LED TV with DVB-T2/C/S2
SRT 24HZ4013N
SRT 32HZ4013N
SRT 39HZ4013N
SRT 40FZ4013N
User Manual
Bedienungsanleitung
Manuel utilisateur
Manuale utente
Manual do Utilizador
Инструкции за употреба
Руководство пользователя
Посібник користувача
Användar Manual
Uživatelská příručka
Navodila za uporabo
SRT 24HZ4013NW
SRT 32HZ4013NW
SRT 39HZ4013NW
SRT 40FZ4013NW
Uputsvo za rukovanje
Používateľská príručka
Használati útmutató
Gebruiksaanwijzing
Korisnički priručnik
Käyttöohje
Brukermanual
Manual del Usuario
Brugervejledning
Manual de Utilizare
Instrukcja obsługi
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Strong SRT 244013N
Summary of Contents for Strong SRT 244013N
- Page 1 LED TV with DVB-T2/C/S2 SRT 24HZ4013N SRT 24HZ4013NW SRT 32HZ4013N SRT 32HZ4013NW SRT 39HZ4013N SRT 39HZ4013NW SRT 40FZ4013N SRT 40FZ4013NW User Manual Korisnički priručnik Bedienungsanleitung Uputsvo za rukovanje Manuel utilisateur Používateľská príručka Manuale utente Használati útmutató Manual do Utilizador Käyttöohje Инструкции...
- Page 2 Fig.1 Fig.2 24“, 39 “ 32“, 40“ Fig.3a Fig.3b 24“ HDMI 2 S/PDIF HDMI 1 SCART (ARC) (coax. output) 32“ AC INPUT VIDEO/ S/PDIF SCART (FIXED CABLE) AUDIO L/R (coax. output) HDMI 2 39“ S/PDIF SCART HDMI 1 (ARC) (coax. output) 40“...
- Page 3 Fig.4 Fig.5 Fig. 6 Pause Prev. Next Stop Repeat All Set A Playlist Info. Aspect Ratio Fig. 7 Pause Prev. Next Stop Repeat All Repeat All Playlist Info. Goto time Fig. 8 Play Prev. Next Stop Repeat All Music Playlist Info.
- Page 4 Supplied by STRONG Austria Represented by STRONG Ges.m.b.H. Franz-Josefs-Kai 1 1010 Vienna, Austria Email: support_at@strong.tv 13 Aug 2018 15:36...
- Page 5 Hereby, STRONG declares that the radio equipment type LED TV is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.strong.tv/en/doc Subject to alterations. In consequence of continuous research and development technical specifications, design and appearance of products may change.
-
Page 6: Table Of Contents
TABLE OF CONTENTS 1.0 INSTRUCTION 1.1 Safety Instructions 1.2 Storage 1.3 Accessories 1.4 Equipment set-up 2.0 INSTALLATION 2.1 Default PIN code: 0000 2.2 Front panel/underside 2.3 Rear panel 2.4 Side panel 2.5 Remote control 2.6 Installing the batteries 2.7 Using the remote control 3.0 FIRST TIME INSTALLATION 3.1 DVB-S/S2 installation 3.2 DVB-T/T2 installation... -
Page 7: Instruction
1.0 INSTRUCTION 1.1 Safety Instructions Read all of the instructions before operating the set. Keep these instructions well for later use. Only use attachments/accessories specified or provided by the manufacturer (such as the „ „ exclusive supply adapter, battery etc.). Please refer to the information on the exterior back enclosure for electrical and safety „... -
Page 8: Storage
WEEE Directive Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. -
Page 9: Rear Panel
1. Power indicator /remote sensor 2. Speakers 3. Buttons: Input source, Menu, V-/V+, CH-/CH+, Standby/ON. 4. Power switch ON/OFF* * Except 24” 2.3 Rear panel NOTE: The graphics are for representation only. 2.3.1 24 inch Fig. 3a 1. USB Connect a USB device for playback of multimedia files 2. -
Page 10: Side Panel
6. S/PDIF (coax. output) Use an RCA cable to connect your TV to a compatible digital amplifier or Home theatre set. 2.3.4 40 inch 1. AC INPUT (FIXED CABLE) Main power cable (100 - 240 V ~ 50/60 Hz) 2. S/PDIF (coax. output) Use an RCA cable to connect your TV to a compatible digital amplifier or Home theatre set. -
Page 11: Remote Control
function. This input is equipped with the ARC (Audio Return Channel) feature to implement audio connections and for a full Dolby audio support. 9. USB Connect a USB device for playback of multimedia files 2.5 Remote control Fig. 4 1. ! Press to mute or restore the volume. -
Page 12: Installing The Batteries
Do not place the remote control under direct sunlight which will cause deformation of the unit „ „ by heat. When the remote sensor is under direct sunlight or strong lighting, the remote control will not „ „ work. If so, please change the lighting or TV's position, or operate the remote control closer to the remote sensor. -
Page 13: Dvb-S/S2 Installation
Germany. This option is only available when the country Germany is selected in the First Time Installation. Another more extensive channel list for Germany and Austria can be downloaded from our website: www.strong.tv. 3.2 DVB-T/T2 installation Terrestrial Setting First select the Tune Type by pressing t u to select DTV, ATV or DTV+ATV (DTV to search digital broadcasts and ATV to search analogue broadcasts). -
Page 14: Electronic Programme Guide (Epg)
NOTE: Full scan will have a duration of approximately 20 minutes, depending on your cable network. Please enter (with 0 ~ 9) the main frequency used by your provider in KHz. Frequency Please enter (with 0 ~ 9) the used Network ID from your provider. Network ID Please enter (with 0 ~ 9) the used Symbol from your provider. -
Page 15: Sound Menu
NOTE: Some options may not be available under some sources. Noise Reduction Eliminates noise in the picture. Available choices are Off, Low, Middle and High. In the User mode, settings can be changed for Brightness, Contrast, Colour and Sharpness. 5.2.1 Contrast/Brightness/Colour Tint/Sharpness If Picture Mode is set to Personal you are able to change the following settings Press pq to select an option, then press t u to adjust. -
Page 16: Channel
Adjust the volume corresponding to the input audio level. Options are On Auto Volume and Off. Surround Sound Turns on the Sound Retrieval System. AD Switch Turn on the Audio description, you can activate the setting of AD volume. When turn on the audio description, a narrator will describe what is happening on the screen for blind or visually impaired viewers. -
Page 17: Time Menu
5.4.5 Channel extra settings Edit the programmes. You can press the COLOUR BUTTONS on the remote Programme Edit control to skip programmes, rename and delete programmes or move programmes, and add programmes to the favourite list by pressing FAV. Signal Information Showing the information of current DTV channel. -
Page 18: Setup Menu
2. Back up all of the data in the USB storage device in case data is lost due to an unexpected accident. STRONG does not assume any liability for the losses by misuse or malfunction. Data backup is consumer's responsibility. -
Page 19: Usb Menu
7. When using a USB Hard Disk Drive which is not powered independently, ensure its power does not exceed 500 mA. Otherwise the TV system will change into standby mode, and you must pull out the USB Hard Disk and restart the TV system. 8. - Page 20 Play & Pause/Stop/Previous/Next Press u 2 to play or pause the playback. Press 3 to stop playing. Press 7 8 to play the previous or the next music file. Press t u to highlight the corresponding icon on the control bar, and then press OK. The TV will response accordingly.
-
Page 21: Troubleshooting
Before calling a service technician, review following information for possible causes and solutions for the problem you are experiencing. If the TV does not work properly after checking it, please contact your local service line or STRONG dealer. Alternatively you can send a support mail via our website www. strong.tv. - Page 22 Make sure your dish installation is up to standards to minimize rain effects. When in doubt, ask a local satellite specialist for advice. NOTE: If the problem persists after these solutions, please contact your local support centre or send a support mail via our website www.strong.tv.
-
Page 23: Specifications
8.0 SPECIFICATIONS Audio Audio Output: 6 W + 6 W Video Channel coverage: DVB-T2: 174 MHz-230 MHz; 470 MHz-860 MHz DVB-C: 50-858 MHz DVB-S2: 950 MHz-2150 MHz System: DTV: DVB-T2, DVB-S2, DVB-C ATV: PAL/SECAM (BG/DK/1) AV: PAL, NTSC Connectors 24 inch, 39 inch 1 x ANT/CABLE IN 1 x SAT IN 1 x CI+... - Page 24 General Data Operating voltage: 100 ~ 240 V AC 50/60 Hz Power consumption: 24”: max. 33 W, typ. 19 W 32” max. 53 W, typ. 33 W 39”: max. 68 W, typ. 53 W 40”: max. 76 W, typ. 50 W 24”, 32”, 39”, 40”: <0.5 W Power consumption in standby: 24”, 32”, 39”, 40”: <0.5 W...
