INSTALLATION INSTRUCTIONS
VOLT
®
Cypress Bollard
VPL-1042-4-BBZ
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2019, VOLT
customersupport@voltlighting.com • 813.978.3700
Low Voltage Landscape Lighting
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Volt VPL-1042-4-BBZ
Summary of Contents for Volt VPL-1042-4-BBZ
- Page 1 VPL-1042-4-BBZ Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2019, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700 - 1 -...
-
Page 2: Important Safety Instructions
INSTALLATION INSTRUCTIONS VOLT Cypress Bollard ® VPL-1042-4-BBZ Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. - Page 3 Package Contents A. (1) Fixture Body C. (1) Hat B. (1) Coupler D. (1) Finial Product Dimensions 6.45” 22.4” 5.9” customersupport@voltlighting.com • 813.978.3700 - 3 -...
- Page 4 INSTALLATION INSTRUCTIONS VOLT Cypress Bollard ® VPL-1042-4-BBZ Install Fixture Hat Screw the coupler onto the top Finial center of the fixture body and hand tighten until snug. Secure the fixture hat onto the Fixture Hat coupler with the finial and hand tighten until snug.
- Page 5 Install Fixture Body to Stake Pass the fixture wire through the center hole of the stake. Thread the fixture body onto the stake and hand tighten until snug. Fixture Body Fixture Wire Ground Stake Soil customersupport@voltlighting.com • 813.978.3700 - 5 -...
- Page 6 INSTALLATION INSTRUCTIONS VOLT Cypress Bollard ® VPL-1042-4-BBZ Wire Connections Supply Wire from Fixture Body Pigtail Wire Connectors Main Supply Cable Strip both leads from the fixture body. Using two wire connectors (sold separately) connect the leads from the fixture body to the main supply cable leads.
- Page 7 customersupport@voltlighting.com • 813.978.3700 - 7 -...
- Page 8 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2019, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
