INSTALLATION INSTRUCTIONS
VOLT
Low Voltage Landscape Lighting
®
VOLT
G2 Arch Brass Path & Area Light
®
VPL-1048-4-BBZ
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2021, VOLT
customersupport@voltlighting.com • 813.978.3700
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Volt VPL-1048-4-BBZ
Summary of Contents for Volt VPL-1048-4-BBZ
- Page 1 VPL-1048-4-BBZ Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2021, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700 - 1 -...
- Page 2 INSTALLATION INSTRUCTIONS G2 Arch Brass Path & Area Light VPL-1048-4-BBZ Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Package Contents A. (1) Fixture Body Parts Required A. (1) Mounting Accessory B. (1) GU4 Bi-Pin Product Dimensions 11.81” 3.39” 5.44” 24.43” customersupport@voltlighting.com • 813.978.3700 - 3 -...
- Page 4 INSTALLATION INSTRUCTIONS G2 Arch Brass Path & Area Light VPL-1048-4-BBZ Remove Lens Loosen the lens and remove it Fixture Body from the fixture body. Lens Install Bulb Insert the bulb with the correct Socket wattage and type marked on the fixture label and push into place.
- Page 5 Install Stake Determine the desired location Board for mounting the stake mount. Hammer the stake into the ground until flange of stake is flush to grade. To avoid damage to the stake, place a board on top of the stake while Stake hammering.
- Page 6 INSTALLATION INSTRUCTIONS G2 Arch Brass Path & Area Light VPL-1048-4-BBZ Wire Connections Fixture Wires Wire Connectors Main Supply Cable Strip both leads from the fixture wires. Using two UL listed wire connectors (sold separately), connect the leads from the fixture wires to the main supply cable leads.
- Page 7 Install/Replace Bulb Reverse Step 2 - Step 3 to expose the bulb and replace it with the correct wattage and type marked on the fixture label. Then, reinstall the lens. IMPORTANT: The bulb must be protected from moisture and dust at all times.
