdlc

    The HSIM-W6 acts as a DHCP server that allows individual clients (PCs, network equipment) to take turns using a range of private IP addresses (often referred to as local IP addresses), and provides optional secondary setup features for these clients on a per-port basis.

  • Page 22: Frame Relay Protocol

    The NAT method allows several DHCP clients on a sub network to connect to WAN clients by allowing the DHCP clients to share a single public IP address. When the HSIM-W6 uses NAT, the NAT method modifies the IP headers and addresses, and the selected fields in upper layer protocol headers.

  • Page 23: Point-To-Point Protocol

    The STAC Electronics Stacker LZS Compression Protocol is supported over PPP providing up to 4:1 data compression. PAP and CHAP Security The HSIM-W6 supports the Password Authentication Protocol (PAP) and Challenge Handshake Authentication Protocol (CHAP) under PPP. PAP provides verification of passwords between devices using a 2-way handshake. One device (peer) sends the system name and password to the other device (authenticator).

  • Page 24: Lqm

    Chapter 2: About the HSIM-W6 In half-duplex operation, the authenticator device challenges the peer device by generating a CHAP challenge, and the challenge contains an MD5 algorithm with a random number that has the encrypted password and system name. The peer device then applies a one-way hash algorithm to the random number and returns this encrypted information along with the system name in the CHAP response.

  • Page 25: Isdn

    The HSIM-W6 supports one ISDN BRI line and either or both of the B channels for transferring data. If the two B channels are used for separate connections, each provides up to 64 Kbps transfer rates.

  • Page 26: Isdn Back-Up

    Time to Connect, Time to Disconnect, Connect Retries, Back-up Override, Input Idle Time-out and Output Idle Time-out, are the six back-up parameters used to manage the ISDN Back-up feature on the HSIM-W6, and are described as follows: Time to Connect allows the user to configure the amount of seconds the Time to Connect —...

  • Page 27: Ip-Ospf Hierarchy

    OSPF area possessing an area id of 0.0.0.0. Areas Areas are groups of networks and attached hosts. A router’s topology database includes area links, and summarized and external links depicting the autonomous system topology. From this database, routers calculate a route using the shortest-path tree algorithm.
  • Page 28 The Backup Designated Router is chosen from those routers who have not declared themselves to be the Designated Router. If a one or more routers have declared itself to be the BDR in their Hello packets, the one with the highest Router Priority becomes the BDR. If no routers have declared themselves to be BDR, then the router with the highest router ID becomes BDR.

  • Page 29: Hdsl

    HSIM-W6 Firmware Support HDSL High-bit rate Digital Subscriber Line (HDSL) technology uses existing copper twisted pair cables designed for conventional analog voice transmission from a telephone carrier servicing area as a low-cost alternative to the quality and speed of fiber optic cables, and provides high-speed full-duplex digital transmission links of up to 1.544 Mbps.
  • Page 30 The HSIM-W6 can operate as a bridge, a router, or both. The HSIM-W6 operates as a router for network protocols that are supported when routing is enabled and operates as a bridge when bridging is enabled. When both bridging and routing are enabled, routing takes precedence over bridging (i.e., the HSIM-W6 uses the protocol address...

  • Page 31: Bridging And Routing Protocol Filtering

    Bridge filtering allows a network administrator to control the flow of packets across the HSIM-W6. Bridge filtering can be used to “deny” or “allow” packets based on a “matched pattern” using a specified position and hexadecimal content within the packet. This enables restricting or forwarding of messages based on address, protocol, or data content.

  • Page 32: Simple Network Management Protocol (Snmp)

    The HSIM-W6 provides SNMP agent support for the following: standard and Enterprise Specific Management Information Bases (MIBs), and support for standard and Enterprise Specific SNMP Traps. SNMP is also used internally for configuration of the HSIM-W6. The active SNMP agent within the HSIM-W6 accepts SNMP requests for status, statistics and configuration updates.
  • Page 33 CTISDN-REMOTEPROFILE-MIB. SNMP Trap Support SNMP Traps are notifications of network events sent by an SNMP compliant device to an SNMP management station. The following SNMP Traps are supported by the HSIM-W6: • IETF Standard Traps: • Warm Start Trap Type Code #1 RFC1214 •...
  • Page 34 Chapter 2: About the HSIM-W6 The following is a list of IP Events that are logged and that create the IP Event Log Change Trap. • IP Routing has been disabled on interface # • IP Routing has been enabled on interface # •...

  • Page 35: Software And Firmware Upgrades

    QuickSET allows the user to retrieve or upgrade the firmware, software, and configuration files from its Firmware Upgrade menu by selecting the TFTP/BootP Services window to access a TFTP (Trivial File Transfer Protocol) server. HSIM-W6 Installation Guide HSIM-W6 Firmware Support 2-21...
  • Page 36 Chapter 2: About the HSIM-W6 2-22 HSIM-W6 Installation Guide...

  • Page 37: Chapter 3 Installation

    Installation This chapter outlines the procedure for attaching the HSIM-W6 to the network. To install the HSIM and WPIMs, you need the following items: • Antistatic wrist strap (provided with the HSIM-W6) • Phillips screwdriver Unpacking the HSIM-W6 Unpack the HSIM-W6 as follows: Remove the shipping material covering the HSIM-W6 in the shipping box.

  • Page 38: Installing Interface Modules

    CAUTION installation. Failure to do so could result in damage to the WPIMs, CSXCOMP/ENCR, and the HSIM-W6. The HSIM-W6 must have at least one WPIM installed before you can begin NOTE configuring the device. Installing WAN Port Interface Modules (WPIMs) Both WAN ports can be populated.
  • Page 39 Press down firmly on the WPIM until the pins slide all the way into the connector. Ensure that the WPIM seats firmly on the standoffs. Secure the WPIM to the three standoffs using the screws that are provided with the HSIM-W6. Reattach the faceplate to the HSIM using the two screws saved in step 3.

  • Page 40: Csx-Comp/Encr Installation

    HSIM Faceplate Screws CSX-COMP/ENCR Installation This section contains instructions on how to install the COMP/ENCR into the HSIM-W6. To help eliminate any potential problems during or after installation, read and understand the following steps: Attach one end of the antistatic wrist strap to your wrist and the other end to an approved electrical ground.
  • Page 41 D-Type connector on the HSIM-W6. Locate the D-Type connector and the standoffs on the HSIM-W6 (refer to The D-Type connector pins of the CSX-COMP/ENCR only fits one way onto the HSIM-W6 D-Type connector. Lower the CSX-COMP/ENCR onto the standoffs and align the connector with the connector pins.

  • Page 42: Installing An Hsim

    (e.g., SmartSWITCH 2200, SmartSWITCH 6000). Refer to the release notes for the version of firmware running on the Cabletron Systems device to ensure that the HSIM-W6 is supported. The following sections provide generic instructions for installing an HSIM-W6 in a SmartSWITCH interface module or in a SmartSWITCH chassis.
  • Page 43 Secure the HSIM to the faceplate using the two screws saved in step 5. Secure the HSIM to the standoffs with the screws saved in step 6. Reinstall the interface module in the chassis. Reattach the network cabling to the module. HSIM-W6 Installation Guide Standoff Screws Faceplate 225704...
  • Page 44 Chapter 3: Installation Standoff Screws HSIM Connector Faceplate Mounting Screws Standoffs 225705 Figure 3-5 Installing the HSIM HSIM-W6 Installation Guide...

  • Page 45: Installing An Hsim In A Smartswitch Chassis

    Secure the HSIM to the standoffs using the screws saved in step 6. Ensure that the chassis cover is in place before reconnecting the power cord. Reattach the chassis cover to the chassis and reconnect the power cord. Reconnect the chassis to your network. HSIM-W6 Installation Guide 3-4. Figure 3-4.
  • Page 46 Chapter 3: Installation 3-10 HSIM-W6 Installation Guide...

  • Page 47: Chapter 4 Troubleshooting

    HSIM-W6 to diagnose power failures, cable faults and link problems. panel LEDs. Table 4-1 through If you are having difficulty installing and configuring the HSIM-W6, perform the following steps: • Check that all cables and connectors have been attached properly. •...
  • Page 48 Chapter 4: Troubleshooting Table 4-2 HSIM-W6 ASYNC LED States (Console Connection Only) Status (STS) Link (LNK) Table 4-3 shows the console connection to the ASYNC port. The configuration setup for a VT100 Mode Terminal is 8 bits, No parity, 1 stop bit, and 9600 baud.
  • Page 49 Table 4-4 HSIM-W6 ASYNC Modem Connection Pinout Table 4-5 HSIM-W6 WAN Link (LNK) LED States Link (LNK) HSIM-W6 Installation Guide Description Transmit Data Data Carrier Detect (DCD) Data Set Ready (DSR) Receive Data Ground Data Terminal Ready (DTR) Request to Send (RTS)
  • Page 50 Chapter 4: Troubleshooting Table 4-6 HSIM-W6 WAN Status (STS) LED States for T1, DI, and E1 Ports Status (STS) Table 4-7 HSIM-W6 WAN Status (STS) LED States for DDS Ports Status (STS) Table 4-8 HSIM-W6 WAN Status (STS) LED States for SYNC Ports...

  • Page 51: Troubleshooting Hsim-W6 Hardware

    Troubleshooting HSIM-W6 Hardware Power (PWR) LED is OFF • Check that the power connection is firmly attached to the back panel of the HSIM-W6, and the other end to an active power source. Processor (CPU) LED is OFF If the CPU stays OFF for an extended amount of time, and the power (PWR) light remains on, the CPU is in an unknown state.

  • Page 52: Processor (Cpu) Led Is Red

    If the port does not function, check the cabling, console connection pinout, and VT configuration. Status (STS) LED is GREEN or GREEN (Blinking) The ASYNC port is connected for modem operation. Data Set Ready (DSR) is Active. • Check the cabling and console connection pinout. Getting Help Chapter HSIM-W6 Installation Guide...

  • Page 53: Status (Sts) Led Is Amber (Blinking)

    The WAN interface is configured, but there is no signal indicating that a valid connection is present on the WAN interface. • Check that the HSIM-W6 and the device at the other end of the segment are powered up. • Use QuickSET or Local Management to make sure that both WAN interfaces, local and remote, are configured correctly.

  • Page 54: Status (Sts) Led Is Off

    Chapter 4: Troubleshooting Status (STS) LED is OFF WPIM-T1, WPIM-E1, WPIM-DI, or WPIM-DDS Installed in HSIM-W6 The port is operating normally. If it is not, and this LED is OFF the port may be disabled. • Use QuickSET or Local Management to make sure that the WAN interface on the Local device is configured correctly.

  • Page 55: Status (Sts) Led Is Red

    Status (STS) LED is AMBER WPIM-T1, WPIM-E1, or WPIM-DI Installed in HSIM-W6 The device is in Yellow alarm mode. A Yellow alarm indicates that the HSIM-W6 is receiving proper framing from the Telco, but the Telco is not receiving proper framing.

  • Page 56: Status (Sts) Led Is Amber (Blinking)

    Use QuickSET or Local Management to make sure that the WAN interface on the local device is configured properly. • Verify the cabling being used between the HSIM-W6 and the CSU/DSU. WPIM-HDSL is Installed in HSIM-W6 The Port is operating normally, the WPIM is synchronized with the HDSL circuit at the remote end.

  • Page 57: Investigating Software Configuration Problems

    Check that your LAN cable is wired correctly and each end securely plugged in. • Make sure that an IP route exists between your local PC and the HSIM-W6. The PC and HSIM-W6 must be on the same IP subnetwork or the HSIM-W6 must be reachable through a router on your LAN.

  • Page 58: Troubleshooting The Frame Relay Connection

    It is not done by polling the FR switch. Invalid — This is done if the physical connection has some sort of problem. The circuit will remain in the Invalid state until negotiation with the FR DCE Switch completes successfully. 4-12 HSIM-W6 Installation Guide...

  • Page 59: Wpim-T1

    WPIM-T1 interface cables. Table A-1 provides connector type and part number information. Table A-1 T-1 Interface Cable Part Numbers Table A-2 provides RJ48 connector pin assignments. HSIM-W6 Installation Guide Connector Type Part Number RJ48C 9372094 Table A-2 T-1 Connector Pin Assignments...
  • Page 60 Receive Ring Receive Tip Not Used Transmit Ring Transmit Tip Not Used Shield Ground Shield Ground Table A-4 Network Pin Assignments Signal Receive Ring Receive Tip Not Used Transmit Ring Transmit Tip Not Used Not Used Not Used HSIM-W6 Installation Guide...

  • Page 61: Wpim-Sy

    WPIM-SY. Cable and Interface Type RS449 V.35 RS232 X.21 RS530 RS530 ALT A RS530A RS530A ALT A HSIM-W6 Installation Guide Table A-5 WPIM-SY Interface Cables Electrical Type RS422 V.35 RS232 X.21 RS422 RS422 RS422 RS422...

  • Page 62: Eia-449

    DB-37 pin male connector DIRECT MNEMONIC Send Data A Send Data B Receive Data A Receive Data B Clear to Send A Clear to Send B Send Timing A Send Timing B Receive Timing A Receive Timing B HSIM-W6 Installation Guide...

  • Page 63: V.35

    NAME Transmit Data A Transmit Data B Receive Data A Receive Data B Clear to Send A Request to Send A HSIM-W6 Installation Guide Connector 2 EIA-449 PAIR PIN NAME SHIELD 20 Receive Common Table A-8 V.35 Interface Cable Assembly Description EIA-530A ALT A to V.35...
  • Page 64 Timing B Receiver Signal Timing A Receiver Signal Timing B Transmitter Signal Timing A Transmitter Signal Timing B Calling Indicator Test Indicator Data Set Ready Data Terminal Ready Loopback Maintenance Local Loopback DRAIN Signal Common Signal Common HSIM-W6 Installation Guide...

  • Page 65: Eia-232

    Transmit Signal Timing Receive Signal Timing Transmit Signal Timing Remote Loopback Local Loopback Signal Common Signal Common HSIM-W6 Installation Guide Table A-10 EIA-232 Interface Cable Assembly Description EIA-530A ALT A to EIA-232 Connector 2 EIA-232 PIN PIN NAME Transmit Data...

  • Page 66: X.21

    Connector Type Sub DB 26-pin male DB-15 pin male DIRECT MNEMONIC Transmit A Transmit B Receive A Receive B Indication A Indication B Control A Control B Signal Element Timing A Signal Element Timing B DRAIN Signal Ground HSIM-W6 Installation Guide...

  • Page 67: Eia-530, Eia-530 Alt A, Eia-530 A, And Eia-530 A Alt A

    Receive Data B Clear to Send A Clear to Send B Request to Send A Request to Send B HSIM-W6 Installation Guide Cable Assembly Description EIA-530A ALT A to EIA-530 EIA-530A ALT A to EIA-530 ALT A EIA-530A ALT A to EIA-530A...
  • Page 68 Receive Signal Timing A Receive Signal Timing B Transmit Signal Timing A Transmit Signal Timing B 21 Remote Loopback Local Loopback Test Mode DCE Ready DTE Ready Signal Common Signal Common Signal Common Ring Indicator HSIM-W6 Installation Guide DIRECT MNEMONIC DRAIN...

  • Page 69: Wpim-Dds

    WPIM-DDS interface cable, and Table A-17 interface cable. Table A-16 DDS Interface Cable Part Number HSIM-W6 Installation Guide provides network Pin Assignment information for the DDS Cable and Interface Type Part Number 9360119...

  • Page 70: Wpim-E1

    WPIM-E1 network interface cable pin assignments. A-12 Cable and Interface Type Connector Type RJ45 Table A-19 Network Interface Signal Receive Ring Receive Tip Shield Ground Transmit Ring Transmit Tip Shield Ground Not Used Not Used Part Number 9372095 HSIM-W6 Installation Guide...
  • Page 71 Table A-20 provides WPIM-E1 DTE interface cable pin assignments. Table A-21 provides WPIM-E1 RJ45 network interface cable pin assignments. HSIM-W6 Installation Guide Table A-20 DTE Interface Signal Receive Ring Receive Tip Shield Ground Transmit Ring Transmit Tip Shield Ground Not Used...

  • Page 72: Wpim-Di

    WPIM-DI network interface cable pin assignments. A-14 Cable and Interface Type Table A-23 WPIM-DI Network Signal Receive Ring Receive Tip AC Coupled Ground Transmit Ring Transmit Tip AC Coupled Ground AC Coupled Ground AC Coupled Ground Connector Part Number Type RJ48 9372094 HSIM-W6 Installation Guide...

  • Page 73: Wpim-Hdsl

    WPIM-HDSL This section provides connector specifications for the WPIM-HDSL interface cables. provides pin assignments for the RJ-45 network interface connector. Table A-25 WPIM-HDSL Network Interface Cable Pin Assignments HSIM-W6 Installation Guide Table A-24 WPIM-DI Drop and Insert Signal Transmit Ring...

  • Page 74: Wpim-S/T

    RJ-45 network interface connector. Table A-26 WPIM-S/T Network Interface Cable Pin Assignments A-16 Signal Not Used Not Used Transmit + Receive + Receive - Transmit - Not Used Not Used Table A-26 HSIM-W6 Installation Guide...

  • Page 75: Regulatory Compliance

    Specifications and Standards Compliance This chapter contains hardware specifications, and safety and compliance standards for the HSIM-W6, and for the individual WPIMs that can be configured with this device. WAN Interface Processor Power Supply Power Consumption Operating Temperature Storage Temperature...

  • Page 76: Individual Wpim Regulatory Compliance

    This unit meets the EMI requirements of FCC Part 15, EN 55022, EN 50082-1, AS/NZS 3548, 89/336/EEC, CSA C108.8, and VCCI V-3. 91/263/EEC, and NET 2. TELECOM — This unit meets the EMC requirements of FCC Part HSIM-W6 Installation Guide...

  • Page 77: Wpim-Dds

    15, VCCI V-3, and CSA108.8. The WPIM-DI meets FCC Part 68 and CS-03. TELECOM — HSIM-W6 Installation Guide Individual WPIM Regulatory Compliance This unit meets the EMI requirements of EN 55022, This unit meets the EMI requirements of FCC Part...

  • Page 78: Wpim-S/T

    Part 15, EN 55022, VCCI V-3, CSA/08.8 EN 50082-1, AS/NZS 3548, 89/336/EEC. NEBS — This unit meets a minimum of Level 1 NEBS requirements in accordance with Bellcore GR 1089. This unit meets the EMC requirements of FCC This unit meets the EMC requirements of FCC HSIM-W6 Installation Guide...
  • Page 79 System Settings Ethernet IPX Network # Configuration Section Remote Router Database Dial Settings Remote Router Database Security Remote Router Database Bridging HSIM-W6 Installation Guide Table C-1 HSIM-W6 Item Router Name Message Dial Authentication Password/Secret ISDN SPID #1 ISDN SPID #2...
  • Page 80 Remote Router Database IPX SAPs a. Used only in PPP numbered mode of addressing b. Used only in PPP numbered mode of addressing Make one chart for each remote router in the remote router database. NOTE Configuration Section Bridging/ Routing...
  • Page 81 FCC Part 68 - User’s Information For HSIM-W6 The following instructions are to ensure compliance with the Federal Communications Commission (FCC) Rules, Part 68: All connections to the WPIM-T1, WPIM-DI and WPIM-DDS must be made using standard plugs and jacks.
  • Page 82 Appendix D: FCC Part 68 - User’s Information For HSIM-W6 If the unit appears to be malfunctioning, it should be disconnected from the telephone lines until you learn if your equipment or the telephone line is the source of the trouble. If your equipment needs repair, it should not be reconnected until it is repaired.
  • Page 83 • The encoded analog and billing protection is factory set and is not under the control of the customer. HSIM-W6 Installation Guide FCC Part 68 - User’s Information For HSIM-W6 , of (Customer Name) (Telephone Number) Subrate digital services. The...
  • Page 84 Appendix D: FCC Part 68 - User’s Information For HSIM-W6 I attest that the operator(s) maintainer(s) of the digital CPE responsible for the establishment, maintenance and adjustment of the encoded analog content and billing information has (have) been trained to perform these functions by successfully completing one of the following: Check appropriate one(s).
  • Page 85 Attachment Unit Interface. An IEEE 802.3 transceiver cable connecting the network AUI — device (such as a router) to the MAU (media access unit). Bandwidth on Demand — or closing multiple B channels) when the load in traffic increases or decreases.
  • Page 86 Transmission within the frequency range used for data transmission; i.e., In-Band Signaling — results in use of bandwidth normally reserved for data. Internet Protocol. A network layer protocol which allows a packet to traverse multiple IP — networks on the way to its final destination. HSIM-W6 Installation Guide...
  • Page 87 Leased Line — communications carrier for private use, usually incurring a monthly service rate. LEDs (Light Emitting Diodes) — Type of indicator lights on the panel of the router. A network connecting computers over a relatively small Local Area Network (LAN) —...
  • Page 88 A Network layer function that determines the path for transmitting packets through a Routing — network from source to destination. An echo message, available within the TCP/IP protocol suite, A Data Link layer protocol that provides asynchronous and Protocols used in IP and IPX for broadcasting open path HSIM-W6 Installation Guide...
  • Page 89 U.S. Department of Defense that define a two level layered approach for interoperability. TCP provides a connection-oriented Transport layer ensuring end-to-end reliability in data transmission. IP provides for Network layer connectivity using connectionless datagrams. The “cloud” of switched virtual connections. Telco Cloud — HSIM-W6 Installation Guide...
  • Page 90 Frames sent out by servers to clients, under IPX, to verify that clients are still logged on. A communications network that is geographically dispersed thus Wide Area Network — requiring links provided by communications carriers. Computer or terminal used by the systems administration or user. Workstation — HSIM-W6 Installation Guide...
  • Page 91 Hardware specs IEEE 802.1d bridging 2-16 IP internet firewall 2-17 IP routing 2-16 LAN support MIB support 2-18 HSIM-W6 Installation Guide Index Network information worksheets A-1, Remote Network Management Remote router worksheet Routing 2-16 Safety Requirements SNMP 2-18 SNMP Community Names...
  • Page 92 Index Index-2 HSIM-W6 Installation Guide...
