Docking station for two laptops

Advertisement

Quick Links

Docking station for two laptops
USB3DDOCKFT
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.startech.com/USB3DDOCKFT
Manual Revision: 11/06/2015
*actual product may vary from photos

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8STUSB3DDOCKFT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for StarTech.com 8STUSB3DDOCKFT

  • Page 1 Docking station for two laptops USB3DDOCKFT *actual product may vary from photos DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the latest information, technical specifications, and support for this product, please visit www.startech.com/USB3DDOCKFT...
  • Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
  • Page 3: Table Of Contents

    Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Product diagram ..................3 Front view ..............................3 Rear view ..............................3 About USB 3.0 and USB 3.1 ..............4 About installation ..................4 Install the driver ............................4 Install the hardware..........................4 Switch which host to control ........................
  • Page 4: Introduction

    Introduction Packaging Contents • 1x laptop docking station • 2x USB 3.0 host cables • 1x universal power adapter (NA/EU/UK/AU) • 1x instruction manual System Requirements The docking station requires the following: • One or two USB-enabled host computer system(s) with an available USB 3.0 port on each host •...
  • Page 5 • Windows XP SP2 or SP3 (32-bit and 64-bit) • Windows Vista Note: In Windows 8.1, Microsoft® removed support for cables from the Windows Easy Transfer software. Operating system requirements are subject to change. For the latest requirements, please visit www.startech.com/USB3DDOCKFT Instruction Manual...
  • Page 6: Product Diagram

    Product diagram Front view Switch host button 3.5mm TRRS headset port (audio and microphone) USB 3.0 fast-charge and sync port Rear view Power USB 3.0 USB 3.0 HDMI RJ45 host ports port switch ports port DC input DisplayPort Security port lock port Instruction Manual...
  • Page 7: About Usb 3.0 And Usb 3.1

    If you receive a prompt to automatically install the driver, complete the on-screen instructions to complete the installation. Install the driver 1. On the first host laptop, use a web browser to navigate to http://www.startech.com/ USB3DDOCKFT. 2. Click the Support tab.
  • Page 8: Switch Which Host To Control

    6. As necessary, connect any other devices to the docking station, including an RJ45 network connection, USB peripherals, a headset, speakers, or microphones. Switch which host to control 1. Ensure that both host laptops are connected to the docking station’s two USB 3.0 host ports.
  • Page 9: Configure A Display Device

    2. Connect the iPad to the USB 3.0 port located on the side of the docking station. Note: If you connect a host laptop (whether it be one or two host laptops) to the docking station while you’re charging a first-generation iPad, the iPad will switch to data sync mode and stop charging.
  • Page 10: Use Mac Os To Configure A Display Device

    Select this option to specify the physical location of the display that’s connected to the docking station in relation to the system’s primary monitor. Screen Resolution Select this option to change the resolution on the display that’s connected to the docking station.
  • Page 11: Supported Video Resolutions

    Supported video resolutions The docking station supports approximately 4K video resolutions total, across both the DisplayPort and HDMI ports. 4K (3840x2160) resolutions can be achieved when a single DisplayPort display is connected to the docking station. The connected display must offer 4K support in order to achieve 4K resolutions.
  • Page 12: Use Windows Easy Transfer To Migrate Settings And Transfer Files

    PCLinq software will appear as a removable drive once a host laptop is connected to the docking station. To use the file transfer functionality, the software must be installed on each connected host laptop. 1. Ensure two laptops are connected to the “HOST” ports on the docking station. Once connected, browse to the location of the “PCLINQ”...
  • Page 13: Technical Support

    Limitation of liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
  • Page 14 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
