LED TV with DVB-T2/C/S2
SRT40FC4003
User Manual
Bedienungsanleitung
Manuel utilisateur
Manuale utente
Manual do Utilizador
Инструкции за употреба
Руководство пользователя
Посібник користувача
Användar Manual
Uživatelská příručka
Navodila za uporabo
Korisnički priručnik
Uputsvo za rukovanje
Používateľská príručka
Használati útmutató
Käyttöohje
Brukermanual
Manual del Usuario
Gebruiksaanwijzing
Brugervejledning
Manual de Utilizare
Instrukcja obsługi
Advertisement
Table of Contents
Related Manuals for Strong SRT40FC4003
Summary of Contents for Strong SRT40FC4003
- Page 1 LED TV with DVB-T2/C/S2 SRT40FC4003 User Manual Korisnički priručnik Bedienungsanleitung Uputsvo za rukovanje Manuel utilisateur Používateľská príručka Manuale utente Használati útmutató Manual do Utilizador Käyttöohje Инструкции за употреба Brukermanual Руководство пользователя Manual del Usuario Посібник користувача Gebruiksaanwijzing Användar Manual Brugervejledning Uživatelská...
- Page 2 Fig. 1a Fig. 1b Fig. 1c Fig. 2...
- Page 3 Fig. 3a HEADPHONES SAT IN ANT/CABLE IN AV IN Fig. 3b SCART HDMI 1 (ARC) HDMI 2 S/PDIF (coax.) Fig. 4 Fig. 5 Fig. 6 Pause Prev. Next Stop Repeat All Set A Playlist Info. Aspect Ratio Fig. 7 Pause Prev.
- Page 4 Supplied by STRONG Austria Represented by STRONG Ges.m.b.H. Franz-Josefs-Kai 1 1010 Vienna, Austria Email: support_fr@strong.tv 28 Jan 2020 14:59...
- Page 5 THE LIMITED AUTHORITY TO USE AS NOTED ABOVE. SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, STRONG declares that the radio equipment SRT 32HB4003, SRT 40FB4003 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.strong.tv/en/doc Subject to alterations.
-
Page 6: Table Of Contents
To obtain the best performance and safety, please read this manual carefully. Please keep this manual for future reference. TABLE OF CONTENTS 1.0 INSTRUCTION 1.1 Safety Instructions 1.2 Storage 1.3 Accessories 1.4 Equipment set-up 2.0 INSTALLATION 2.1 Default PIN code: 0000 2.2 Front panel/underside 2.3 Rear panel 2.4 Side panel... -
Page 7: Instruction
1.0 INSTRUCTION 1.1 Safety Instructions Read all of the instructions before operating the set. Keep these instructions well for later use. Only use attachments/accessories specified or provided by the manufacturer (such as the „ „ exclusive supply adapter, battery etc.). Please refer to the information on the exterior back enclosure for electrical and safety „... -
Page 8: Storage
WEEE Directive Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. -
Page 9: Installation 2.1 Default Pin Code: 0000
2.0 INSTALLATION 2.1 Default PIN code: 0000 2.2 Front panel/underside Fig. 2 NOTE: The graphics are for representation only. 1. Power indicator /remote sensor 2. Speakers 3. Buttons: Input source, Menu, V-/V+, CH-/CH+, Standby/ON. 4. Power switch ON/OFF 2.3 Rear panel NOTE: The graphics are for representation only. -
Page 10: Remote Control
6. S/PDIF (coax. output) Use an RCA cable to connect your TV to a compatible digital amplifier or Home theatre set. 2.5 Remote control Fig. 4 1. ! Press to mute or restore the volume. 2. q Press to turn the TV on or standby. 3. -
Page 11: Installing The Batteries
Do not place the remote control under direct sunlight which will cause deformation of the unit „ „ by heat. When the remote sensor is under direct sunlight or strong lighting, the remote control will not „ „ work. If so, please change the lighting or TV's position, or operate the remote control closer to the remote sensor. -
Page 12: Dvb-S/S2 Installation
Scan type Select which input source you want to use: DVB-S to receive satellite broadcasts (and if you are equipped with a satellite dish), DVB-T to receive terrestrial broadcasts or DVB-C to receive cable broadcasts. 3.1 DVB-S/S2 installation Satellite Setting First select the region where you are using the TV. -
Page 13: Electronic Programme Guide (Epg)
NOTE: Please check the settings for your cable system used by your provider! Press OK to continue. Crypted Select FTA Channels to search Free-To-Air channels only or All Channels to search FTA and encrypted channels Press pq t u to highlight the country that you want to install, then press OK to start searching. 4.0 ELECTRONIC PROGRAMME GUIDE (EPG) EPG stands for Digital Electronic Programme Guide. -
Page 14: Sound Menu
Colour Adjust the saturation of the colour based on your own preference. Tint No function Sharpness Adjust the peaking in the detail of the picture. 5.2.2 Colour Temperature In this menu you can change the overall colour cast of the picture. Press pq to select Colour Temperature, then press OK to enter a sub-menu. - Page 15 Press OK to adjust. After finish your adjustment, press OK to save and return to the previous menu. Below items depend if they are available of select input source. Use INPUT to select another source. 5.4.1 Auto Tuning Press pq to select Auto Tuning, select the Scan Type and proceed with OK. 5.4.2 Dish Setup If you use DVB-S/S2 as input source, the Dish Setup menu allow you to set you satellite and belonging settings as DiSEqC port and LNB type.
-
Page 16: Time Menu
NOTE: To modify the order of the channels contained in the channel list do as follow: press Menu and OK to select Program Edit (it is also possible access this option by pressing PROG button on the remote control). To move a channel, select it by using pq or CH +/- button then press YELLOW button. Now, there are two different ways to move the channel: Enter the number of the new position by using the 0 ~ 9 buttons on the remote control and confirm with OK or YELLOW. -
Page 17: Usb
Some USB storage devices may not be compatible to operate smoothly with this TV. Back up all of the data in the USB storage device in case data is lost due to an unexpected accident. STRONG does not assume any liability for the losses by misuse or malfunction. Data backup is consumer's responsibility. -
Page 18: Usb Menu
This TV may not support some multimedia files changed and upgraded as the change of the encoding format or other technical aspects advances. Please refer to chapter 9. Appendix for a list of supported file formats for USB playback. 6.2 USB menu Press SOURCE and select USB. - Page 19 Repeat Highlight the icon and press OK. You can select 3 different modes: None to disable the function, 1 to repeat one track only and All to repeat the entire list once it is finished. Highlight the icon and press OK to check the information of the playing Information music.
-
Page 20: Troubleshooting
Before calling a service technician, review following information for possible causes and solutions for the problem you are experiencing. If the TV does not work properly after checking it, please contact your local service line or STRONG dealer. Alternatively, you can send a support mail via our website www. strong.tv. - Page 21 Make sure your dish installation is up to standards to minimize rain effects. When in doubt, ask a local satellite specialist for advice. NOTE: If the problem persists after these solutions, please contact your local support centre or send a support mail via our website www.strong.tv.
-
Page 22: Specifications
8.0 SPECIFICATIONS Audio Audio Output: 8 W + 8 W Video Channel coverage: DVB-T2: 174 MHz-230 MHz; 470 MHz-860 MHz DVB-C: 50-858 MHz DVB-S2: 950 MHz-2150 MHz System: DTV: DVB-T2, DVB-S2, DVB-C ATV: PAL/SECAM (BG/DK/1) AV: PAL, NTSC Connectors 1x ANT/CABLE IN 1x SAT IN 1x SCART 1x CI+...
