- Page 1 1335M Model Revision 21.2 Updated Jan 7, 2014 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
-
Page 3: Table Of Contents
Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials. - Page 4 11335M Recommended Spare Parts List ....................16 AAC Part # SP1335M Spare Parts Kit ..................... 16 Parameter Settings for Efka Controller ..................... 17 1335M Folder Spacer Reference Chart ..................... 18 Assembly Drawings & Parts Lists ......................19 11335M Manual Pillowtop Ruffler, No Flange ..................20 11335M-SDAT Manual Pillowtop Ruffler ....................
- Page 5 1335M-9500 Stepper Box Assembly ......................62 1335M-2100A Ruffler Cylinder Assembly ....................63 1335M-2200 Ruffler Mounting Angle Assembly..................64 1335M-2400 Ball Screw and Nut Assembly .................... 65 A-2216D 1/2 Book Folder, 1/2 “Capacity ....................66 A-2216K5/16 Flat Folder W/ Flange, 5/16 x 6” Capacity ................ 67...
- Page 6 1335M-PD Pneumatic Diagram ........................ 94 1335M-PDK5 Pneumatic Diagram ......................95 1959-PD Pneumatic Diagram, Flanging Unit ................... 96 1335M-500WD Wiring Diagram, Control Box ..................97 1335M-WD Wiring Diagram ........................98 1335M-01WD Wiring Diagram ........................ 99 1334S-01WD Wiring Diagram, Flanging Unit ..................100...
-
Page 7: Important Safety Instruction
Technical Manual & Parts Lists Important Safety Instruction This part of the Instruction Material is provided for the safe use of your equipment. It contains important information to help work safely with the unit and describes the dangers inherent in machinery. Some of these dangers are obvious, while others are less evident. -
Page 8: Liability
Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet. -
Page 9: Safety Equipment On The Machines
Manual & Parts Lists Technical A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or... -
Page 10: Protective Eyewear
Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine. -
Page 11: Important Notices
Manual & Parts Lists Technical Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated. - Page 12 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.
-
Page 13: Maintenance
Manual & Parts Lists Technical Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine. -
Page 14: Repair
Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts. -
Page 15: A Word To The End User
Manual & Parts Lists Technical A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines. -
Page 16: General Machine Data
Technical Manual & Parts Lists General Machine Data Electrical & Pneumatic Specifications Electrical: 220 VAC, 5amp, 50/60 Hz Single Phase Pneumatic: 70-80 PSI, 2 SCFM avg. Sewing Head: Mitsubishi LS2-2210 Lockstitch Sewing Speed: 4000 RPM Needle (Standard): Schmetz DBX1 Size 140 Stitch Density: 6 SPI Sewing Head:... -
Page 17: Control Box Operation
Manual & Parts Lists Technical Control Box Operation Main Control Box: The front of the main control box has an Auto/Manual Switch, a Manual Ruffle Pushbutton, an Unwinder Reverse Switch, a Fuse Holder, and 6 Thumbwheels. On the back is the power entry socket and an on/off switch. Be sure the on/off switch is always Note: The on/off switch only switches one line and does not make the box safe to work on. -
Page 18: Stepper Control Boxes
Technical Manual & Parts Lists Stepper Control Boxes There are two stepping motor boxes located under the table. The box with the 10-turn adjustable potentiometer on the Fig. 4 front controls the Ruffler and the box without controls the Puller. The Puller box has three Thumbwheels on the front which are set to synchronize the puller to the sewing head. -
Page 19: Basic Machine Operation
Manual & Parts Lists Technical Basic Machine Operation Loading the Gusset Roll and Unwinder Remove the small disc from the Unwinder spindle. Load the gusset (or border) roll onto the Unwinder spindle so the good side is up and the flange is toward the large disc as the material comes off the roll to the left. -
Page 20: Sewing The Panel
Technical Manual & Parts Lists Sewing the Panel Heal back the treadle or step on the foot lift pedal to raise the presser foot. Swing in the stripper blade and the folder/ruffler assembly. Be sure the sensor at the back of the swing-out bracket is lit indicating that the bracket is all the way in to the detent. -
Page 21: General Machine Adjustments
Manual & Parts Lists Technical General Machine Adjustments Air Pressure Set all air supply pressure regulators (Right to left): Main Pressure: 70 PSI Puller Pressure: 30 PSI Ruffle Blade Pressure: 10 PSI Foot Sew Pressure: 15 PSI Sewing Head See the manufacturer’s manuals for normal adjustments and parts. The presser foot spring pressure should be set very light so that the ruffling blade can feed under the foot while ruffling. -
Page 22: General Machine Maintenance
AAC Part # SP1335M Spare Parts Kit QTY PART # DESCRIPTION QTY PART # DESCRIPTION 1 1278-7055B Prox Switch 1 GG100XL037 Gear Belt 2 1335M-2002C Ruffler Blade 1 GG110XL75U Gear Belt 3 2’ EEFE-RR2 Reflective Tape 1 GG187L050 Gear Belt 1 FFSM312LVQ Electric Eye... -
Page 23: Parameter Settings For Efka Controller
Manual & Parts Lists Technical Parameter Settings for Efka Controller... -
Page 24: 1335M Folder Spacer Reference Chart
Technical Manual & Parts Lists 1335M Folder Spacer Reference Chart... -
Page 25: Assembly Drawings & Parts Lists
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or... -
Page 26: 11335M Manual Pillowtop Ruffler, No Flange
Technical Manual & Parts Lists 11335M Manual Pillowtop Ruffler, No Flange AAC Drawing Number 192725C Rev5 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 1335M-4000A Unwinder Assy Error! Page 76 1335M-420 Guide Roller Assy Bookma... -
Page 27: 11335M-Sdat Manual Pillowtop Ruffler
Manual & Parts Lists Technical 11335M-SDAT Manual Pillowtop Ruffler AAC Drawing Number 192897C Rev0 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 73 1335M-4000A Unwinder Assy Page Page 76 1335M-420 Guide Roller Assy Page Page 47... -
Page 28: 11335M-Suat Manual Pillowtop Ruffler
Technical Manual & Parts Lists 11335M-SUAT Manual Pillowtop Ruffler AAC Drawing Number 192898C Rev2 QTY PART # DESCRIPTION 4059-FP301D Foot Switch Assy Page 73 1335M-4000A Unwinder Assy Page Page 76 1335M-420 Guide Roller Assy Page Page 47 1335M-G Generic Console... -
Page 29: 11335Ma-Sdat Manual Pillowtop Ruffler
Manual & Parts Lists Technical 11335MA-SDAT Manual Pillowtop Ruffler AAC Drawing Number 192881C Rev0 QTY PART # DESCRIPTION 1335M-1005 Sit Down Treadle Assy Page 81 Page Page 73 1335M-4000A Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page Page 47... -
Page 30: 11335Ma-Suat Manual Pillowtop Ruffler
Technical Manual & Parts Lists 11335MA-SUAT Manual Pillowtop Ruffler AAC Drawing Number 192882C Rev2 QTY PART # DESCRIPTION 4059-FP301D Foot Switch Assy Page 73 1335M-4000A Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page Page 47 1335M-G Generic Console... -
Page 31: 11337At Air Table Assembly
Manual & Parts Lists Technical 11337AT Air Table Assembly AAC Drawing Number 9002611 Rev5 QTY PART # DESCRIPTION 1335081 SUPPORT, SHELF AR 1337023 BRACKET, TABLE TOP RUFFLR AR 1337024 MOUNT, AIR TABLE 1337A-0168B BRACKET, RETAINER Page 80 1337A-160 AIR TABLE ASSY,SINGLE TBL Page 1337A-175C SHELF, AIR TABLE,23"X30"... -
Page 32: 11335Ma Manual Pillowtop Ruffler, With Flange, Flat Ruffle
Technical Manual & Parts Lists 11335MA Manual Pillowtop Ruffler, with Flange, Flat Ruffle AAC Drawing Number 192849C Rev1 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 73 1335M-4000A Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy... -
Page 33: 11335Mb Manual Pillowtop Ruffler, W/Premade Folded Gusset
Manual & Parts Lists Technical 11335MB Manual Pillowtop Ruffler, W/Premade Folded Gusset AAC Drawing Number 192756C Rev2 QTY PARTS # DESCRIPTION Page 73 1335M-4000A Unwinder Assy Page Page 77 1335M-425 Guide Roller Assy Page Page 47 1335M-G Generic Console Page... -
Page 34: 11335Mc Continental Foundation Ruffler, 18", No Flange
Technical Manual & Parts Lists 11335MC Continental Foundation Ruffler, 18”, No Flange AAC Drawing Number 192820C Rev1 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 73 1335M-4000A Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy... -
Page 35: 11335Mc-Sdat Continental Foundation Ruffler, 18
Manual & Parts Lists Technical 11335MC-SDAT Continental Foundation Ruffler, 18” AAC Drawing Number 192883C Rev0 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 73 1335M-4000A Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page... -
Page 36: 11335Mc-Suat Continental Foundation Ruffler, 18
Technical Manual & Parts Lists 11335MC-SUAT Continental Foundation Ruffler, 18” AAC Drawing Number 192884C Rev2 QTY PART # DESCRIPTION 4059-FP301A Foot Switch Assy Page 73 1335M-4000A Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page Page 47 1335M-G Generic Console... -
Page 37: 11335Mda Manual Pillowtop Ruffler
Manual & Parts Lists Technical 11335MDA Manual Pillowtop Ruffler AAC Drawing Number 192885C Rev1 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 71 1335105 Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page Page 38... -
Page 38: 11335Mda-Sdat Manual Pillowtop Ruffler
Technical Manual & Parts Lists 11335MDA-SDAT Manual Pillowtop Ruffler AAC Drawing Number 192886C Rev1 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 71 1335105 Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page Page 38... -
Page 39: 11335Mda-Suat Manual Pillowtop Ruffler
11335MDA-SUAT Manual Pillowtop Ruffler AAC Drawing Number 192887C Rev2 QTY PART # DESCRIPTION 4059-FP103D Foot Switch Assy Page 71 1335105 Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page Page 38 1335MD-G Generic Console Page Page 67 A-2216K5/16 Flat Folder Page... -
Page 40: 11335Mdc Continental Foundation Ruffler, 16
Technical Manual & Parts Lists 11335MDC Continental Foundation Ruffler, 16” AAC Drawing Number 192888C Rev2 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 71 1335105 Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page... -
Page 41: 11335Mdc-Sdat Continental Foundation Ruffler, 16
Manual & Parts Lists Technical 11335MDC-SDAT Continental Foundation Ruffler, 16” AAC Drawing Number 192889C Rev1 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 71 1335105 Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page... -
Page 42: 11335Mdc-Suat Continental Foundation Ruffler, 16
11335MDC-SUAT Continental Foundation Ruffler, 16” AAC Drawing Number 192890C Rev2 QTY PART # DESCRIPTION 1278-6160E Foot Switch Assy Page 71 1335105 Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page Page 47 1335M-G Generic Console Page Page 69 A-2216M 5/16 Book Folder Page... -
Page 43: 1335M-2300 Pivot Assembly
Manual & Parts Lists Technical 1335M-2300 Pivot Assembly AAC Drawing Number 192731C Rev3 QTY PART # DESCRIPTION 1335M-2004 Pivot Arm 1335M-2007 Pivot Block 1335M-2009 Drive Link 1335M-2010 Pivot Block 1335M-2011 Pivot Shaft 1335M-2012 Side Link 1335M-2013 Link Shaft 1335M-2014 Link Shaft... -
Page 44: 1335Md-G Generic Console
1959-112 Thread Plate Assy Page Page 49 1335M-120 Puller Drive Assy SSBC98032 Screw, Button Cap Page Page 51 1335M-1000 Stand & Motor SSSC98040 Screw, Socket Cap Page Page 55 1335M-2000A Ruffler Assy SSHC01048 Screw, Hex Cap Page Page 57 1335M-3000A Puller Assy... -
Page 45: 11335Mde Euro Top Ruffler, 9
Manual & Parts Lists Technical 11335MDE Euro Top Ruffler, 9” AAC Drawing Number 192891C Rev1 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 71 1335105 Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page... -
Page 46: 11335Mde-Sdat Euro Top Ruffler, 9
Technical Manual & Parts Lists 11335MDE-SDAT Euro Top Ruffler, 9” AAC Drawing Number 192892C Rev1 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 71 1335105 Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page... -
Page 47: 11335Mde-Suat Euro Top Ruffler, 9
11335MDE-SUAT Euro Top Ruffler, 9” AAC Drawing Number 192893C Rev1 QTY PART # DESCRIPTION 1278-6160E Foot Switch Assy Page 71 1335105 Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page Page 47 1335M-G Generic Console Page 68 Page A-2216L5/16 Flat Folder Page... -
Page 48: 11335Me Euro Top Ruffler, 9
Technical Manual & Parts Lists 11335ME Euro Top Ruffler, 9” AAC Drawing Number 192894C Rev0 QTY PART # DESCRIPTION Page 81 1335M-1005 Sit Down Treadle Assy Page Page 73 1335M-4000A Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page... -
Page 49: 11335Me-Sdat Euro Top Ruffler, 9
Manual & Parts Lists Technical 11335ME-SDAT Euro Top Ruffler, 9” AAC Drawing Number 192895C Rev0 QTY PART # DESCRIPTION 1335M-1005 Sit Down Treadle Assy Page 81 Page Page 73 1335M-4000A Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page... -
Page 50: 11335Me-Suat Euro Top Ruffler, 9
Technical Manual & Parts Lists 11335ME-SUAT Euro Top Ruffler, 9” AAC Drawing Number 192896C Rev2 QTY PART # DESCRIPTION 4059-FP301D Foot Switch Assy Page 73 1335M-4000A Unwinder Assy Page Page 78 1335M-430 Guide Roller Assy Page Page 47 1335M-G Generic Console... -
Page 51: 11335Msa Manual Pillowtop Ruffler, W/ Air Table
Manual & Parts Lists Technical 11335MSA Manual Pillowtop Ruffler, W/ Air table AAC Drawing Number 192742C Rev2 QTY PART # DESCRIPTION Page 80 1337A-160 Air Table Assy Page 1337A-0168C Retainer Brkt 1337A-175 Shelf Page 20 11335M Manual Ruffler Page 4048-2210MM Table Top, Mod. -
Page 52: 11335M-34 Manual Pillowtop Ruffler, W/ Auto Flanger
1335M-4200A Support Frame Assy Page Page 77 1335M-425 Guide Roller Assy Page Page 47 1335M-G Generic Console Page Page 99 AR 1335M-01WD Wiring Diagram Page A-2216K5/16 Folder NNH3/8-16 Hex Nut SSHC01048 Screw, Hex Cap SSHC25192 Screw, Hex Cap WWFS1/4 Flat Washer... -
Page 53: 1335M-G Generic Console
Manual & Parts Lists Technical 1335M-G Generic Console AAC Drawing Number 192835C Rev3 QTY PART # DESCRIPTION Page 89 1335M-10 Sew Head Assy Page Page 49 1335M-120 Puller Drive Assy Page Page 51 1335M-1000 Stand & Motor Page Page 53... - Page 54 Technical Manual & Parts Lists...
-
Page 55: 1335M-120 Puller Drive Assembly
Manual & Parts Lists Technical 1335M-120 Puller Drive Assembly AAC Drawing Number 9001014 Rev4 QTY PART # DESCRIPTION 011-020 MOTOR, STEPPER W/PLUG 1335-116 SHAFT,FLATTED,60C,.375 1335-119 BLOCK, BEARING 1335-124 GUARD, MOTOR BELT 1335M-121 HEX SHAFT, 3/8X4 3/8 1335M-127 MOUNT, MOTOR 1335M-128... - Page 56 Technical Manual & Parts Lists...
-
Page 57: 1335M-1000 Stand & Motor Assembly
Manual & Parts Lists Technical 1335M-1000 Stand & Motor Assembly AAC Drawing Number 192705C Rev8 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 0211-702A Cable, Position Sensor NNH1/2-13 Hex Nut SSSCM3X30 Socket Cap Screw NNH5/16-18 Hex Nut 1278-6689B... - Page 58 Technical Manual & Parts Lists...
-
Page 59: 1335M-2000 Ruffler Assembly
Screw, Socket Cap 1335M-2040 Adjustment Screw SSSC98048 Screw, Socket Cap 1335M-2042 Cover SSTS90024 Screw, Truss Head Page 63 1335M-2100A Ruffler Cylinder Assy SSTS98040 Screw, Truss Head Page Page 64 1335M-2200 Mount Angle Assy TTCL1APPK1‘ Plastic Knob Page Page 37 1335M-2300... - Page 60 Technical Manual & Parts Lists...
-
Page 61: 1335M-2000A Ruffler Assembly
Manual & Parts Lists Technical 1335M-2000A Ruffler Assembly AAC Drawing Number 9000004 Rev 3 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1278-7055D PROX SWITCH W/PLUG,12" NNE1/2-13 ELASTIC LOCK NUT AR 1325-4126 TEFLON TAPE, 1" NNH2-56 #2-56 HEX NUT... - Page 62 Technical Manual & Parts Lists...
-
Page 63: 1335M-3000A Puller Assembly
Manual & Parts Lists Technical 1335M-3000A Puller Assembly AAC Drawing Number 192802C Rev3 QTY PART # DESCRIPTION 1278-7055D Prox Switch 1335M-2034 Nut Plate 1335M-3001A Yoke 1335M-3002 Shaft, .375 x 3.38 1335M-3003 Shaft, .375 x 5.33 1335M-3004 Belt Cover 1335M-3005 Cylinder Mount Brkt... -
Page 64: 1335M-5000A Stripper Blade Assembly
Technical Manual & Parts Lists 1335M-5000A Stripper Blade Assembly AAC Drawing Number 192505B Rev2 QTY PART # DESCRIPTION 1335M-5001 Mounting Plate 1335M-5002 Mnt, Stripper Blade 1335M-5003B Stripper Blade 1335M-5004 Washer Plate RRBEEHIVEH Spring SSM200246 Screw, Shoulder SSM22593 Screw, Fillister Head... -
Page 65: 1335M-6000 Footlift Assembly
Manual & Parts Lists Technical 1335M-6000 Footlift Assembly AAC Drawing Number 192736C Rev1 QTY PART # DESCRIPTION 1918-073 Footlift Link 32006517 Oil Tray, Mod 32006524 Pivot Mount Brkt AA198RA508 Flow Control AAC6DP-2 Air Cylinder AAFBP-11C Pivot Brkt BBAW-5Z Rod End... -
Page 66: 1335Md-6000 Footlift Assembly
Technical Manual & Parts Lists 1335MD-6000 Footlift Assembly AAC Drawing Number 192864C Rev 3 QTY PART # DESCRIPTION 1918-073 FOOTLIFT LINK 1335M-6001 OIL PAN, MODIFIED 1335M-6002 SHAFT 32006524 BRKT, PIVOT MNT AA198RA508 FLOW CONTROL AAC6DP-2 AIR CYLINDER AAFBP-11C PIVOT BRKT... -
Page 67: 1335183 Stripper Blade
QTY PART # DESCRIPTION 1335154 PIVOT ROD, STRIP BLADE 1335475 STRIPPER BLADE-1804P 1335624 Block, Mounting 1335627 MOUNT ARM, STRIPPER BLADE 1335M-5001 PLATE,MOUNTING CCSC6F3_8 COLLAR,SET 3/8 RRBEEHIVEH SPRING,HEAVY BEEHIVE SSBC98024 10-32 X 3/8 BUTTON CAP SC SSFC01032 1/4-20 X 1/2 FLAT ALN CAP SSM200246 SCREW,SHLDR,SLT.248X.437L... -
Page 68: 1335M-9500 Stepper Box Assembly
Technical Manual & Parts Lists 1335M-9500 Stepper Box Assembly AAC Drawing Number 192710C Rev2 QTY PART # DESCRIPTION 1335M-9010 Step Box Brkt 1335M-9011 Shelf Motor Box 1335M-9012 Mnt, Ctrl Box AP-28-800C Control Box AP-28-800Y1 Stepper Box EE37F3312 Power Cord MMSLD-ECH... -
Page 69: 1335M-2100A Ruffler Cylinder Assembly
Manual & Parts Lists Technical 1335M-2100A Ruffler Cylinder Assembly AAC Drawing Number 192504B Rev5 QTY PART # DESCRIPTION 1335M-2001 Ruffler Foot Brkt 1335M-2002C Stripper Blade 1335M-2003A Cylinder Mount Plate 1335M-2033 Stop Mount 1335M-5004 Washer Plate AA198RA510 Flow Control AACMXH1025 Air Cylinder... -
Page 70: 1335M-2200 Ruffler Mounting Angle Assembly
Technical Manual & Parts Lists 1335M-2200 Ruffler Mounting Angle Assembly AAC Drawing Number 192727C Rev1 QTY PART # DESCRIPTION 1335M-2005 Mounting Angle 1335M-2017 Rod End 1335M-2027 Cylinder Mount 1335M-2028 Cylinder Support 1335M-2046 Nut Plate A-2206A Threaded Rod AA198RA510 Flow Control AAC8DP-.5... -
Page 71: 1335M-2400 Ball Screw And Nut Assembly
Manual & Parts Lists Technical 1335M-2400 Ball Screw and Nut Assembly 9000982... -
Page 72: A-2216D 1/2 Book Folder, 1/2 "Capacity
Technical Manual & Parts Lists A-2216D 1/2 Book Folder, 1/2 “Capacity AAC Drawing Number 192757C Rev0 QTY PART # DESCRIPTION 211-064 Nut Plate SSFC98064 Screw, Flat Allen A-2216B17 Plate End Assy A-2216G31 Spacer, 1/2” A-2216D02 Folder Plate A-22166D04 Folder Top A-2216D36 Guide, 7/16 A-2216G10... -
Page 73: A-2216K5/16 Flat Folder W/ Flange, 5/16 X 6" Capacity
Manual & Parts Lists Technical A-2216K5/16 Flat Folder W/ Flange, 5/16 x 6” Capacity AAC Drawing Number 192836C Rev3 QTY PART # DESCRIPTION NNW10-32 Wing Nut A-2216D22 T-Nut A-2216D53 Spacer, 1/4 A-2216G29 Spacer, 5/16 A-2216K02 Folder Plate A-2216K04 Folder Top A-2216D34 Guide, 5/16 NNK10-32... -
Page 74: A-2216L5/16 Euro Folder W/ Flange, 5/16 X 9" Capacity
Technical Manual & Parts Lists A-2216L5/16 Euro Folder W/ Flange, 5/16 x 9” Capacity AAC Drawing Number 192823C Rev3 QTY PART # DESCRIPTION NNW10-32 Wing Nut A-2216D22 T-Nut A-2216D53 Spacer, 1/4 A-2216G29 Spacer, 5/16 A-2216L02 Folder Plate A-2216L04 Folder Top A-2216D34 Guide, 5/16 NNK10-32... -
Page 75: A-2216M5 Flat Folder W/ Flange, 5/16 X 6" Capacity
Manual & Parts Lists Technical A-2216M5 Flat Folder W/ Flange, 5/16 x 6” Capacity AAC Drawing Number 192824C Rev6 QTY PART # DESCRIPTION NNW10-32 Wing Nut A-2216D22 T-Nut A-2216G29 Spacer, 5/16 A-2216M02 Folder Plate A-2216M04 Folder Top A-2216D34 Guide, 5/16 NNK10-32 Kep Nut SSBC98064... - Page 76 Technical Manual & Parts Lists...
-
Page 77: 1335105 Unwinder Assembly
1325-346 HOLDER,ROD,1/2 NNH1/4-20 1/4-20 HEX NUT 1325-346A HOLDER, ROD, 3/4" NNH3/8-16 3/8-16 HEX NUT 1335-837A ROD,1/2 DIA, NNH5/16-18 5/16-18 HEX NUT 1335M-2046 PLATE,NUT,8-32 NNJ10-32 NUT,JAM 1335M-4007 COVER, BELT NNK1/4-20 KEP NUT, 1/4-20 1347-001 EDGE GUIDE,SPLIT NNK10-32 KEP NUT, 10-32 1961-365... - Page 78 Technical Manual & Parts Lists...
-
Page 79: 1335M-4000A Unwinder Assembly
NO. QTY PART # DESCRIPTION 1325-346 Rod Holder, 1/2 NNK1/4-20 Kep Nut 1325-346A Rod Holder, 3/4 PP12LF050-3/4 Gear Pulley 1335M-4002A Shaft, 3/4 x 22 PP24LB050M3 Gear Pulley 1335M-4003A Support Brkt SSHC01048 Screw, Hex Cap TTH32415 Threaded Handle SSHC01080 Screw, Hex Cap... -
Page 80: 1335M-4200A Support Frame Assembly
Technical Manual & Parts Lists 1335M-4200A Support Frame Assembly AAC Drawing Number 192833C Rev0 QTY PART # DESCRIPTION 1325-346 Rod Holder, 1/2 1325-346A Rod Holder, 3/4 1335M-4003A Support Brkt 1335M-4201 Frame Support 265155A Eye Holder 1335-837 Rod, 1/2 U AAF1/8... -
Page 81: 1959-800 Roll Holder Assembly
Manual & Parts Lists Technical 1959-800 Roll Holder Assembly AAC Drawing Number 192739C Rev5 QTY PART # DESCRIPTION NNH1/2-13 Hex Nut 1959-802 Rod, 3/8 x 28 A-4-024 SSHC01160 Screw, Hex Cap WWL1/4 Lock Washer WWFS1/4 Flat Washer 1959-101 Rod, 1/4 x 17 1959-105 Tube Assy 1959-106B... -
Page 82: 1335M-420 Guide Roller Assembly
Technical Manual & Parts Lists 1335M-420 Guide Roller Assembly AAC Drawing Number 192832C Rev0 QTY PART # DESCRIPTION 97-1711 Tube, 3/4 x 30 8732-0576 Tube, 1/2 x 9 1335-318 Rod Slide Arm 1335-319 Rod Clamp Arm Cross Block, 1/2 28201... -
Page 83: 1335M-425 Guide Roller Assembly
Manual & Parts Lists Technical 1335M-425 Guide Roller Assembly AAC Drawing Number 192834C Rev0 QTY PART # DESCRIPTION 97-1711 Tube, 3/4 x 30 97-1711A Tube, 3/4 x 10 1335-835 Bent Rod, 1/2 x 4 x 18 8732-0576 Rod, 1/2 x 9... -
Page 84: 1335M-430 Guide Roller Assembly
Technical Manual & Parts Lists 1335M-430 Guide Roller Assembly AAC Drawing Number 192822C Rev3 QTY PART # DESCRIPTION 97-1711 Tube, 3/4 x 30 97-1711C Tube, 3/4 x 14 1335-835A Bent Rod, 1/2 x 4 x 26 8732-0576 Rod, 1/2 x 9... -
Page 85: 1278-6160E Foot Switch Assembly
Manual & Parts Lists Technical 1278-6160E Foot Switch Assembly AAC Drawing Number 192853C Rev2 QTY PART # DESCRIPTION 3’ MM6970T64 Abrasive Tape AR 3844P-119B Label NNK6-32 Kep Nut SSFC80016 Screw, Flat Allen 1278-5051B Plate 1278-6161 Foot Pedal Mod. AR 3844P-119A Label 0211-705C Cable... -
Page 86: 1337A-160 Air Table Assembly
Technical Manual & Parts Lists 1337A-160 Air Table Assembly AAC Drawing Number 1337296 Rev8 QTY. PART# DESCRIPTION 1335-159 ACCESS COVER 1337135 BLOWER ASSY 1337A-0161 ANGLE, CORNER 1337A-0163 WELDMENT, LEG, TABLE 1337A-150 AIR TABLE ASSY K-235 CONNECTOR,ROMEX,1/2" MMFB4444 FOOT, RUBBER NNH1/2-13 NUT,HEX,1/2-13 SSHC01048 1/4-20 X 3/4 HEX CAP... -
Page 87: 1335M-1005 Sit-Down Treadle Assembly
Manual & Parts Lists Technical 1335M-1005 Sit-Down Treadle Assembly AAC Drawing Number 192857C Rev1 QTY PART # DESCRIPTION 1335M-105 Treadle Brkt 160929A Show Stand Brkt K-100-30M Treadle Brace K-340 Threadle W/BRKT NNK1/4-20 Kep Nut NNC1/4-20 Cap Nut SSHC01048 Screw, Hex Cap... - Page 88 Technical Manual & Parts Lists...
-
Page 89: 1334S-01 Auto Flanging Workstation
Manual & Parts Lists Technical 1334S-01 Auto Flanging Workstation AAC Drawing Number 192761C Rev4 QTY PART # DESCRIPTION 1334-1000A Sewing Head 0411-069B Thread Break Brkt 0411-070 Clamp, Sensor Brkt 1334-1100C Folder Mount WWFS10 Flat Washer AR WW000538 Washer 1959-112 Thread Plate 1334-3011 Cable 1959-025... - Page 90 Technical Manual & Parts Lists...
-
Page 91: 1959-700A Table & Frame Assembly
Manual & Parts Lists Technical 1959-700A Table & Frame Assembly AAC Drawing Number 192766C Rev3 QTY PART # DESCRIPTION 1959-004 Table Top 1959-110 Stand 1959-120 Mount Brkt 213-005 Stop Button 26127 NNJ1/4-20 Jam Nut 4000D1-500 Control Box 4058-2 Motor PPM616 Pulley SSZH#10192 Sheet Metal Screw... - Page 92 Technical Manual & Parts Lists...
-
Page 93: 1335M-500 Control Box Assembly
Manual & Parts Lists Technical 1335M-500 Control Box Assembly AAC Drawing Number 192692C Rev9 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION MM40450010 Slide Lock FFC5.2LST1 Thumb Wheel Switches MMSLD-ECH Bumper 1335M-501 Control Box Cover FFC5S1 End Cap... -
Page 94: 1335M-113 Foot Pressure Assembly
Technical Manual & Parts Lists 1335M-113 Foot Pressure Assembly AAC Drawing Number 192700A Rev1 QTY PART # DESCRIPTION 1335M-106 Pressure Rod 1335M-107 Knob, Modified 1335M-108 Lever 1335M-112 Mount Brkt AA198RR508 Flow Control AAC7DP-.5 Air Cylinder AAFBP-11C Pivot Brkt AAFCT-7 Clevis... -
Page 95: 1335Md-10 Sewing Head Modification
Manual & Parts Lists Technical 1335MD-10 Sewing Head Modification AAC Drawing Number 192862C Rev1 QTY PART # DESCRIPTION 1335M-3009 Brkt B1122552000 Gasket SSFC90048 Screw, Flat Allen SSM50267 Screw, Fillister Head 22100-019 Sync Adapter 1278-6364 Tape Mount Disc SJUKI-481U Sewing Head... - Page 96 Technical Manual & Parts Lists...
-
Page 97: 1335Md-3000A Puller Assembly
Manual & Parts Lists Technical 1335MD-3000A Puller Assembly AAC Drawing Number 192863C Rev3 PART # DESCRIPTION 1278-7055D Prox Switch 1335M-2034 Nut Plate 1335M-3001 Roller Drive Yoke 1335M-3002 Shaft, .375 x 3.38 1335M-3003 Shaft, .375 x 5.33 1335M-3004 Belt Cover 1335M-3010... - Page 98 Technical Manual & Parts Lists...
-
Page 99: 1335M-Kit105 Tensioner Kit
Manual & Parts Lists Technical 1335M-KIT105 Tensioner Kit AAC Drawing Number 1335M-KIT105 Rev 3 QTY PART # DESCRIPTION 1335274 WASHER PLATE - PANEL TENS 1335275 TOP PLATE- PANEL TENSION 1335278 PANEL TENSION FINGER 1335280 NUT PLATE - PANEL TENSION 1335281... -
Page 100: 1335M-Pd Pneumatic Diagram
Technical Manual & Parts Lists 1335M-PD Pneumatic Diagram 125618C... -
Page 101: 1335M-Pdk5 Pneumatic Diagram
Manual & Parts Lists Technical 1335M-PDK5 Pneumatic Diagram 125669C... -
Page 102: 1959-Pd Pneumatic Diagram, Flanging Unit
Technical Manual & Parts Lists 1959-PD Pneumatic Diagram, Flanging Unit 125492C... -
Page 103: 1335M-500Wd Wiring Diagram, Control Box
Manual & Parts Lists Technical 1335M-500WD Wiring Diagram, Control Box 125615C... -
Page 104: 1335M-Wd Wiring Diagram
Technical Manual & Parts Lists 1335M-WD Wiring Diagram 125619C... -
Page 105: 1335M-01Wd Wiring Diagram
Manual & Parts Lists Technical 1335M-01WD Wiring Diagram 125629C... -
Page 106: 1334S-01Wd Wiring Diagram, Flanging Unit
Technical Manual & Parts Lists 1334S-01WD Wiring Diagram, Flanging Unit 125627C... - Page 107 Manual & Parts Lists Technical...
- Page 108 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
- Page 109 Declaración de Garantia Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero.
- Page 110 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 Printed in the USA www.atlatt.com...
