Volt VPL-1002 Series Installation Instructions Manual

Low voltage landscape lighting, elegant harp led path/area light
Hide thumbs
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION INSTRUCTIONS
VOLT
®
Elegant Harp LED Path/Area Light
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2016, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
customersupport@voltlighting.com • 813.978.3700
Low Voltage Landscape Lighting

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPL-1002 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Volt VPL-1002 Series

Summary of Contents for Volt VPL-1002 Series

  • Page 1 Elegant Harp LED Path/Area Light Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2016, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved. customersupport@voltlighting.com • 813.978.3700...
  • Page 2 INSTALLATION INSTRUCTIONS VOLT Elegant Harp LED Path/Area Light ® VPL-1002 Series Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
  • Page 3 Package Contents A. (1) Luminaire B. (1) Stake Parts Required A. (1) Lamp (Sold Separately) Product Dimensions 10” 8” 2” 26” Install Stake Determine desired location for mounting luminaire. Hammer stake into ground until Board flange of stake is flush to grade. To avoid damage to stake, place a board on top of stake while hammering.
  • Page 4 INSTALLATION INSTRUCTIONS VOLT Elegant Harp LED Path/Area Light ® VPL-1002 Series Install Luminaire to Stake Clear away area in ground at wireway Luminaire slot in top of stake. Align the wireway slots on base and stake. Lay luminaire pigtail into wireway slots and thread...
  • Page 5 Remove Diffuser Remove screws from diffuser to Shade expose the socket. Diffuser Screw Install Lamp Insert lamp with correct wattage Socket and type marked on luminaire label. CAUTION: Do not exceed maximum wattage marked on luminaire label. Lamp NOTE: DO NOT touch lamp with bare hands.
  • Page 6 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2016, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
