  • Page 1 SuperServer ® 1019D-FRN5TP 1019D-12C-FRN5TP 1019D-14C-FRN5TP 1019D-16C-FRN5TP USER’S MANUAL Revision 1.0b...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Warnings Special attention should be given to the following symbols used in this manual.

  • Page 4: Table Of Contents

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System .......................10 1.3 System Features ........................11 1.4 Chassis Features .......................13 Control Panel ........................13 Front Features ........................15 1.5 Motherboard Layout ......................16 Quick Reference Table for X11SDS-8C/12C/14C/16C .............17 Quick Reference Table for AOM-SMF-TP4F ..............18 Chapter 2 Installation in a Rack 2.1 Overview ..........................20...
  • Page 5 Preface Memory Installation ......................29 Memory Support ......................29 DIMM Module Population Configuration ................29 DIMM Module Population Sequence ................30 Install Procedure ......................31 Removal Procedure .......................31 Motherboard Battery ......................32 3.4 Chassis Components ......................33 AIOM and EDSFF "Ruler" Device Bays ................33 Replacing Fans ......................37 Checking the Airflow ......................38 Checking the Server's Airflow ..................38 Power Supply ........................39...
  • Page 6 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Appendix A BIOS Error Codes Appendix B Standardized Warning Statements for AC Systems Appendix C UEFI BIOS Recovery Instructions Appendix D System Specifications...
  • Page 7 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 8: Chapter 1 Introduction

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Chapter 1 Introduction 1.1 Overview The 1019D-(12C/14C/16C-)FRN5TP is a SuperServer system in the SC103-R407B chassis, containing an X11SDS-8C, X11SDS-12C, X11SDS-14C, or X11SDS-16C motherboard. Main Parts List Description Part Number Quantity Power supply PWS-407-1R Fans FAN-0157L4 CPU Passive Heatsink SNK-C0111PL AOM-SMF-TP4F I/O Slots...
  • Page 9 Chapter 1: Introduction Motherboard Model Variation Table Motherboard Model X11SDS-8C X11SDS-12C X11SDS-14C X11SDS-16C Name Intel Xeon Intel Xeon Intel Xeon Intel Xeon Processor Name D-2146NT D-2163IT D-2173IT D-2183IT Number of Cores Number of Threads Cache 11MB 17MB 19MB 22MB Processor Base 2.3GHz 2.1GHz 1.7GHz...

  • Page 10: Unpacking The System

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 1.2 Unpacking the System Inspect the box in which the server was shipped and note if it was damaged in any way. If any equipment appears damaged, file a damage claim with the carrier who delivered it. Decide on a suitable location for the rack unit that will hold the server.

  • Page 11: System Features

    Chapter 1: Introduction 1.3 System Features The table below provides you with an overview of the main features of the 1019D-(12C/14C/16C-)FRN5TP. Refer to Appendix D for additional specifications. System Features Motherboard X11SDS-8C for 1019D-FRN5TP X11SDS-12C for 1019D-12C-FRN5TP X11SDS-14C for 1019D-14C-FRN5TP X11SDS-16C for 1019D-16C-FRN5TP Chassis SC103-R407B...
  • Page 12 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual System Features Power 400W AC-DC, 80+ Platinum level Cooling Five 40 x 40 x 56 mm 13K-11K RPM counter-rotating fans Form Factor 1U rackmount Dimensions (WxHxD) 17.2 x 1.7 x 15 in. (437 x 43 x 381 mm)

  • Page 13: Chassis Features

    Chapter 1: Introduction 1.4 Chassis Features Note: The following parts are not included as part of the chassis, but are required as part of the system to function: • up to four AIOM modules (chassis comes with four dummy covers) •...
  • Page 14 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Figure 1-1. Control Panel and Front Ports Control Panel and Front Ports Features Item Feature Description Used to connect to text-based terminal or a terminal application such as PuTTY to Console manage the system via a shell (e.g., bash). The system must be on for this feature to work.

  • Page 15: Front Features

    Chapter 1: Introduction Informational LED LED Appearance Description Solid Green The node is powered on and operating normally. Blinking Green The node is in the process of shutting down. Solid Red The node is detecting an overheated condition. 1Hz Blinking Red The node is detecting a fan failure.

  • Page 16: Motherboard Layout

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 1.5 Motherboard Layout Below is a layout of the X11SDS-8C with the jumper, connector, and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information, and jumper settings, refer to Chapter 4. USB0 JSLOT4 SRW6...

  • Page 17: Quick Reference Table For X11Sds-8C/12C/14C/16C

    Power and Reset Button JRK1 Intel RAID Key Header (supporting AIOM Slots) JSIM1 Nano SIM Card Socket JSLOT1 - JSLOT4 Supermicro Advanced I/O Module (AIOM) *Please unplug power before removing/installing module cards JTPM1 Trusted Platform Module (TPM)/Port 80 Connector JUID UID Switch Header...

  • Page 18: Quick Reference Table For Aom-Smf-Tp4F

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Quick Reference Table for AOM-SMF-TP4F Jumper Description Default Setting JPTG1 10G LAN Enable/Disable Pins 1-2 (Enabled) Description Status LED1 Power LED Solid Green: Power On Connector Description Front Control Panel Cable Header JCOM1 Serial Console Port and USB 3.0 Port JLAN1 1G RJ45 Port and USB 3.0 Port JLAN2...
  • Page 19 Chapter 1: Introduction CPU D-2146-NT PCIe3.0 8 x4 4x SIOM (2x4 EACH) DDR4 DIMMA DIMMB(Far) 2666/2400/2133/1866 MHz USB2.0 X 4 DDR4 DIMMD DIMME(Far) 2666/2400/2133/1866 MHz USB2.0 X 2 USB2.0 X 1 USB 2.0 HUB DEFAULT M.2 X4 PWR_I/O BOARD CONNECTOR SATA III PCIe3.0 X4 EDSFF X4...

  • Page 20: Chapter 2 Installation In A Rack

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Chapter 2 Installation in a Rack 2.1 Overview This chapter provides advice and instructions for mounting your system in a rack. Caution: Electrostatic Discharge (ESD) can damage electronic components. To pre- vent such damage to PCBs (printed circuit boards), it is important to use a grounded wrist strap, handle all PCBs by their edges, and keep them in anti-static bags when not in use.

  • Page 21: Server Precautions

    Chapter 2 Installation in a Rack • In multiple rack installations, the racks should be coupled together.Always make sure the rack is stable before extending a server or other component from the rack. • Extend only one server or component at a time - extending two or more simultaneously may cause the rack to become unstable.

  • Page 22: Circuit Overloading

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

  • Page 23: Installing The Rails

    Chapter 2 Installation in a Rack 2.3 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. Also refer to the installation instructions that came with the rack. This rail set fits a rack between 26" and 33.5" deep. Identifying the Sections of the Rack Rails The chassis package includes two rack rail assemblies in the rack mounting kit.

  • Page 24: Installing The Inner Rails

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Installing the Inner Rails The inner rails are pre-attached to the chassis, but should the need arise to remove them reinstallation of the rails is simple and can be accomplished with a standard head screwdriver. Installing the Inner Rails 1.

  • Page 25: Installing The Outer Rack Rails

    Chapter 2 Installation in a Rack Installing the Outer Rack Rails Outer rails attach to the server rack and hold the server in place. The outer rails for the SC103-R407B chassis extend between 30 inches and 33 inches. Installing the Outer Rails to the Rack 1.

  • Page 26: Installing The Chassis Into A Rack

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 2.4 Installing the Chassis into a Rack Once rails are attached to the chassis and the rack, you can install the server. Warning: Mounting the system into the rack requires at least two people to support the chassis during installation.

  • Page 27: Chapter 3 Maintenance And Component Installation

    Chapter 3 Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 28: Accessing The System

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 3.2 Accessing the System Removing the Chassis Cover You can access some chassis components, such as fans, by removing the cover. Removing the Top Cover 1. Remove the power from the system as described in Section 3.1. 2.

  • Page 29: Motherboard Components

    DIMM slots with memory modules of the same type and size will result in interleaved memory, which will improve memory performance. Check the Supermicro website for possible updates to memory support. DIMM Module Population Configuration For optimal memory performance, follow the table below when populating memory.

  • Page 30: Dimm Module Population Sequence

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual DIMM Module Population Sequence When installing memory modules, the DIMM slots should be populated in the following order: DIMMA1, DIMMB1, DIMMD1, DIMME1. • Always use DDR4 DIMM modules of the same type and speed. • Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed of the slowest DIMM.

  • Page 31: Install Procedure

    Caution: Exercise extreme caution when installing or removing memory modules to prevent damage to the DIMMs or slots. Note: Visit the product page on the Supermicro website for possible updates to memory support (www.supermicro.com). Removal Procedure To remove a DIMM module, unlock the release tabs then pull the module from the slot.

  • Page 32: Motherboard Battery

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Motherboard Battery The motherboard uses CMOS memory to retain BIOS settings when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery 1. Remove power from the system as described in section 3.1 and remove the node from the chassis.

  • Page 33: Chassis Components

    1. Remove the dummy AIOM insert from the front side of the chassis by holding the lever and gently pulling the insert out from the chassis. 2. A Supermicro AIOM network module (such as AOC-AG-i8, sold separately) may now be installed into the slot.
  • Page 34 1. Power down the system as described in section 3-1. Once the dummy AIOM insert is removed, the Supermicro AIOM network module may be installed. 2. Gently slide the AIOM module into the slot by aligning the PCB edge into the chassis rail.
  • Page 35 Chapter 3 Maintenance and Component Installation 4. The module has a spring loaded push pin. Push the pin inward to engage with the chassis. 5. Slide the lock on the metal bracket to the right. This prevents the push pin from accidental release.
  • Page 36 Inserting the EDSFF Module 1. Power down the system as described in section 3-1. Once the dummy EDSFF insert is removed, the Supermicro EDSFF network module may be installed. 2. Gently slide the EDSFF module into the slot. 3. Once the EDSFF module is inserted, gently push the module into the slot for connector engagement, then rotate/press down on the latch to lock it in place.

  • Page 37: Replacing Fans

    Chapter 3 Maintenance and Component Installation Replacing Fans Five counter-rotating fans circulate air through the chassis to lower the internal temperature. These fans are designed to be easily changed, with no tools required and no need to remove any other parts inside the chassis. Replacing a System Fan 1.

  • Page 38: Checking The Airflow

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Checking the Airflow Checking the Server's Airflow • Make sure there are no objects to obstruct airflow in and out of the server. • Do not operate the server without the AIOM module or AIOM dummy insert, and EDSFF drives or EDSFF dummy insert.

  • Page 39: Power Supply

    100-240v input voltage. An amber light will be illuminated on the power supply when the power is off. An illuminated green light indicates that the power supply is operating. New units can be ordered directly from Supermicro or authorized distributors. Changing One of the Two Redundant Power Supplies 1.

  • Page 40: Installing An Optional Hard Drive

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Installing an Optional Hard Drive Installing an Optional 2.5" Hard Disk Drive with a Fixed Enclosure 1. Obtain the mounting enclosure and secure the drive(s) to the enclosure with four screws. 2. Secure the HDD enclosure to the top side of the motherboard. 3.
  • Page 41 Chapter 3 Maintenance and Component Installation Screws Screws Figure 3-10. Securing the Mounting Enclosure with Hard Drive to the top side of the Motherboard Caution: Do not unplug or pull the cables around the drive bay when the enclosure screws are not secured to the system. Unplugging or pulling the cables may cause the motherboard to shift or be lifted up.

  • Page 42: Chapter 4 Motherboard Connections

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 43: Headers And Connectors

    Chapter 4: Motherboard Connections 4.2 Headers and Connectors Fan Headers The X11SDS series has five 4-pin fan headers (FAN1 - FAN5). These headers are backwards- compatible with the traditional 3-pin fans. However, fan speed control is available for 4-pin fans only by Thermal Management via the IPMI 2.0 interface. Refer to the table below for pin definitions.
  • Page 44 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual M.2 Slot The X11SDS series motherboard has four M.2 slots. M.2 was formerly known as Next Generation Form Factor (NGFF) and serves to replace mini PCI-E. M.2 allows for a variety of card sizes, increased functionality, and spatial efficiency. The M.2 slot at JMD1 is an E-Key that supports PCI-E3.0 x2 and USB 2.0 interfaces in a 2230 form factor, whereas the M.2 slot at JMD2 is a B-Key that supports PCI-E3.0 x2, SATA3.0, and USB3.0 interfaces in a 2242/3042 form factor.
  • Page 45 PCI-E3.0 x8 lanes in each slot which can be utilized to offer additional LAN ports, VPU, storage devices, etc. on the motherboard. Please visit the Supermicro website for all available module options. Please also keep in mind that it is mandatory that power be unplugged prior...
  • Page 46 Note: UID can also be triggered via IPMI on the control panel. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com/ support/manuals/. UID Switch...

  • Page 47: Jumpers

    Chapter 4: Motherboard Connections 4.3 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. See the diagram below for an example of jumping pins 1 and 2.
  • Page 48 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual VGA Enable/Disable JPG1 allows you to enable or disable the VGA port using the onboard graphics controller. The default setting is Enabled. VGA Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled (Default) Pins 2-3 Disabled Manufacturing Mode Select Close pins 2-3 of jumper JPME2 to bypass SPI flash security and force the system to operate in the manufacturing mode, which will allow the user to flash the system firmware from a host...
  • Page 49 Chapter 4: Motherboard Connections IPMI LAN Port Enable/Disable Use the JBM1 jumper to enable or disable the IPMI Shared LAN port on LAN3. IPMI LAN Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled (Default) Pins 2-3 Disabled TPM Enable/Disable Use JPT1 to enable or disable support for the TPM module.

  • Page 50: Led Indicators

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 4.4 LED Indicators BMC Heartbeat LED BMC_HB_LED1 is the BMC Heartbeat LED. When the LED is blinking green, the BMC is functioning normally. Refer to the table below for more information. BMC Heartbeat LED Indicator LED Color Definition Green: BMC: Normal...

  • Page 51: Chapter 5 Software

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to create a DVD of the drivers and utilities it contains.
  • Page 52 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Note: Click the icons showing a hand writing on paper to view the readme files for each item. Click the computer icons to the right of these items to install each item (from top to the bottom) one at a time.

  • Page 53: Superdoctor ® 5

    5.2 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 54: Ipmi

    There are several BIOS settings that are related to IPMI. IPMI management is supported when the lower 10G LAN port is connected (Figure 1-1). For general documentation and information on IPMI, please visit our website at: http://www.supermicro.com/products/nfo/IPMI.cfm.

  • Page 55: Chapter 6 Uefi Bios

    Chapter 6: UEFI BIOS Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS Setup utility for the X11SDS series motherboard. The BIOS is stored in a flash chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 56: Main Menu

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is the BIOS build date after RTC reset. Supermicro X11SDS series BIOS Version This feature displays the version of the BIOS ROM used in the system.
  • Page 57 Chapter 6: UEFI BIOS Memory Information Total Memory This feature displays the total size of memory available in the system. Memory Speed This feature displays the speed of the memory detected by the system.

  • Page 58: Advanced

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 6.3 Advanced Use this menu to configure advanced settings. Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction. When this occurs, restore to default manufacturer settings. Boot Feature ...
  • Page 59 Chapter 6: UEFI BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this feature is set to Immediate, the ROM BIOS of the host adapters will "capture" Interrupt 19 at bootup immediately and allow the drives that are attached to these host adapters to function as bootable disks.
  • Page 60 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual • Processor Socket • Processor ID • Processor Frequency • Processor Max Ratio • Processor Min Ratio • Microcode Revision • L1 Cache RAM • L2 Cache RAM • L3 Cache RAM • Processor 0 Version Hyper-Threading (ALL) Select Enabled to support Intel Hyper-threading Technology to enhance CPU performance.
  • Page 61 Chapter 6: UEFI BIOS If set to Enable, the hardware prefetcher will prefetch streams of data and instructions from the main memory to the L2 cache to improve CPU performance. The options are Enable and Disable. Adjacent Cache Prefetch (Available when supported by the CPU) The CPU prefetches the cache line for 64 bytes if this feature is set to Disabled.
  • Page 62 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual *If the feature above is set to Custom, the following features will be available for configuration: Power Performance Tuning This feature allows you to set whether the operating system or the BIOS controls the Energy Performance BIAS (EPB). The options are OS Controls EPB and BIOS Controls EPB.
  • Page 63 Chapter 6: UEFI BIOS Hardware PM State Control  Hardware P-States This setting allows you to select between OS and hardware-controlled P-states. Select- ing Native Mode allows the OS to choose a P-state. Selecting Out of Band Mode allows the hardware to autonomously choose a P-state without OS guidance. Selecting Native Mode with No Legacy Support functions as Native Mode with no support for older hard- ware.
  • Page 64 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Chipset Configuration  Warning: Setting the wrong values in the sections below may cause the system to malfunction. North Bridge Configuration   Memory Configuration Enforce POR Select POR (Plan of Record) to enforce POR restrictions on DDR4 frequency and volt- age programming.
  • Page 65 Chapter 6: UEFI BIOS Mirror Mode This feature allows memory to be mirrored between two channels, providing 100% redundancy. The options are Disable and Enable Mirror Mode (1LM). *If the feature above is set to Enable Mirror Mode, Multi Rank Sparing ADDDC Sparing will not be available for configuration: Memory Rank Sparing Select Enable to enable memory-sparing support for memory ranks to improve memory...
  • Page 66 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual *If the feature above is set to Enable, Patrol Scrub Interval will be available for configuration: Patrol Scrub Interval This feature allows you to decide how many hours the system should wait before the next complete patrol scrub is performed. Use the keyboard to enter a value from 0-24. The default setting is 24.
  • Page 67 Chapter 6: UEFI BIOS ECRC Use this feature to enable or disable Error Capabilities and Control Register (ECRC). The options are Disable and Enable.  IOAT Configuration Disable TPH Transparent Huge Pages (TPH) is a Linux memory management system that enables communication in larger blocks (pages).
  • Page 68 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual PassThrough DMA Use this feature to allow devices such as network cards to access the system memory without using a processor. Select Enable to use the Non-Isoch VT-d Engine Pass Through Direct Memory Access (DMA) support. The options are Enable and Disable. Use this feature to enable Non-Isoch VT-d Engine Address Translation Services (ATS) support.
  • Page 69 Chapter 6: UEFI BIOS CfgBar size Use this feature to set up the VMD configuration BAR size. The default is 25. CfgBar attribute Use this feature set up the VMD configuration BAR attribute. The default option is 64-bit prefetchable. MemBar1 size Use this feature to set up the VMD memory BAR1 size.
  • Page 70 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual CfgBar attribute Use this feature set up the VMD configuration BAR attribute. The default option is 64-bit prefetchable. MemBar1 size Use this feature to set up the VMD memory BAR1 size. The default is 25. MemBar1 attribute Use this feature set up the VMD configuration BAR attribute.
  • Page 71 Chapter 6: UEFI BIOS MemBar1 size Use this feature to set up the VMD memory BAR1 size. The default is 25. MemBar1 attribute Use this feature set up the VMD configuration BAR attribute. The options are 32-bit prefetchable, 64-bit non-prefetchable, and 64-bit prefetchable. MemBar2 size Use this feature to set up the VMD memory BAR2 size.
  • Page 72 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Server ME Configuration  • Oper. Firmware Version • Backup Firmware Version • Recovery Firmware Version • ME Firmware Status #1 • ME Firmware Status #2 • Current State • Error Code SATA Configuration  When this submenu is selected, the AMI BIOS automatically detects the presence of the SATA devices that are supported by the Intel PCH chip and displays the following features: SATA Controller Use this feature to enable or disable the onboard SATA controller supported by the Intel PCH...
  • Page 73 Chapter 6: UEFI BIOS Aggressive Link Power Management When this feature is set to Enable, the SATA AHCI controller manages the power usage of the SATA link. The controller will put the link in a low power mode during extended periods of I/O inactivity, and will return the link to an active state when I/O activity resumes.
  • Page 74 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual SATA HDD Unlock This feature allows you to remove any password-protected SATA disk drives. The options are Disable and Enable. *If the feature "Configure sSATA as" above is set to RAID, sSATA RSTe Boot Into and sSATA RAID Option ROM/UEFI Driver are available for configuration: sSATA RSTe Boot Info Select Enable to provide full int13h support for the devices attached to the sSATA controller.
  • Page 75 Chapter 6: UEFI BIOS PCIe/PCI/PnP Configuration  The following information will display: • PCI Bus Driver Version • PCI Devices Common Settings: Above 4G Decoding (Available if the system supports 64-bit PCI decoding) Select Enabled to decode a PCI device that supports 64-bit in the space above 4G Address. The options are Disabled and Enabled.
  • Page 76 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual JSLOT1 ~ JSLOT4 OPROM Use this feature to select which firmware type to be loaded for the add-on card in this slot. The options are Disabled, Legacy PXE, EFI, and Legacy iSCSI. Onboard Video Option ROM Use this feature to select the onboard Video Option ROM type.
  • Page 77 Chapter 6: UEFI BIOS Ipv4 HTTP Support Select Enabled to enable IPv4 HTTP boot support. The options are Disabled and Enabled. Ipv6 PXE Support Select Enabled to enable IPv6 PXE boot support. The options are Disabled and Enabled. Ipv6 HTTP Support Select Enabled to enable IPv6 HTTP boot support.
  • Page 78 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual  Serial Port 2 Configuration Serial Port 2 Select Enabled to enable the onboard serial port specified by the user. The options are Disabled and Enabled. Enable this feature for the next two features to display and only the Change Settings feature is available for configuration.
  • Page 79 Chapter 6: UEFI BIOS Bits per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
  • Page 80 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual COM2/SOL Console Redirection Select Enabled to use the SOL port for Console Redirection. The options are Disabled and Enabled. *If the feature above is set to Enabled, the following features are available for configuration: Console Redirection Settings ...
  • Page 81 Chapter 6: UEFI BIOS Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 82 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) This submenu allows you to configure Console Redirection settings to support Out-of-Band Serial Port management. Console Redirection Select Enabled to use a COM port selected by the user for EMS Console Redirection. The options are Disabled and Enabled.
  • Page 83 Chapter 6: UEFI BIOS Data Bits Parity Stop Bits ACPI Settings  WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) platform and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment in order to reduce system crashes and enhance system recovery and health monitoring.
  • Page 84 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Pending operation Use this feature to schedule a TPM-related operation to be performed by a security device for system data integrity. The options are None and TPM Clear. Note: Your system will reboot to carry out a pending TPM operation. Platform Hierarchy Use this feature to disable or enable platform hierarchy for platform protection.
  • Page 85 Chapter 6: UEFI BIOS  Discard Changes and Exit Use this feature to discard all changes and exit TLS settings. Delete Cert Use this feature to delete certification. Intel(R) Virtual RAID on CPU  Intel(R) VROC with VMD Technology 5.4.0.1039 RAID volume and Intel VMD Controller information will be displayed if they are detected by the system.

  • Page 86: Ipmi

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 6.4 IPMI Use this menu to configure Intelligent Platform Management Interface (IPMI) settings. This feature displays the IPMI firmware revision in your system. Status of BMC This feature displays the status of the IPMI firmware installed in your system. System Event Log Enabling/Disabling Options SEL Components...
  • Page 87 Chapter 6: UEFI BIOS When SEL is Full This feature allows you to determine what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full.
  • Page 88 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual VLAN This feature is configurable if the Update IPMI LAN Configuration feature is set to Yes. Use this feature to enable or disable the IPMI VLAN function. The options are Disable and Enable. *If the feature above is set to Enable, the VLAN ID feature below is available for configuration: VLAN ID Use this feature to select a value for VLAN ID.
  • Page 89 Chapter 6: UEFI BIOS Configuration Address Source Use this feature to select the source of the IP address for this computer. If Static is selected, you will need to know the IP address of this computer and enter it to the system manually in the field.

  • Page 90: Security

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 6.5 Security Use this menu to configure the security settings. Administrator Password Use this feature to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from three to 20 characters long. User Password Use this feature to set the user password to enter the BIOS setup utility.
  • Page 91 Chapter 6: UEFI BIOS Secure Boot Mode This feature allows you to select the desired secure boot mode for the system. The options are Standard and Custom. *If Secure Boot Mode is set to Custom, Key Management features are available for configuration: CSM Support This feature is for manufacturing debugging purposes.
  • Page 92 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual  Restore DB defaults Select Yes to restore the DB defaults.  Platform Key (PK) Update Select Yes to load a factory default PK or No to load from a file on an external media.  Key Exchange Keys (KEK) Update Select Yes to load a factory default KEK or No to load from a file on an external media.
  • Page 93 Chapter 6: UEFI BIOS  OsRecovery Signatures Update Select Yes to load a factory default dbr or No to load from a file on an external media. Append Select Yes to add the dbr from the manufacturer's defaults list to the existing dbr. Select No to load the dbr from a file.

  • Page 94: Event Logs

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 6.6 Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options Smbios Event Log Change this feature to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 95 Chapter 6: UEFI BIOS Smbios Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events. The options are Enabled and Disabled. MECI (Multiple Event Count Increment) Enter the increment value for the multiple event counter. Enter a number between 1 to 255. The default setting is 1.

  • Page 96: Boot

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 6.7 Boot Use this menu to configure boot settings: Boot mode select Use this feature to select the boot mode. The options are LEGACY, UEFI, and DUAL. LEGACY to EFI Support Select Enabled to boot EFI OS support after Legacy boot order has failed. The options are Disabled and Enabled.
  • Page 97 Chapter 6: UEFI BIOS • Boot Option #8 • Boot Option #9 • Boot Option #10 • Boot Option #11 • Boot Option #12 • Boot Option #13 • Boot Option #14 • Boot Option #15 • Boot Option #16 •...

  • Page 98: Save & Exit

    SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 6.8 Save & Exit Use this menu to configure save and exit settings. Save Options Discard Changes and Exit Select this feature to quit the BIOS Setup without making any permanent changes to the system configuration and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.
  • Page 99 Chapter 6: UEFI BIOS Default Options Restore Optimized Defaults To set this feature, select Restore Optimized Defaults and press <Enter>. These are factory settings designed for maximum system performance but not for maximum stability. Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>. This enables the user to save any changes to the BIOS setup for future use.
  • Page 100 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Appendix A BIOS Error Codes A.1 BIOS Error Beep (POST) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 101 When BIOS performs the Power-On Self-Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.
  • Page 102 Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 103 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 104 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 105 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 106 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 107 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 108 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원 공급장치로부터...
  • Page 109 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 110 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 111 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 112 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 113 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 114 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 115 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 116 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 117 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 118 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 119 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 120 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 121 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
  • Page 122 Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 123 Directory of a USB device or a writeable CD/DVD. Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website at www.supermicro.com to download the BIOS image into a USB flash device and rename it "Super.ROM" for BIOS recovery use.
  • Page 124 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 3. After locating the healthy BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 125 Appendix C: UEFI BIOS Recovery 5. After the BIOS recovery process is complete, press any key to reboot the system. 6. Using a different system, extract the BIOS package into a USB flash drive. 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu.
  • Page 126 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual 8. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 6. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process. Note: Do not interrupt this process until the BIOS flashing is complete.
  • Page 127 Appendix D: System Specifications Appendix D System Specifications Processors Single Intel Xeon D-2146NT with speeds of up to 80W for 1019D-FRN5TP in an H4 LGA1151 type socket Single Intel Xeon D-2163IT with speeds of up to 75W for 1019D-12C-FRN5TP in an H4 LGA1151 type socket Single Intel Xeon D-2173IT with speeds of up to 70W for 1019D-14C-FRN5TP in an H4 LGA1151 type socket Single Intel Xeon D-2183IT with speeds of up to 100W for 1019D-16C-FRN5TP in an H4 LGA1151 type socket Note: Please refer to the motherboard specifications pages on our website for updates to supported processors.
  • Page 128 SuperServer 1019D-(12C/14C/16C-)FRN5TP User's Manual Power Supply Model: PWS-407P-1R (x2), 80 Plus level Platinum Total Output Power: 400W AC Input Voltages: 100-240V, 200-240V Rated Input Frequency: 50-60Hz Max: 33A & Min: 0.5A 5V SB: Max: 3A / Min: 0A Output Type: Gold Finger Connector Mating with Molex 45984-4343 Operating Environment Operating Temperature: 0º...
