Select Advanced Function and press the OK button.
3.
Select Enter Password and press the OK button.
4.
Do one of the following:
5.
To set a numeric character, press the up arrow navigation
•
button to select a number and press the OK button.
To set an uppercase letter, press the down arrow navigation
•
button to select a letter and press the OK button.
When you're done selecting the characters in your password,
6.
press the OK button.
Press the ESC button until you have exited the Log Manager
7.
menu to return to the Erase mode menu.

Printing a Receipt

You can use SDOCK1EU3P2 with a serial printer to print an erase
record with details of the process, including the date and time
that the drive was erased, the erase mode used, and more. The
receipt also includes an area for a signature.
Note: The RS232 serial-based printer port uses 9600 baud.
Use the RS232 serial-based printer port to connect a serial
1.
printer to the eraser.
Configure the connected serial printer to work on 9600
2.
baud. Consult the documentation that came with the serial
printer for more information about how to configure it.
When a process is complete, a receipt automatically prints
3.
on the connected serial printer.
