Technical Manual & Parts Lists
1315B
Model
Revision 0
Updated April 24, 2023
Atlanta Attachment Company
362 Industrial Park Drive
Lawrenceville, GA 30046
770-963-7369 • www.atlatt.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1315B and is the answer not in the manual?

Questions and answers

Related Manuals for Atlanta Attachment Company 1315B

Summary of Contents for Atlanta Attachment Company 1315B

  • Page 1 1315B Model Revision 0 Updated April 24, 2023 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
  • Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.

  • Page 4: Table Of Contents

    Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Liability ..............................2 Safety Equipment on the Machines ......................3 Protective Eyewear ............................. 4 Important Notices............................5 Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................
  • Page 5 Technical Manual & Parts Lists Other Oiling Points ........................... 30 Caution: ..............................30 Setting the Needle ............................. 31 Threading the Machine ..........................32 Tension ..............................33 Needle Thread Tension ..........................33 Looper Thread Tension ..........................33 Pressure ..............................33 Presser Foot Pressure ..........................33 Alternating Pressers ..........................
  • Page 6 1315498 Push Plate Assembly ........................ 103 1315502 Table Assembly ........................105 1315575 Tape Roll Holder........................109 1315595 Head Pusher Assembly ......................110 1315603 Sensor Bracket Assembly ...................... 111 1315A-PD Pneumatic Diagram ......................112 1315B-WD Wiring Diagram ........................113 1315B-WD1 Wiring Diagram ......................... 114...

  • Page 7: Important Safety Instruction

    Technical Manual & Parts Lists Important Safety Instruction This part of the Instruction Material is provided for the safe use of your equipment. It contains important information to help work safely with the unit and describes the dangers inherent in machinery. Some of these dangers are obvious, while others are less evident.

  • Page 8: Liability

    Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet.

  • Page 9: Safety Equipment On The Machines

    Technical Manual & Parts Lists The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or...

  • Page 10: Protective Eyewear

    Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine.

  • Page 11: Important Notices

    Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory about reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated. Pass on the corresponding information to the firemen when they arrive.
  • Page 12 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.

  • Page 13: Maintenance

    Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine.

  • Page 14: Repair

    Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts.

  • Page 15: A Word To The End User

    Technical Manual & Parts Lists A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines.

  • Page 16: Component Identification

    Technical Manual & Parts Lists Component Identification...

  • Page 17: General Machine Data

    Technical Manual & Parts Lists General Machine Data Electrical & Pneumatic Specifications Electrical: 220 VAC, 5amp, 50/60 Hz Single Phase Main Air - 80 PSI, 5 SCFM avg. (3/8” supply line) Pneumatic: Pneumatic Component Belt Tension - 40-50 PSI Sewing Head: AAC 300UX5 Sewing Speed: 3000 RPM...

  • Page 18: Basic Machine Operation

    Technical Manual & Parts Lists Basic Machine Operation The operator loads a mattress and covers the Mattress Edge Detect Eye. The machine will not sew unless the eye is covered. The Foot lift Touch Switch is used to raise the foot for loading a mattress.
  • Page 19 Technical Manual & Parts Lists Once the Rotate Arm Reverse High On Time setting is reached. The arm is then switched into reverse low speed. The arm continues to move in reverse low speed until the Rotate Arm Home Sensor is reached. The Rotate Arm Home Stop Delay then starts which allows for adjusting the arm to stop parallel to the conveyor.
  • Page 20 Technical Manual & Parts Lists After the flip cycle has been completed the operator uses the High Speed Sew pedal to bring the mattress back to the middle of the conveyor. If the Mattress Flip Location setting is set to "0"...

  • Page 21: Operational Path Of Screens

    Technical Manual & Parts Lists Operational Path of Screens. Ready Operator Screen Setu Rotate Arm Page System Information Show all Settings...
  • Page 22 Technical Manual & Parts Lists Advanced Settings Security...
  • Page 23 Technical Manual & Parts Lists Advanced Setup...
  • Page 24 Technical Manual & Parts Lists Advanced Manual...
  • Page 25 Technical Manual & Parts Lists On-Board Diagnostics Typical Warning Page example Help Screens. Accessible by pushing at the top-middle section of a Button. Typical Help Page example...

  • Page 26: Efka Control Box

    The functions can be changed upon power up or after a full heal back. The control box has been programmed to operate specifically with the 1315B unit. If the box is later replaced, the new box will need to be programmed according to the included parameter list to function properly.

  • Page 27: General Machine Maintenance

    Technical Manual & Parts Lists General Machine Maintenance Daily • Clean machine at the end of every shift. • Clean lint etc. from the looper area on the sewing head. • Remove any threads wrapped around moving parts. • Wipe all photo eye lenses with a clean nonabrasive dry cloth. •...

  • Page 28: Electric Eye Sensor Adjustment

    Technical Manual & Parts Lists Electric Eye Sensor Adjustment To adjust the sensor, first remove the clear plastic cover from the end of the sensor. There are two adjusting screws under the cover. One is labeled “GAIN” and is used to set the sensitivity of the sensor.

  • Page 29: Efka Parameter Settings (Sewing Head Motor)

    Technical Manual & Parts Lists Efka Parameter Settings (Sewing Head Motor) Programming Instructions Power on holding down the “P” button until “COD” is displayed. Press “>>” once and enter the number “3112” Press “E” once and “2.0.0” is displayed. This is a parameter. Proceed to the parameter to be changed and press “E”.
  • Page 30 Technical Manual & Parts Lists Before Programming, Perform a Master Reset of Parameters (See Below) PARAMETER RANGE VALUE DESCRIPTION 0-26 Mode of operation. MUST SET THIS PARAMETER FIRST! EB301 Treadle Mode (will not see if box has not been flashed) 400-9900 rpm 3200 Maximum side speed...

  • Page 31: Speed Setting Controls

    Technical Manual & Parts Lists Speed Setting Controls Use the information below to help select which electrical component to adjust in order to synchronize the following sewing speeds. Side Sewing Speed Controls Sewing head - Side speed pot located on the sewing head console. Conveyor Serial Bus Parameter 121 Corner Sewing Speed Controls...

  • Page 32: Conveyor Belt Tracking Instructions

    Technical Manual & Parts Lists Conveyor Belt Tracking Instructions Turn off the air pressure before making any adjustments. 1. Make sure the upper conveyor drive roller is perpendicular to the frame. The motor mounted end of the roller is fixed so this is your starting point. The other end of the roller should be adjusted after losing the screws in or out until it is in the same relationship to the frame as...
  • Page 33 Technical Manual & Parts Lists 3. Locate the lower idler roller assembly mount brackets that are attached to the upper frame. These mount brackets each have two adjustment screws (i) (j) that allow you to tilt the mount bracket forward or backward in relation to the conveyor belt travel. 4.
  • Page 34 Technical Manual & Parts Lists A. If the belt is tracking toward the operator (o) , adjust the driven roller mount brackets as follows: The mount bracket that is on the same side as the operator should be tilted to the right toward the drive roller end of the conveyor.

  • Page 35: Servicing The Sew Head

    Technical Manual & Parts Lists Servicing the Sew Head Installation Assemble the oil pan to the hangers. Insert the assembled oil pan into the machine cut-out table placing four rubber bushings in the hanger holes as shown in Fig. 1. Attach the oil drain jar to the oil pan as shown in Fig.

  • Page 36: Lubrication

    Technical Manual & Parts Lists Lubrication Machines of Class 300U have a semi-automatic lubricating system comprising of a hollow arm shaft and a hollow bed shaft which act as oil reservoirs. The oil is distributed to all the principal bearings by centrifugal force through small jets in the shafts when the machine is in operation. Provision is also made for hand lubricating other movable parts which are not.

  • Page 37: Setting The Needle

    Technical Manual & Parts Lists Setting the Needle Refer to Fig. 6. Turn the machine pulley over toward the operator until the needle bar is at its highest point. Loosen the needle set screw. Insert the needle into the needle bar and clamp as far as it will go making certain that the scarf of the needle faces toward the left.

  • Page 38: Threading The Machine

    Technical Manual & Parts Lists Threading the Machine Either left twist or right twist thread may be used in the needles and loopers. Rough or uneven thread, or thread which passes through the needle eye with difficulty will interfere with successful operation of the machine.

  • Page 39: Tension

    Technical Manual & Parts Lists Tension Tension on the thread should be as light as possible while still sufficient to set the stitch correctly in material. Needle Thread Tension To regulate the needle thread tension, turn the thumb screw indicated in Fig. 8 as may be required. Important: Regulate the needle thread tension only when the presser foot is down.

  • Page 40: Alternating Presser With Pneumatic Pressure Control

    Technical Manual & Parts Lists Alternating Presser with Pneumatic Pressure Control Adjust the height of the Pressure Cylinder with the presser feet resting on the throat plate. There should be a clearance of 1/4” between the Presser Bar Spring Fork and bottom of the cylinder. To raise the cylinder, loosen the lower lock nut and tighten upper lock nut, see Fig.

  • Page 41: Machine With Puller Feed

    Technical Manual & Parts Lists Machine with Puller Feed The length of the stitch is determined by the stitch gears in the puller feed mechanism. The compound feed stitch length should be set slightly shorter than the stitch length of the puller feed. To change the Puller Feed gears for adjusting stitch length, remove the two cover plate screws and remove the cover plate, Fig.

  • Page 42: Machines With Alternating Pressers

    Technical Manual & Parts Lists Machines with Alternating Pressers The lift of the vibrating and lifting pressers is controlled by an adjustable eccentric. To adjust, remove the arm cover at the rear of the machine. Turn the machine pulley over toward the operator until the feeding presser is down.

  • Page 43: Setting The Height Of Feed Bar

    Technical Manual & Parts Lists Setting the Height of Feed Bar When the feed bar is set at the correct height, the feed lift link clamp will be aligned with the rock shaft timing flat. To adjust, make certain that the feed lifting crank timing screw, Fig. 19, engages the shaft spot correctly.

  • Page 44: Timing The Feed Lift Eccentric

    Technical Manual & Parts Lists Timing the Feed Lift Eccentric When the feed dog is at its highest position, the top of the teeth should be parallel with, and project full depth of the teeth above the upper surface of the throat plate. To adjust, insert screwdriver in the hole in the feed strap and loosen the two set screws, Fig.

  • Page 45: Setting The Distance From The Looper To The Needle

    Technical Manual & Parts Lists Setting the Distance from the Looper to the Needle Sidewise Setting When the looper is correctly positioned, the point of the looper just clears the scarf of the needle on the forward stroke of the looper. To adjust, turn the machine pulley until the looper point is directly opposite of the center of the needle.

  • Page 46: Timing Looper Driving Crank

    Technical Manual & Parts Lists Timing Looper Driving Crank When the looper driving crank is properly timed, the point of the looper will pass above the eye of the needle at the same distance on both the forward and backward strokes of the looper. To adjust when the point of the looper passes higher on the forward stroke, loosen the looper driving crank set screw, Fig.

  • Page 47: Positioning Spreader

    Technical Manual & Parts Lists Positioning Spreader Fig 32 Fig 31 Sidewise and Height Setting When the looper on its forward stroke is passing the spreader a) The point of the spreader should be exactly opposite the top of the thread groove at the left side of the looper.

  • Page 48: Adjusting Needle Thread Tension Releaser

    Technical Manual & Parts Lists The needle thread take-up and thread guide may be adjusted to increase or decrease the amount of thread drawn at the top of the needle bar stroke. To increase the amount, loosen the thread take-up screw, Fig. 34, and raise the take-up or loosen the guide screw and lower the guide.

  • Page 49: Notes

    Technical Manual & Parts Lists Notes :...

  • Page 50: Aac 300Ux6 Assembly Drawings & Parts Lists

    Technical Manual & Parts Lists AAC 300UX6 Assembly Drawings & Parts Lists Atlanta Attachment Company is the exclusive stocking distributor for AAC Tape Edge Sewing Heads and recommended spare parts for AAC Tape Edge machines. We can also supply proprietary parts in most cases for Cash*, Spuhl*, Porter, United* Tape Edge workstations.
  • Page 51 Technical Manual & Parts Lists...

  • Page 52: Upper Shaft Assembly

    Technical Manual & Parts Lists Upper Shaft Assembly NO. PART # DESCRIPTION NO. PART # DESCRIPTION 32 415077 415138 CRANK, NEEDLE BAR LIFTING ECC FLANGE 32848 BEARING 33 374098 SCREW 2812239 NEEDLE BAR CRANK COMPLETE 34 415081 ECCENTRIC COMP 549024 SCREW 35 268491 LIFTING ECCENTRIC...
  • Page 53 Technical Manual & Parts Lists...

  • Page 54: Front Assembly Sewing Arm

    Technical Manual & Parts Lists Front Assembly Sewing Arm NO. PART # DESCRIPTION NO. PART # DESCRIPTION 25 414545 267617 LINK HINGE PIN SET SCREW 268258 PACKING WICK 26 267657 VIB PRESSER BAR 267627 LIFTING LINK 27 267658 VIBRATING PRESSER BAR HINGE ST 415061 LIFTING CRANK 28 281912...
  • Page 55 Technical Manual & Parts Lists...

  • Page 56: External Parts Sewing Arm #1

    Technical Manual & Parts Lists External Parts Sewing Arm #1 NO. PART # DESCRIPTION 32788 ROCK SHAFT 32788 ROCK SHAFT 32789 ROCK SHAFT 548035 141424 SCREW 267110 NEEDLE BEARING,GBH-78 415065 COLLAR COMP 504020 SCREW (300UX5) 415069 CONN CRANK 414509 SCREW 374362 SUBSTITUTION REQUIRED 267617...
  • Page 57 Technical Manual & Parts Lists...

  • Page 58: Lower Shaft Assembly

    Technical Manual & Parts Lists Lower Shaft Assembly NO. PART # DESCRIPTION NO. PART # DESCRIPTION 34 541197 415176 DRIVE CRANK 374099 SCREW 35 545297 SCREW 500264833 LOOPER DRIVING CRANK SET SCREW 36 415082 ECCENTRIC COMP 268102 COVER, OIL HOLE 37 415073 FEED DRIVING ECC FLANGE 414563...
  • Page 59 Technical Manual & Parts Lists...

  • Page 60: Front Assembly Sewing Bed

    Technical Manual & Parts Lists Front Assembly Sewing Bed NO. PART # DESCRIPTION NO. PART # DESCRIPTION 28 281208 559061 FEED DOG LOOPER COMPLETE WITH GUARD 267665 LOOP DEFLECTOR 29 268382 LOOPER ONLY (ORDER 281207 FOR SCREW, LOOP DEFL 30 281207 NEEDLE GUARD 559064 FEED DOG SHANK...
  • Page 61 Technical Manual & Parts Lists...

  • Page 62: Cross Shaft In Sewing Bed

    Technical Manual & Parts Lists Cross Shaft in Sewing Bed NO. PART # DESCRIPTION 281975 SPREADER 268162 SPREADER POINT 414552 SCREW 547670 WASHER 415196 SPREADER HOLDER 414529 SCREW 268184 SPREADER BAR BRACKET 414524 SCREW 559065 SPREADER BAR 268190 SPREADER DRIVE PIN 415297 BUSHING 415389...
  • Page 63 Technical Manual & Parts Lists...

  • Page 64: External Parts Sewing Arm #2

    Technical Manual & Parts Lists External Parts Sewing Arm #2 NO. PART # DESCRIPTION KE0085 FOOT LIFTER LEVER 201363 SCREW 300W 267707 RELEASING PLATE 543850001 PLATE PIN 414577 HINGE SCREW 543804004 WASHER 541166003 204348 SWITCH SPRING 414570 SCREW 544336 STUD SCREW 267704 LIFTER LEVER ROD 248423...
  • Page 65 Technical Manual & Parts Lists...

  • Page 66: External Parts Sewing Arm #3

    Technical Manual & Parts Lists External Parts Sewing Arm #3 NO. PART # DESCRIPTION 268506 TH GUIDE BRACKET 268111 LOOPER BRACKET 268505 LOOPER TH GUIDE 50169 SCREW (5) 414537 SCREW 544875 PLUG 267971 THREAD TENSION HA046072 TENSION DICS 32572 TENSION DISC (5) 59538 SPRING BUSHING 131741...
  • Page 67 Technical Manual & Parts Lists...

  • Page 68: External Parts Sewing Arm #4

    Technical Manual & Parts Lists External Parts Sewing Arm #4 NO. PART # DESCRIPTION KE0021 FACE PLATE (WITH 268033) 268330 FACE PLATE HINGE STUD 544053 SET SCREW 268033 LOCK STUD 228661 COVER CUSHION 268032 LOCK SPRING 415016 SPRING PLATE 414534 SCREW KE0072 ARM SIDE COVER...
  • Page 69 Technical Manual & Parts Lists...

  • Page 70: External Parts Sewing Arm #5

    Technical Manual & Parts Lists External Parts Sewing Arm #5 NO. PART # DESCRIPTION KE0073 BED PLATE (RIGHT) 414508 SCREW KE0037 BED PLATE (LEFT) 559060 THROAT PLATE 374107001 THROAT PLATE SCREW (BACK) 200100 SCREW KE0075 FEED REGULATING STUD SOCKET 268081 STUD, FEED REG 270026 FEED REG STUD SPR...
  • Page 71 Technical Manual & Parts Lists Accessories...

  • Page 72: Assembly Drawings & Parts Lists

    Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or...

  • Page 73: 11315B Auto Tape Edge Machine

    Technical Manual & Parts Lists 11315B Auto Tape Edge Machine AAC Drawing Number 9008712 Rev 3...
  • Page 74 Technical Manual & Parts Lists...
  • Page 75 Technical Manual & Parts Lists...
  • Page 76 Technical Manual & Parts Lists...
  • Page 77 Technical Manual & Parts Lists...
  • Page 78 Technical Manual & Parts Lists...
  • Page 79 Technical Manual & Parts Lists...

  • Page 80: 1315050 Rotate Arm Assembly

    Technical Manual & Parts Lists 1315050 Rotate Arm Assembly AAC Drawing Number 1315050 Rev 4...
  • Page 81 Technical Manual & Parts Lists...

  • Page 82: 1315030 Backstop Assembly

    Technical Manual & Parts Lists 1315030 Backstop Assembly AAC Drawing Number 1315030 Rev 2...
  • Page 83 Technical Manual & Parts Lists...

  • Page 84: 1315100 Sew Head Assembly

    Technical Manual & Parts Lists 1315100 Sew Head Assembly AAC Drawing Number 1315100 Rev 9...
  • Page 85 Technical Manual & Parts Lists...

  • Page 86: 1315115 Arm Gearbox Assembly

    Technical Manual & Parts Lists 1315115 Arm Gearbox Assembly AAC Drawing Number 1315115 Rev 5...
  • Page 87 Technical Manual & Parts Lists 1315115 parts list...

  • Page 88: 1315435 Limit Switch Assembly

    Technical Manual & Parts Lists 1315435 Limit Switch Assembly AAC Drawing Number 1315435 Rev 4 NO QTY PART # DESCRIPTION 1 1315157 PLATE, LIMIT SENSOR 1 1315428 PLATE,NUT 10-32 25MM CTC 1 1315429 MOUNT, SENSOR HORZ. 1 EEAP2R41W02 SWITCH, SAFETY, LIMIT, 5 *10' FF18984C CABLE,4 COND,18 AWG,300V 1 FFM4518...

  • Page 89: 1315245 Control Box. Electrical Assembly

    Technical Manual & Parts Lists 1315245 Control Box. Electrical Assembly AAC Drawing Number 1315245 Rev 4...
  • Page 90 Technical Manual & Parts Lists...
  • Page 91 Technical Manual & Parts Lists...

  • Page 92: 1315300 Console Assembly

    Technical Manual & Parts Lists 1315300 Console Assembly AAC Drawing Number 1315300 Rev 3...
  • Page 93 Technical Manual & Parts Lists 1315300 parts list QTY PART # DESCRIPTION 1315123 MOUNT, EFKA 1315124 COVER, COLUMN 1315125 CONSOLE BASE, WELDMENT 1315128 AXLE, COLUMN 1315130 MOUNT, CONSOLE 1315138 COVER, WELDMENT 1315144 AXEL, PIVOT 1315146 COVER, CONSOLE 1315148 WIPER, COLUMN SHORT 1315149 WIPER, COLUMN LONG 1315150...

  • Page 94: 1315200 Column Assembly

    Technical Manual & Parts Lists 1315200 Column Assembly AAC Drawing Number 1315200 Rev 6...
  • Page 95 Technical Manual & Parts Lists 1315200 parts list...

  • Page 96: 1315327 Lift Platform Assembly

    Technical Manual & Parts Lists 1315327 Lift Platform Assembly AAC Drawing Number 1315327 Rev 4...
  • Page 97 Technical Manual & Parts Lists 1315327 parts list NO QTY PART # DESCRIPTION 1315060 ASSY,FOOTPEDAL 1315339 ROLLER, TOP 1315341 AXLE, TOP ROLLERS 1315354 COVER, TOWER 1315355 BLOCK, PI VOT TOWER 1315380 ASSY, BASE PLATFORM 1315385 RI SER, WELDMENT 1315386 ASSY, RI SER, .5 FRONT 1315387 RI SER, .5 REAR WELDMENT 1315388...

  • Page 98: 1315060 Foot Pedal Assembly

    Technical Manual & Parts Lists 1315060 Foot Pedal Assembly AAC Drawing Number 1315060 Rev 0 QTY PART # DESCRIPTION 1278-6161 FOOT SWITCH MODIFICATION 1315-010 CABLE, FOOT PEDAL 1315047 PLATE, PEDAL MOUNT 1315048 GUARD, PEDAL AAF1/8 1/8" PLASTIC CLAMP NNE6-32 NUT,ELASTIC LOCK,6-32 SSFC80024 #6-32 X 3/8 FLAT ALLEN...

  • Page 99: 1315400 Flipper Assembly

    Technical Manual & Parts Lists 1315400 Flipper Assembly AAC Drawing Number 1315400 Rev 7...
  • Page 100 Technical Manual & Parts Lists...
  • Page 101 Technical Manual & Parts Lists...
  • Page 102 Technical Manual & Parts Lists...

  • Page 103: 1315095 Pilot Valve Assembly

    Technical Manual & Parts Lists 1315095 Pilot Valve Assembly AAC Drawing Number 1315095 Rev 0...

  • Page 104: 1315430 Pneumatic Panel

    Technical Manual & Parts Lists 1315430 Pneumatic Panel AAC Drawing Number 1315430 Rev 4...
  • Page 105 Technical Manual & Parts Lists 1315430 parts list NO QTY PART # DESCRIPTION 1315209 COVER 1315566 PANEL, PNEUMATIC AA198-508 REGULATOR, 0-160 W/GAUGE AA198-5110 FILTER/REGULATOR/LOCKOUT AAE1315-12 SOLENOID ASSY,12 STATION AAQME-3-4 MALE ELBOW 3/8OD TUBE AAQME-4-4 ELBOW, MALE,1/4X1/4NPT AAQUY-3-3 QUICK UNION Y 3/8 X 3/8 AAQUY-4-4 Y UNION, 1/4X1/4 AAVF51FM1B AIR/ELEC PRESSURE SW...

  • Page 106: 1315450 Tape Guide Assembly

    Technical Manual & Parts Lists 1315450 Tape Guide Assembly AAC Drawing Number 1315450 Rev 2 QTY PART # DESCRIPTION 1315174 ROD, BENT, 1/2 CRS 1315475 CLAMP, 3/4 ROD 1335-316 ROD, SS, "L", 3/8, 4.0 X 1335-320 ROD,S/S,3/8,6.5L 1338-028 RING,TAPE GUIDE 28201 BLOCK,CROSS,(LARGE) 28202...

  • Page 107: 1315479 Air Jet Assembly; (Right Side)

    Technical Manual & Parts Lists 1315479 Air Jet Assembly; (Right Side) AAC Drawing Number 1315479 Rev 1...

  • Page 108: 1315483 Air Jet Assembly; (Left Side)

    Technical Manual & Parts Lists 1315483 Air Jet Assembly; (Left Side) AAC Drawing Number 1315483 Rev 0...

  • Page 109: 1315498 Push Plate Assembly

    Technical Manual & Parts Lists 1315498 Push Plate Assembly AAC Drawing Number 1315498 Rev 2...
  • Page 110 Technical Manual & Parts Lists...

  • Page 111: 1315502 Table Assembly

    Technical Manual & Parts Lists 1315502 Table Assembly AAC Drawing Number 1315502 Rev 4...
  • Page 112 Technical Manual & Parts Lists...
  • Page 113 Technical Manual & Parts Lists...
  • Page 114 Technical Manual & Parts Lists...

  • Page 115: 1315575 Tape Roll Holder

    Technical Manual & Parts Lists 1315575 Tape Roll Holder AAC Drawing Number 1315575 Rev 1...

  • Page 116: 1315595 Head Pusher Assembly

    Technical Manual & Parts Lists 1315595 Head Pusher Assembly AAC Drawing Number 1315595 Rev 1 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1315597 MOUNT, CYLINDER BASE NNE5/16-18 NUT,ELASTIC LOCK,5/16-18 1315598 BASE, HEAD PUSHER NNK1/4-20 KEP NUT, 1/4-20 1315600 WELDMENT, HEAD PUSHER RAM SSAS024128...

  • Page 117: 1315603 Sensor Bracket Assembly

    Technical Manual & Parts Lists 1315603 Sensor Bracket Assembly AAC Drawing Number 1315603 Rev 1 QTY PART # DESCRIPTION 1315015 BLOCK, EYE MOUNT 1315016 BLOCK, SENSOR 1315017 BRACKET, SENSOR MOUNT 1315020 BLOCK, NUT 1315605 BRACKET, SENSOR MTG FFT18FF100Q EYE,FIXED FIELD, 4IN MMAM1-A0-4AM PROX SWITCH,10-30VDC,12MM TTH32426 HANDLE,THRD,5/16-18X1-1/4...

  • Page 118: 1315A-Pd Pneumatic Diagram

    Technical Manual & Parts Lists 1315A-PD Pneumatic Diagram AAC Drawing number 125606A Rev 0...

  • Page 119: 1315B-Wd Wiring Diagram

    Technical Manual & Parts Lists 1315B-WD Wiring Diagram AAC Drawing Number 125692D Rev 12...

  • Page 120: 1315B-Wd1 Wiring Diagram

    Technical Manual & Parts Lists 1315B-WD1 Wiring Diagram AAC Drawing Number 125691D Rev 1...
  • Page 121 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
  • Page 122 Declaración de Garantía Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero.
  • Page 124 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 Printed in the USA 770-963-7369 www.atlatt.com...

Table of Contents
