2.0 INSTALLATION
2.1 Default PIN code: 0000

2.2 Front panel/underside

NOTE:
1. Power indicator /remote sensor
2. Speakers
3. Buttons: Input source, Menu, V-/V+, CH-/CH+, Standby/ON.
4. Power switch ON/OFF

2.3 Rear panel

NOTE:
1. SAT IN
2. ANT/CABLE IN
3. CI+
4. AV IN
5. HEADPHONES

2.4 Side panel

NOTE:
1. SCART
2. HDMI 1 (ARC)
3. HDMI 2
4. VGA
5. USB
The graphics are for representation only.
The graphics are for representation only.
Connect a satellite dish to the TV for searching programmes.
Connect a terrestrial antenna or cable connection from your provider to the
TV for searching programmes.
Connect a Conditional Access Module (CAM).
3.5 mm female jack entry for composite video and left/right audio
connection.
Speakers will be muted when earphone is plugged in and headphone
selected.
The graphics are for representation only.
Connect devices like DVD or VCR using SCART cable
Connect HDMI input signal from a signal source such as DVD, Blu-ray player
or game console or directly to a Digital Amplifier that supports the ARC
function. This input is equipped with the ARC (Audio Return Channel) feature
to implement audio connections and for a full Dolby audio support.
Connect HDMI input signal from a signal source such as DVD, Blu-ray player or
game console.
Connect a VGA source computers may have
Connect a USB device for playback of multimedia files
Fig. 2
Fig. 3a
Fig. 3b
