uATX-Q670A (MQ670AM)

Micro-ATX Motherboard

User's Manual 1st Ed
1
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

Advertisement

Table of Contents
loading

Related Manuals for GIGAIPC uATX-Q670A

Summary of Contents for GIGAIPC uATX-Q670A

  • Page 1: Micro-Atx Motherboard

    (MQ670AM) Micro-ATX Motherboard User’s Manual 1st Ed www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 2: Copyright Notice

    GIGAIPC reserves the right to make changes in the product design without notice to its users. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 3: Acknowledgement

    IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 4: Packing List

    Quantity uATX-Q670A (MQ670AM) IO Shield SATA cable If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 5: About This Document

    (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 6: Safety Precautions

    11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 8: Fcc Statement

    Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 9: China Rohs Requirements (Cn)

    ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○ 连接器及线材 O： 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。 X： 表示该有毒有害物质至少在该部件的 某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求。 备注： 此产品所标示之环保使用期限， 系指在一般正常使用状况下。 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 10: China Rohs Requirement (En)

    SJ/T 11363-2006-stipulated requirement. Note: The Environment Friendly Use Period as labeled on this product is applicable under normal usage only www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 11: Table Of Contents

    VGA (VGA Port) .............. 27 2.2.7 COM1 (COM1 Port (RS-232/422/485 & RI/5V/12V)) ....28 2.2.8 JCOM1 (RI pin RI/5V/12V Select jumper for COM1 Port)...29 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 12 2.2.29 AT_CN (AT/ATX mode select jumper) ......50 2.2.30 BKL_CN (Backlight Control header) ......... 51 2.2.31 LVDS (LVDS connector) ........... 52 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 13 3.3.14 Intel(R) Platform Service Record ........74 3.3.15 Tls Auth Configuration ............. 75 Chipset ................76 Security ................78 Boot .................. 81 Save & Exit ............... 82 MEBx ................83 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 14: Chapter1 - Product Specifications

    Chapter 1 Chapter1 - Product Specifications www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 15 33.02 132.08 72.39 31.6 35.5 243.84 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 16: Specifications

    1 x PCIe x1 (Gen 3x1) 1 x PCIe x4 (Gen 3x4) 1 x 2280/2242 M.2 M-Key (PCIe Gen 4x4, SATA 6Gb/s) 1 x 2230 M.2 E-Key www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 17 OS Compatibility Windows 10/11 (x64) Operating temperature: 0°C to 60°C Operating humidity: 0-90% (non-condensing) Operating Properties Non-operating temperature: -40°C to 85°C Non-operating humidity: 0%-95% (non-condensing) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 18: Chapter 2 - Hardware Information

    Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 19: Jumpers And Connectors

    Jumpers and Connectors www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 20 USB 2.0 header FUSB2_3 TPM header M.2 Slot, 2242/2280 M-key M.2 Slot, 2230 E-Key COM2, COM3, COM4 Serial Port header (RS-232) GPIO_CNT General Purpose input/output header www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 21 PCIEX16_A, PCIEX16_B PCIe x16 (Gen4 x16) Slot PCIEX1 PCIe x1 (Gen3 x1) Slot AT_CN AT/ATX mode select jumper BKL_CN Backlight Control header LVDS LVDS connector www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 22: Rear I/O Connector

    1 x 2.5GbE LAN Port (top) USB3_LAN2 2 x USB 3.2 Gen 2x1 (bottom) 3 x Audio Jacks AUDIO (Line in, Line out, Mic in) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 23: Usb3_Lan2 (Usb 3.2 Gen 2X1 + 2.5Gbe Lan Connector)

    TX4- State Description USB3_RX1n USB3_RX2n Orange On 2.5Gbps data rate USB3_RX1p USB3_RX2p Green On 1Gbps data rate USB3_TX1n USB3_TX2n 100M&10Mbps data rate USB3_TX1p USB3_TX2p www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 24: Usb3_Lan1 (Usb 3.2 Gen 1 + Gbe Lan Connector)

    TX4- State Description USB3_RX1n USB3_RX2n Orange On 1Gbps data rate USB3_RX1p USB3_RX2p Green On 100Mbps data rate USB3_TX1n USB3_TX2n 10Mbps data rate USB3_TX1p USB3_TX2p www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 25: Dp (Display Port Connector)

    DP (Display Port Connector) DP Connector Pin No. Definition Pin No. Definition TX0p TX3n TX0n TX1p AUXp TX1n TX2p AUXn Hot Plug Detect TX2n 3.3V TX3p 3.3V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 26: Hdmi_12 (Hdmi Connector)

    2.2.5 HDMI_12 (HDMI Connector) HDMI Connector Pin No. Definition Pin No. Definition TX2p CLKn TX2n TX1p TX1n TX0p Hot Plug TX0n Detect CLKp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 27: Vga (Vga Port)

    2.2.6 VGA (VGA Port) D-sub Connector Pin No. Definition Pin No. Definition Green Blue DDCSDA 15 11 HSYNC VSYNC DDCSCL www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 28: Com1 (Com1 Port (Rs-232/422/485 & Ri/5V/12V))

    Serial Port Connector RS-422 RS-485 Pin No. RS-232 Full Duplex Half Duplex TXD- TXD+ RXD+ — RXD- — — — — — — — — — www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 29: Jcom1 (Ri Pin Ri/5V/12V Select Jumper For Com1 Port)

    HORNGTONG Connector type JCOM1 Jumper 2x3pin header, pitch 2.54mm 1-2 Close: 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 30: P12V_Cpu (8-Pin Atx 12V Power Connector (For Cpu))

    CPU)) PIN 1 ATX 12V Connector Connector PN Vendor 740-96-085B61 PINREX Connector type 2x4pin header, pitch 4.2mm Pin No. Definition +12V +12V +12V +12V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 31: Cpu_Fan (Cpu Fan Connector)

    2.2.10 CPU_FAN (CPU Fan connector) PIN 1 CPU FAN Connector Connector PN Vendor 744-81-045W11 PINREX Connector type 1x4pin header, pitch 2.54mm Pin No. Definition Detect Speed Control www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 32: Dimm_A1, Dimm_A2, Dimm_B1, Dimm_B2

    2.2.11 DIMM_A1, DIMM_A2, DIMM_B1, DIMM_B2 (DDR4 DIMM Sockets) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 33: Atx (24-Pin Atx Main Power Connector)

    Vendor 740-96-245B70 PINREX Connector type 2x12pin header, pitch 4.2mm Pin No. Definition Pin No. Definition 3.3V 3.3V 3.3V -12V PS_ON Power Good 5VSB 3.3V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 34: Sata2, Sata3, Sata4, Sata5, Sata6, Sata7 (Sata 6Gb/S Connector)

    2.2.13 SATA2, SATA3, SATA4, SATA5, SATA6, SATA7 (SATA 6Gb/s Connector) SATA 6Gb/s Connector Connector PN Vendor WATM-07ABNB2BAUW3 WINWIN SATA2 SATA4 SATA6 770-83-07SW19 PINREX SATA3 SATA5 SATA7 Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 35: F_Panel (Front Panel Header)

    2x5pin header, pitch 2.54mm Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power button+ Reset button Power button- No connect No pin www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 36: Case_Open (Chassis Open Intrusion Alert Header)

    PIN 1 chassis open intrusion alert header Connector PN Vendor 210-91-02GBK2 PINREX PH02R23BAZE11 HORNGTONG Connector type 1x2pin header, pitch 2.54mm Pin No. Definition Detect www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 37: Sys_Fan (System Fan Connector)

    2.2.16 SYS_FAN (System Fan connector) PIN 1 System FAN Connector Connector PN Vendor 744-81-045R11 PINREX Connector type 1x4pin header, pitch 2.54mm Pin No. Definition Detect Speed Control www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 38: Fusb30 (Usb 3.2 Gen 1 Header)

    TX2p TX2n RX2p RX2n Pin No. Definition RX1n Connector PN Vendor RX1p 52X-80-20GU65 PINREX TX1n WUIR-19A9N4BU3W WINWIN TX1p Connector type 2x10pin header, pitch 2.0mm www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 39: Clr_Cmos (Clear Cmos Jumper)

    Connector type Pin No. Definition 1x3pin header, pitch 2.54mm Clear CMOS No Connect 1-2 Close: Clear CMOS data (Default setting) 2-3 Close: Normal Operator www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 40: Fusb2_1, Fusb2_2, Fusb2_3 (Usb 2.0 Header)

    PIN 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Connector type 2x5pin header, pitch 2.54mm Pin No. Definition No Pin No Connect www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 41: Tpm (Tpm Header)

    TPM module connector Connector PN Vendor 52M-90-14GBE7 PINREX LCB25-I1424S01C-12 LIONCONN Connector type Pin No. Definition 2x7pin header, pitch 2.0mm Clock 3.3V Reset 3.3V IRQ_SERIAL SDIN www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 42: M2M (M.2 Slot, 2242/2280 M-Key)

    SUSCLK SATA2 RXp Detect 3.3V 3.3V SATA2 TXn 3.3V SATA2 TXp SATA1 RXn Connector PN Vendor SATA1 RXp 80159-8521 BELLWETHER APCI0096-P002A LOTES SATA1 TXn www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 43: M2E (M.2 Slot, 2230 E-Key)

    PCIE wake up BT_Disable 3.3V WLAN_Disable 3.3V 3.3V Connector PN Vendor Pin No. Definition Pin No. Definition 2E0BC21-S85BE-7H FOXCONN 80152-8521 BELLWETHER PCIE_TXp APCI0095-P002A LOTES PCIE_TXn CL_Reset www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 44: Com2, Com3, Com4 (Serial Port Header (Rs-232))

    2.2.23 COM2, COM3, COM4 (Serial Port header (RS-232)) PIN 1 Serial port Header Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Connector type 2x5pin header, pitch 2.0mm Pin No. Definition No Connect www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 45: Gpio_Cnt (General Purpose Input/Output Header)

    PINREX A2004WV-2X06P46 JOINT-TECH Connector type 2x6pin header, pitch 2.0mm Pin No. Definition GPIO-output_1 GPIO-input_1 GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock SMBus DATA www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 46: F_Audio (Front Panel Audio Header)

    Front panel audio header Connector PN Vendor 210-92-05GE05 PINREX Connector type 2x5pin header, pitch 2.54mm Pin No. Definition MIC_LEFT MIC_RIGHT Detect LINE_RIGHT JACKSENSE Detect No connect LINE_LEFT www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 47: Pciex4 (Pcie X4 (Gen3 X4) Slot)

    2.2.26 PCIEX4 (PCIe x4 (Gen3 x4) Slot) PCIe x4 connector Connector PN Vendor WPES- WINWIN 064AN41B22UWS 2EG03211-D2D-DF FOXCONN www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 48: Pciex16_A, Pciex16_B (Pcie X16 (Gen4 X16) Slot)

    2.2.27 PCIEX16_A, PCIEX16_B (PCIe x16 (Gen4 x16) Slot) PCIe x16 connector Connector PN Vendor 10144667-123Z0LF www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 49: Pciex1 (Pcie X1 (Gen3 X1) Slot)

    2.2.28 PCIEX1 (PCIe x1 (Gen3 x1) Slot) PCIe x1 connector Connector PN Vendor WPES- WINWIN 036AN41B22UWS 2EG01811-D7D-DF FOXCONN www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 50: At_Cn (At/Atx Mode Select Jumper)

    1x3pin header, pitch 2.0mm Pin No. Definition AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 51: Bkl_Cn (Backlight Control Header)

    Backlight control header Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Connector type 1x5pin header, pitch 2.0mm Pin No. Definition 5V (option 12V) Backlight Enable www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 52: Lvds (Lvds Connector)

    Note: *The LVDS output connector of the unit is only intended to be connected to an UL/IEC/EN CLK2+ approval equipment with fire enclosure. CLK1+ CLK2- www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 53: Chapter 3 - Bios

    Chapter 3 Chapter 3 – BIOS www.gigaipc.com...

  • Page 54: Introduction

    Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com...

  • Page 55: The Main Menu

    ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com...

  • Page 56: Advanced

    The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. Advanced menu items for 12th CPU Advanced menu items for 13th CPU www.gigaipc.com...

  • Page 57: Amt Configuration

    Discrete LAN. Trigger CIRA boot Activate Remote Disabled : Disables TPM feature (Default setting) Assistance Process Enabled : Enables TPM feature To Un-configure ME without password. Unconfigure ME Disabled : Disables Unconfigure ME (Default settings) Enabled : Enables Unconfigure ME www.gigaipc.com...
  • Page 58 Disabled : Disables watchdog Timer (Default setting) Enabled : Enables watchdog Timer OS Timer Sets OS Watchdog Timer. BIOS Timer Sets BIOS Timer. Disabled : Disables ASF Sensors Table (Default setting) ASF Sensors Table Enabled : Enables ASF Sensors Table www.gigaipc.com...
  • Page 59 Secure Erase Simulated : Performs SE flow without erasing SSD (Default setting) mode Real : Erase SSD Force Secure Erase on next boot. Force Secure Disabled : Disables Force Secure Erase (Default setting) Erase Enabled : Enables Force Secure Erase www.gigaipc.com...
  • Page 60 Disabled : Disables One Click Recovery Windows recovery boot. Allows CSME to request Secureboot to be disabled for One Click Recovery. OCR Disable Secure Enabled : Enables One Click Recovery disable Secure Boot function. Boot (Default setting) Disabled : Disables One Click Recovery disable Secure Boot function. www.gigaipc.com...
  • Page 61 Disabled : Disables remote platform erase feature. Platform Erase Enabled : Enables remote platform erase feature. (Default setting) Feature Change RPE SSD Erase Action behavior Simulated : performs RPE SSD Erase flow without erasing SSD. SSD Erase Mode (Default setting) Real : Erase SSD. www.gigaipc.com...

  • Page 62: Tpm Configuration

    3.3.2 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM (Default setting) TPM Device dTPM : External TPM (When using External TPM module or having Selection TPM chip on MB) www.gigaipc.com...
  • Page 63 Item Description Security Device Enabled : Enables TPM feature (Default setting) Support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...

  • Page 64: Cpu Configuration

    Enabled : Enables CPU C states function (Default setting) Disabled : Disables CPU C states function To optimize CPU performance. Dual Tau Boost Enabled : Enables Dual Tau Boost function Disabled : Disables Dual Tau Boost function (Default setting) www.gigaipc.com...

  • Page 65: Sata Configuration

    SATA HDD/SSD information Serial ATA Port 4 shows SATA HDD/SSD information Serial ATA Port 5 shows SATA HDD/SSD information Serial ATA Port 6 shows SATA HDD/SSD information Serial ATA Port 7 / shows SATA HDD/SSD information or M.2 SSD information www.gigaipc.com...

  • Page 66: It8786 Super Io Configuration

    Enabled : Enables allows you to configure the serial port settings Configuration Disabled : if Disabled, displays no configuration for the serial port Serial Port 4 Configuration Device settings : Display the specified Serial Port base I/O address and IRQ www.gigaipc.com...

  • Page 67: Hardware Monitor

    Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature CPU Fan Speed Shows current CPU fan Speed SYS Fan Speed Shows current System fan Speed www.gigaipc.com...

  • Page 68: S5 Rtc Wake Settings

    Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com...

  • Page 69: Ami Graphic Output Protocol Policy

    3.3.9 AMI Graphic Output Protocol Policy Item Description Choose default monitor output when there are more than one monitor Output Select plugged on the motherboard. www.gigaipc.com...

  • Page 70: Network Stack Configuration

    Disabled : Disables IPv6 HTTP Support Enabled : Enables IPv6 HTTP Support PXE boot wait time Wait time in seconds, or use ESC key to abort the PXE boot. Media detect count Number of times the presence of media will be checked. www.gigaipc.com...

  • Page 71: Nvme Configuration

    3.3.11 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com...

  • Page 72: Offboard Sata Controller Configuration

    3.3.12 Offboard SATA Controller Configuration www.gigaipc.com...

  • Page 73: Digital Io Port Configuration

    Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com...

  • Page 74: Intel(R) Platform Service Record

    USE the <↑> and <↓> keys to choose a USB device option, the <Enter> Export Platform key to select a USB device option to export data. Service Record To NOTE : Export file name is "PlatformServiceRecord_YYYY-MM-DD HH- MM-SS.bin" Only support UEFI File system format. www.gigaipc.com...

  • Page 75: Tls Auth Configuration

    Press [Enter] to configure advanced items : Server CA Configuration : Enroll Cert : 1. Enroll Cert Using File Enroll Cert 2. Cert GUID : Input digit character in 11111111-2222-3333-4444-1234567 890ab format. 3. Commit Changes and Exit 4. Discard Changes and Exit www.gigaipc.com...

  • Page 76: Chipset

    Auto : Detects display device automatically (Default setting) Internal Graphics Enabled : Enables onboard graphics Disabled : Disables onboard graphics Enable/Disable onboard LAN controller Onboard LAN1 Enabled : Enables onboard LAN controller (Default setting) Onboard LAN2 Disabled : Disables onboard LAN controller www.gigaipc.com...
  • Page 77 Disabled : Disables Warning message (Default setting) Warning Enabled : Enables Warning message Clear : Clear the chassis intrusion status record Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com...

  • Page 78: Security

    To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 79 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without Key Management full authentication Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 80 ’Mi c r o s of t UEFI C A’ MS UEFI CA Key Copy NVRAM content of Certificate in Export Secure Boot Secure Boot variables to Authorized Signature variables files in a root folder on a database(db) file system device www.gigaipc.com...

  • Page 81: Boot

    Enable/Disable Built-in EFI Shell Built-in EFI Shell Enabled : Enables Built-in EFI Shell Disabled : Disables Built-in EFI Shell (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com...

  • Page 82: Save & Exit

    Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...

  • Page 83: Mebx

    MEBx Item Description Intel(R) ME For MEBx Login Password www.gigaipc.com...
