INSTALLATION INSTRUCTIONS
VOLT
Low Voltage Landscape Lighting
®
VOLT
Traditional Lantern Brass Path & Area Light
®
VPL-1047-4-BBZ
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2021, VOLT
customersupport@voltlighting.com • 813.978.3700
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -
Advertisement
Table of Contents
Related Manuals for Volt VPL-1047-4-BBZ
Summary of Contents for Volt VPL-1047-4-BBZ
- Page 1 VPL-1047-4-BBZ Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2021, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700 - 1 -...
- Page 2 INSTALLATION INSTRUCTIONS VOLT Traditional Lantern Brass Path & Area Light ® VPL-1047-4-BBZ Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Package Contents A. (1) Fixture Body Parts Required A. (1) Mounting Accessories C. (1) SCB Lamp (sold separately) B. (1) Flame Lamp Product Dimensions 10.75” 8” 6” 25” customersupport@voltlighting.com • 813.978.3700 - 3 -...
- Page 4 INSTALLATION INSTRUCTIONS VOLT Traditional Lantern Brass Path & Area Light ® VPL-1047-4-BBZ Remove Hat Bottom Remove the bottom of the hat, by using a screwdriver to loosen the screws. Hat Top Screws Hat Bottom Install Flame Lamp Flame Lamp Install the flame lamp by aligning the line on the bottom of the lamp to the holes in the socket.
- Page 5 Reinstall Hat Bottom Reinstall the hat bottom using the previously removed screws. Use a screwdriver to make sure the screws are secure. Hat Top Screw Hat Bottom Remove Lens Remove the lens on the bottom of the hat by loosening the screws using a screwdriver.
- Page 6 INSTALLATION INSTRUCTIONS VOLT Traditional Lantern Brass Path & Area Light ® VPL-1047-4-BBZ Reinstall Lens Place the lens back onto the bottom of the hat and use the previously removed screws to secure. Tighten with a screwdriver. Lens Screw Install Stake...
- Page 7 Install Fixture to Stake Pass supply wires through the open slot of the stake Stem and thread the fixture onto the stake. Hand tighten until Supply Wires snug. Clear away area in ground and lay the supply Ground wires into wireway slot. Stake Soil Wire Connections...
- Page 8 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2021, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
