2.0 INSTALLATION
2.1 Default PIN code: 0000

2.2 Front panel/underside

NOTE:
1. Power indicator /remote sensor
2. Speakers
3. Buttons: Input source, Menu, V-/V+, CH-/CH+, Standby/ON.
4. Power switch ON/OFF

2.3 Rear panel

NOTE:
1. AC INPUT (FIXED CABLE)
2. S/PDIF (coax. output)
3. VIDEO/AUDIO L/R
4. HDMI 3
5. SCART

2.4 Side panel

NOTE:
1. ANT/CABLE IN
2. SAT IN
3. YPbPr
4. CI+
5. HEADPHONE
6. HDMI 1
7. VGA
The graphics are for representation only.
The graphics are for representation only.
Main power cable (100 - 240 V ~ 50/60 Hz)
Use an RCA cable to connect your TV to a compatible digital amplifier or
Home theatre set.
Connect AUDIO and VIDEO input signals from a signal source such as DVD.
Connect HDMI input signal from a signal source such as DVD, Blu-ray player
or game console.
Connect devices like DVD or VCR using SCART cable
The graphics are for representation only.
Connect a terrestrial antenna or cable connection from your provider to the
TV for searching programmes.
Connect a satellite dish to the TV for searching programmes.
Connect YPbPr sources.
Connect a Conditional Access Module (CAM).
Speakers will be muted when earphone is plugged in and headphone
selected.
Connect HDMI input signal from a signal source such as DVD, Blu-ray player
or game console.
Connect a VGA source computers may have
Fig. 2
Fig. 3
Fig. 3
