QBiP-1605B
3.5" SBC Boards- QBiP-1605B User's Manual
1st Ed
1
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QBiP-1605B and is the answer not in the manual?

Questions and answers

Related Manuals for GIGAIPC QBiP-1605B

Summary of Contents for GIGAIPC QBiP-1605B

  • Page 1: Sbc Boards- Qbip-1605B User's Manual 1St Ed

    QBiP-1605B 3.5” SBC Boards- QBiP-1605B User’s Manual 1st Ed www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 2: Copyright Notice

    GIGAIPC reserves the right to make changes in the product design without notice to its users. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 3: Acknowledgement

    IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 4: Packing List

    Item Quantity QBiP-1605B SATA power cable If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 5: About This Document

    (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 6: Safety Precautions

    11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 8: Fcc Statement

    Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 9: China Rohs Requirements (Cn)

    ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○ 连接器及线材 O： 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。 X： 表示该有毒有害物质至少在该部件的 某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求。 备注： 此产品所标示之环保使用期限， 系指在一般正常使用状况下。 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 10: China Rohs Requirement (En)

    SJ/T 11363-2006-stipulated requirement. Note: The Environment Friendly Use Period as labeled on this product is applicable under normal usage only www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 11: Table Of Contents

    SATAPW (SATA 6 Gb/s power connector) ...... 25 2.2.6 SATA (SATA 6 Gb/s connector) ........26 2.2.7 FUSB2_2 (USB 2.0 header) ..........27 2.2.8 FUSB2_1 (USB 2.0 header) ..........28 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 12 2.2.24 CPU_FAN (System FAN Connector) ......... 43 2.2.25 SYS_FAN (System FAN Connector) ........44 2.2.26 Battery (Battery Connector) ........... 45 2.2.27 IO Connector Information ..........46 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 13: Chapter1 - Product Specifications

    Chapter 1 Chapter1 - Product Specifications QBiP-1605B www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 14 GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 15: Specifications- Qbip-1605B

    1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s) 1 x 2230 M.2 E-Key Expansion Slots 1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) -- support 3G module www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 16 1 x 4-pin box power connector (+9V~36V Full Range) Operating temperature: 0°C to 60°C Operating humidity: 0-90% (non-condensing) Operating Properties Non-operating temperature: -40°C to 85°C Non-operating humidity: 0%-95% (non-condensing) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 17: Chapter 2 - Hardware Information

    Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 18: Jumpers And Connectors

    Jumpers and Connectors www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 19 COM2 RS-232/422/485, and 5V/12V/RI COM COM2 Serial port header COM1 RS-232/422/485, and 5V/12V/RI COM COM1 Serial port header MPCIE Mini PCIE for 3G/4G module www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 20 HDMI Connector (*The HDMI3’s Function is HDMI3 Disabled, during eDP Function Enabled) HDMI4 HDMI Connector LAN2 LAN Connectors LAN1 LAN Connectors USB3 USB 3.2 Gen 1 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 21: Bkl_Cn (Backlight Control Connector)

    2.2.1 BKL_CN (Backlight Control connector) Pin 1 Backlight Control connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition eDP_BKLTEN eDP_BKLTCTL www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 22: Spk_Out (Speaker Out Connector)

    Speaker out connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out R+ Speaker Out R- Speaker Out L- Speaker Out L+ www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 23: F_Audio (Audio Line-Out Port)

    F_Audio (Audio line-out port) Pin 1 F_Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Definition F_MIC1_L F_MIC1_R F_AUDIO_DET F_HP_R F_MIC_JD FAUDIO_JD F_HP_L F_HP_JD www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 24: Sodimm1, Sodimm2 (Ddr4 So-Dimm Slot#1/Slot#2)

    2.2.4 SODIMM1, SODIMM2 (DDR4 SO-DIMM slot#1/ slot#2) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 25: Satapw (Sata 6 Gb/S Power Connector)

    2.2.5 SATAPW (SATA 6 Gb/s power connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 26: Sata (Sata 6 Gb/S Connector)

    2.2.6 SATA (SATA 6 Gb/s connector) Pin 1 SATA 6Gb/s Connector Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 27: Fusb2_2 (Usb 2.0 Header)

    2.2.7 FUSB2_2 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05G117 PINREX Pin No. Definition No Pin No Connect www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 28: Fusb2_1 (Usb 2.0 Header)

    2.2.8 FUSB2_1 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05G117 PINREX Pin No. Definition No Pin No Connect www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 29: Gpio_Cnt (General Purpose Input/Output Header)

    Pin 1 GPIO Connector Connector PN Vendor 725-81-12TW00 PINREX A2004WV-2X06P46 JOINT-TECH Definition Definition GPI_0 GPO_0 GPI_1 GPO_1 GPI_2 GPO_2 GPI_3 GPO_3 SMB_IO_ SMB_IO_ DATA 3.3V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 30: Sys_Panel (Front Panel Header)

    Vendor 210-92-05G111 PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 31: M2E (M.2 E-Key For Wifi Ngff)

    2.2.11 M2E (M.2 E-key for WiFi NGFF) 2.2.12 M2M (M.2 M key for NVME/SATA) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 32: At_Cn (At/Atx Power Mode Select Jumper)

    2.2.13 AT_CN (AT/ATX power mode select jumper) Pin 1 AT/ATX power mode select jumper Pin No. Definition 1-2 Close : AT mode. 2-3 Close : ATX mode. COMM (Default setting) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 33: Hdmi/Edp_Cn (Hdmi/Edp Mode Select Jumper)

    Pin No. Definition 1-2 Close: HDMI mode. HDMI (Default setting, HDMI3 I/O COMM is Enable) 2-3 Close: eDP mode. (HDMI3 I/O Port is Disable) HDMI3 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 34: Jcom2 (Com2 Ri Pin Ri/5V/12V Select)

    2.2.15 JCOM2 (COM2 RI pin RI/5V/12V Select) Pin 1 JCOM11 Jumper Select 1-2 Close: 5V (Power COM) 3-4 Close: RI (Stand COM) Default 5-6 Close: 12V (Power COM) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 35: Jcom1 (Com1 Ri Pin Ri/5V/12V Select)

    2.2.16 JCOM1 (COM1 RI pin RI/5V/12V Select) Pin 1 JCOM11 Jumper Select 1-2 Close: 5V (Power COM) 3-4 Close: RI (Stand COM) Default 5-6 Close: 12V (Power COM) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 36: Com1 (Serial Port Header)

    2.2.17 COM1 (Serial port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Pin No. Definition DTRD No Connect RI/5V/12V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 37: Com2 (Serial Port Header)

    2.2.18 COM2 (Serial port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Pin No. Definition DTRD No Connect RI/5V/12V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 38: Com3 (Serial Port Header)

    2.2.19 COM3 (Serial port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Pin No. Definition DTRD No Connect RI/5V/12V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 39: Com4 (Serial Port Header)

    2.2.20 COM4 (Serial port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Pin No. Definition DTRD No Connect RI/5V/12V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 40: Mpcie (Mini Pcie For 3G/4G Module)

    2.2.21 MPCIE (Mini PCIE for 3G/4G module) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 41: Dc In (Dc In 1 X 4 Pin Power Connector)

    2.2.22 DC IN (DC IN 1 x 4 pin power connector) Pin 1 DC IN power connector Connector PN Vendor 753-81-04TW00 PINREX Pin No. Definition DCIN DCIN www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 42: Edp (Edp Connector)

    Pin No. Definition EDP_TXN0 EDP_TXN3 EDP_TXP0 EDP_TXP3 eDP_DET# EDP_TXN1 EDP_TXP1 EDP_AUXN EDP_AUXP EDP_TXN2 EDP_TXP2 EDP_HPD 3.3V Connector PN Vendor 50286-02071-001 ACES A1252WV-SF- JOINT-TECH 2X10PN6BG1G00L www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 43: Cpu_Fan (System Fan Connector)

    2.2.24 CPU_FAN (System FAN Connector) Pin 1 CPU FAN Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH 1 2 3 4 Pin No. Definition FANTECH www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 44: Sys_Fan (System Fan Connector)

    2.2.25 SYS_FAN (System FAN Connector) Pin 1 CPU/System FAN Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Pin No. Definition FANTECH www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 45: Battery (Battery Connector)

    2.2.26 Battery (Battery Connector) Pin 1 Battery Cable Connector Pin No. Definition 3.3V RTC www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 46: 2.2.27 Io Connector Information

    Disabled, during eDP Function Enabled) 30 HDMI 4 HDMI Connector 31 LAN2 LAN Connectors 32 LAN1 LAN Connectors 33 USB3 USB 3.2 Gen 1 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
