1317A Model Revision 2.2 Updated Jan 17, 2017 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
Page 3
Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.
Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................9 1317A AUTO FLANGER OPERATING INSTRUCTIONS ..............10 MAIN SCREEN............................10 SETUP SCREEN ............................13 ADVANCED SETTING PAGES ......................14 ADVANCED MANUAL PAGES: ......................14 LAST CORNER ADJUSTMENTS: ......................
Technical Manual & Parts Lists Important Safety Instruction This part of the Instruction Material is provided for the safe use of your equipment. It contains important information to help work safely with the unit and describes the dangers inherent in machinery. Some of these dangers are obvious, while others are less evident.
Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet.
Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or...
Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine.
Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated.
Page 11
Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.
Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine.
Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts.
Technical Manual & Parts Lists A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines.
Technical Manual & Parts Lists 1317A AUTO FLANGER OPERATING INSTRUCTIONS: MAIN SCREEN At power-up the machine displays this screen. The machine will not start until all five “Ready” conditions are met. With the machine unloaded, all the conditions should be ready except Panel Trailing Edge Eye.
Page 16
Technical Manual & Parts Lists The blank area to the left of the time display will show the machine piece counter. Press it to reset the daily piece count and access the machine monitor information. Also shown on the main screen is the sew time for the previous panel. FOOT PEDALS: There are four foot pedals located in front of the console.
Page 17
Technical Manual & Parts Lists rear edge guide. All five READY conditions should be good and you can now swipe the start switch located below the screen. The machine will sew up to the first corner, sew the first corner, then sew the next side up to the LAW TAG insertion position and stop (if enabled).
Technical Manual & Parts Lists SETUP SCREEN The SETUP screen provides access to various machine manual functions, settings adjustments, and other machine information. In the SERVICE MODE screen you can sew manually at HIGH SPEED. You can actually sew a complete panel while in this mode, manually turning corners and cutting the flange, You also have the option of sewing with or without the conveyor running (useful when doing maintenance on the sewing head).
Technical Manual & Parts Lists ADVANCED SETTING PAGES Press SECURITY button. Enter security code 33333. Press enter, exit. There are multiple setting pages that allow the control and adjustment of various functions of the machine. Pressing the dark area above each setting displays information about each setting. The + & - buttons can be held down to scroll fast or pressed momentarily for fine adjustment.
Technical Manual & Parts Lists LAST CORNER ADJUSTMENTS: #1. The Finish Guide in front of the sewing head shifts “in” to control the over-sew alignment on the last corner. It should shift when the unsewn portion of the last side has just passed the guide. This is controlled by the Finish Guide Count (Setting #36).
Page 21
Technical Manual & Parts Lists off-loading the panel to the rear of the machine and helping move the next panel to the sewing head. Tap the Conveyor Pedal to stop the conveyor. Sew Head Corner Speed (#10) controls the speed of sewing around the corners. Adjust as needed to get a flat corner sew and to be synchronous with the corner rotation speed.
Page 22
Technical Manual & Parts Lists are running at a setting of, for example, 6 stitches per inch, you would use counter #32 to adjust the corner stopping position. Jam Detect Set Distance (#37) sets the sensitivity of the jam detector wheel located to the left of the sewing head.
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or...
Technical Manual & Parts Lists 1317888 TURNTABLE ASSY. AAC Drawing Number 1317888 Rev 3 NO QTY PART # DESCRIPTION 1317515 BAR,STIFFENER 1317884 PLATE,BASE CONSOLE 1317885 SLIDE PLATE, SEW HEAD 1317887 CAM GUIDE 1317889 PLATE,BASE,CONSOLE 1317892 STIFFENER BAR 1317893 STIFFENER BAR LONG 1318004 RAIL,LINEAR,TAPPED 1318005...
Technical Manual & Parts Lists 1317900 MATERIAL ADV. & CUTTER AAC Drawing Number 1317900 Rev4 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 1975-412A PLATE,NUT,4-40,.95CTC AAQME-5-8 QUICK MALE ELBOW 3517 WASHER,THRUST,BRONZE AAQME-5-10 AIR ELBOW, 10-32 X 5/32 1317083 BRACES,TOP,BACK BBB-66 BEARING,NEEDLE,.375B...
Technical Manual & Parts Lists 1317969 ACCESS DOOR SIDE AAC Drawing Number 1317969 Rev 7 NO QTY PART # DESCRIPTION 1318298 WASTE CHUTE 1318317 WASTE CHUTE BOTTOM 1318318 AI R AMP. BRKT, WASTE 1318368 ACCESS DOOR, SI DE AAQME-4-4 ELBOW, MALE,1/4X1/4NPT MM1155-12A HI NGE,PI ANO,STL,2"...
Technical Manual & Parts Lists 1317983 FLANGE ROLL HOLDER ASSY. AAC Drawing Number 1317983 Rev 1 NO QTY PART # DESCRIPTION 1317977 TRIM ROLL BRACKET 1317979 LOCATOR PLATE 1317984 ROD,SS, 1/2 X 16.0 L 1318276 ROD,SST,1/2X13.61L 1318315 FLANGE JAM DET ARM 787-3-032 CONE BEARING ASSY, 1/2 SH 787-4-032...
Technical Manual & Parts Lists 1318003 CONVEYOR AAC Drawing Number 1318003 Rev 2 NO QTY PART # DESCRIPTION 1317625 BRKT,EGDE GUIDE MOUNT 1317626 GUIDE, EDGE 1318007 CONVEYOR BELT 58W X 351.8 1318008 CONVEYOR BELT 17W X 153.7 1318097 WELDMENT COVER DRIVE SIDE 1318098 WELDMENT OUTER TRAY 1318099...
Technical Manual & Parts Lists 1318052 CONVEYOR DRIVE ASSY. AAC Drawing Number 1318052 Rev 1 NO QTY PART # DESCRIPTION 0211-209 PLATE,NUT,10-32@2.25 CTC 4059-DC1500ABA4 MOTOR & CONTROL W/PGM 1318054 TIMING PULLEY AT10 18T 1961022 MTG. PLT, EFKA MOTOR 1961025 GUARD, EFKA MOTOR 1961028 KEY, 3/16 SQ X 11/16 LG GG124L050...
Technical Manual & Parts Lists 1318083 CONV. DRIVE IDLER ASSY. AAC Drawing Number 1318083 Rev 0 NO QTY PART # DESCRIPTION 1318082 BEARI NG STUD 1 DI A CASE60 1318086 TENSI ON PLATE 1318087 TENSI ON BAR 1318088 TI E BAR I DLER 1318102 I DLER MNT PLATE 1365634...
MODULE,PROGRAM 4080-160 MODULE,HI POWER OUTPUT 4080-200 MODULE,AI R PRESSURE 4080-930 MODULE,DATA EEDC2X2 COVER,WI RE DUCT AAE1317A SOLENOI D ASSY,1317A 4080-990C POWER SUPPLY,SBUS,24VDC AP-28-800W CONTROL BOX,STEPPER MTR AP-28-820D CONTROL BOX, STEP,10A EECA491024 CONTACTOR, MI NI , 240V EEDF2X2 DUCT,WI RE,2X2, MOD EETS35X7.5A...
Technical Manual & Parts Lists 1318240 SWING ARM W/CLAMP ASSY. AAC Drawing Number 1318240 Rev 0 NO QTY PART # DESCRIPTION 1318205 CLAMP SUPPORT BOX 1318210 PANEL CLAMP ASSY 1318211 SWING ARM NNK1/4-20 NUT,KEP,1/4-20 SSBC01032 1/4-20 X 1/2 BUT CAP SC SSBC90024 8-32X3/8 BUTTON CAP WWF8...
Technical Manual & Parts Lists 1318267 FINISH GUIDE ASSEMBLY AAC Drawing Number 1318267 Rev 1 NO QTY PART DESCRIPTION 1318149 GUI DE,EDGE,UPPER 1318150 MOUNT PLATE CYL AA198RA510 FL CONT,5/32X10-32 aaCxsm2040 CYLI NDER,AI R,DUAL ROD SSFCM5X12 M5-0.8X12, FLAT ALLEN SSSC95080 10-24 X 1-1/4 SOC CAP SSSCM6X35 M6X30 SOC CAP SCREW WWFS1/4...
Technical Manual & Parts Lists 1318280 ROTATE SENSOR ASSY. AAC Drawing Number 1318280 Rev 1 NO QTY PART # DESCRIPTION 1317682 BRKT,PROX,EENI5Q18 1318278 ROTATE PROX MOUNT 1318324 PLATE,WASHER, 1/8X2X 1393373 PLATE, NUT, 4-40 EENI5Q18AN6X SENSOR, PROX. NPN,10-30DC SSPP70024 4-40 X 3/8 PAN HD PHIL SSPS70048 4-40 X 3/4 PAN HD SLOTTED SSPS70064...
Technical Manual & Parts Lists 1318292 PULLER ENGAGE EYE ASSY. AAC Drawing Number 1318292 Rev 0 NO QTY PART # DESCRIPTION 1335-316B ROD, SS, "L", 3/8, 4 X 13 23080 BLOCK,CLAMP,EYE 23132A HOLDER, EYE FFSM312LVQ EYE,ELECTRIC,10-30VDC SSPS70048 4-40 X 3/4 PAN HD SLOTTED SSSC98048 10-32 X 3/4 SOC CAP WWL4...
Technical Manual & Parts Lists 1318300 EDGE GUIDE EYE ASSY. AAC Drawing Number 1318300 Rev 2 NO QTY PART DESCRIPTION 1278-6940 EYE ADJUSTMENT BAR 1278-6941 EYE MOUNT 1318304 MOUNT, EYE ROD 1335-320B ROD, ST, S/S, 11" L 350-12104 1/4 ROD AA198-7006 O RI NG, 1/8 I D, 1/4 OD FFSM312LVQ EYE,ELECTRI C,10-30VDC...
Technical Manual & Parts Lists 1318352 CONVEYOR SUB ASSY #1 AAC Drawing Number 1318352 Rev 1 NO QTY PART # DESCRIPTION 1315483 AI R JET ASSEMBLY; LEFT 1318052 CONVEYOR DRI VE ASSY 1318083 CONV DRI VE I DLER ASSY 1318104 MOTOR BASE WELDMENT 1318340 TENSI ON ROLL ASSY, REAR...
Technical Manual & Parts Lists 1317992 TENSION OPENER ASSY. AAC Drawing Number 1317992 Rev 2 NO QTY PART # DESCRIPTION 1317918 PLATE,THREAD TENS. MOUNT 1317929 SPACER CYLINDER AR 13225008 CENTER TENS. EYELETS 1389915 WASHER, THREAD TENS. OPEN 1392988 PIN, TENSION OPENER,SHORT AR 13139555 THREAD TENSION POST AR 13139605...
Technical Manual & Parts Lists 1337595 SEWING HEAD ASSEMBLY AAC Drawing Number 1337595 Rev 4 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION *AR 13104500 OI L DRAI N SCREW 1337644 THREAD GUI DE 13142609 OI L TUBE HOLDER 30 *AR 22924708 OI L SI GHT GLASS * AR 13143300...
Technical Manual & Parts Lists 1337830 BELT FEED ASSY. AAC Drawing Number 1337830 Rev 2 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 13116702 THREAD TRIMMER NNJ1/4-28 NUT, HEX, JAM, 1/4-28 1325-39C SPRING CLIP NNJ5/16-18 NUT,JAM,5/16-18 1337325 TOP SUPPORT LATCH BKT NNJ7/16-20 NUT,JAM,7/16-20 1337467...
Page 108
Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
Page 109
Declaración de Garantía Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero.
Page 110
Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 Printed in the USA www.atlatt.com...
