INSTALLATION and OPERATION MANUAL
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notification.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
BARNES
BARNES
Submersible Sewage Ejector
®
Series: 3SE-DS, 1.5 & 2HP
1750RPM, 60Hz
(Double Seal)
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
Form No. 088889-Rev. R
Advertisement
Table of Contents
Related Manuals for Barnes 3SE-DS Series
Summary of Contents for Barnes 3SE-DS Series
- Page 1 BARNES BARNES ® INSTALLATION and OPERATION MANUAL Submersible Sewage Ejector Series: 3SE-DS, 1.5 & 2HP 1750RPM, 60Hz (Double Seal) IMPORTANT! Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur.
-
Page 2: Table Of Contents
PRESSURE GAUGE KIT (see parts list) Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc 1994, 2002, 3/06, 6/06, 9/06 Alteration Rights Reserved... -
Page 3: Safety First
SAFETY FIRST! Please Read This Before Installing Or Operating Pump. This information is provided for SAFETY and to PREVENT Do not block or restrict discharge hose, as discharge EQUIPMENT PROBLEMS. To help recognize this information, hose may whip under pressure. observe the following symbols: IMPORTANT! Warns about hazards that can result WARNING! - DO NOT wear loose clothing that may... -
Page 4: Pump Specifications
SECTION: A - PUMP SPECIFICATIONS: DISCHARGE ....3” NPT, Vertical UPPER BEARING: LIQUID TEMPERATURE . 104°F (40°C) Continuous Design ..Single Row, Ball, Oil Lubricated MOTOR HOUSING ..Cast Iron ASTM A-48, Class 30 Load ..... Radial VOLUTE ......Cast Iron ASTM A-48, Class 30 LOWER BEARING: SEAL PLATE .... -
Page 5: General Information
B-4) Service Centers: secure the guide rails in the upper mounting brackets and For the location of the nearest Barnes service center, check locate the base on the bottom of the wet well. Level the base your Barnes representative or Crane Pumps & Systems, Inc., with grout and/or shims. -
Page 6: Start-Up Operation
OR RUN IF AN OVERLOAD CONDITION OCCURS ! this sheet is to be completed as applicable. Return one copy to Barnes and store the second in the control panel or with NOTE: Single phase pumps can be orederd with an the pump manual if no control panel is used. -
Page 7: Electrical Data
As the motor is oil filled, no lubrication or other maintenance below 15 KV. breakdown), the the pump must be is required, and generally Barnes Pumps will give very carefully inspected for leaks at the shaft seals (31), reliable service and can be expected to operate for years on cable assemblies (30) and (32), and hex nut (16), normal sewage pumping without failing. - Page 8 If found to be defective contact a motor service station or Barnes Pumps service department. Check rotor for wear. If REMOVE PLUG rotor or the stator windings are defective, the complete motor must be replaced.
- Page 9 Motor - Slide lower bearing (6) and motor (20) squarely into the seal plate (1) until bearing seats on the bottom. Torque motor bolts to 17 inch pounds. Make wire connections per paragraph CONNECTORS F-3.3. Set square ring (8) in groove on seal plate (1), lower motor housing (5) down onto seal plate (1) while aligning holes.
- Page 10 Power Cable (30A) Power Cable (32A) Gland Nut (30B) Hex Nut (16) Gland Nut (32B) Friction Ring (30C) Grommet (30D) Friction Ring (32C) Friction Ring (30C) Grommet (32D) Friction Ring (32C) FIGURE 4 F-3.4) Cable Assemblies: INNER SEAL- To expose inner shaft seal (31) for examination, Power Cable - Refill with cooling oil (if it has been drained) as remove outer seal as outlined above.
-
Page 11: Replacement Parts
SECTION: G REPLACEMENT PARTS Stationary Member (31A) G-1 ORDERING REPLACEMENT PARTS: Polished Face Out When ordering replacement parts, ALWAYS furnish the following information: 1. Pump serial number and date code. (Paragraph G-4) 2. Pump model number. (Paragraph G-3) 3. Pump part number. (Paragraph G-2) Seal Plate (1) 4. -
Page 12: Trouble Shooting
TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”... -
Page 13: Cross-Section (Fig. 8)
FIGURE 8... -
Page 14: Exploded View (Fig. 9)
FIGURE 9... -
Page 15: Parts List
PARTS KITS Seal Repair Kits Double Seal ..P/N - 130177 (†) 8, 10, 31 Service Kits Double Seal ..P/N - 130173 (♦) 2, 3, 6, 8, 10, 23, 31, 40, 41, 42, 53 Tools: Seal Pusher... P/N- TL-21360 Bullet .... - Page 16 066072 Grommet (single phase) 051452 Grommet (three phase) 067562 †♦ Shaft Seal, Inner Carbon/Ceramic/Buna-N (STD) 067562SB Tungsten/Tugsten/Buna-N 067562SD Silicon/Silicon/Buna-N 067562SF Carbon/Ceramic/Viton 067562SH Tungsten/Tugsten/Viton 067562SK Silicon/Silicon/Viton 067562 Shaft Seal, Outer Carbon/Ceramic/Buna-N (STD) 067562SB Tungsten/Tugsten/Buna-N 067562SD Silicon/Silicon/Buna-N 067562SF Carbon/Ceramic/Viton 067562SH Tungsten/Tugsten/Viton 067562SK Silicon/Silicon/Viton See Table 2 Control Cable Set...
-
Page 17: Returned Goods Policy
IMPORTANT! IMPORTANT! WARRANTY REGISTRATION WARRANTY REGISTRATION Your product is covered by the enclosed Warranty. Your product is covered by a warranty: www.cranepumps.com/downloadables/CATALOGS_OIPMs/Warranty/24MonthWarranty.pdf If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. If you have a claim under the provisions of the warranty, contact your local Crane Pumps &...
