Table 1: Checklist Of Items — Continued
Item
EIA/TIA-574 Serial
Port Cable
Headset (optional)
Handset (optional)
Headset Adapter
Cord
Mounting Strips

Installation Procedures

The CALLMASTER VI voice terminal comes with two mounting strips
that you can use to mount the unit to the desktop, the side of the
monitor, or the wall in your work area. The installation procedures are
the same no matter where you mount the unit.
To mount the strips, do the following steps:
1. Turn the CALLMASTER VI voice terminal over.
2. Remove the backing from one side of the mounting strips.
3. Stick the mounting strips in the indentations on the top and the
bottom on the back of the CALLMASTER VI voice terminal.
4. Remove the remaining backing from the mounting strips.
5. Fasten the CALLMASTER VI voice terminal to the wall, desktop,
or other area.
Description
9-pin, male/female cable
Note: Lucent supports only
Lucent headsets. For headsets
compatible with the
CALLMASTER VI, see
"Connecting the Headset" later in
this chapter.
Handset with custom cable
provided as a D-Kit.
4-pin cord that connects the
phone to the headset.
A kit containing two strips of
fastening tape.
4
