- Page 1 1345-5P Model Revision 4.2 Updated February 26, 2025 (wr) Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
- Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.
-
Page 4: Table Of Contents
Technical Manual & Parts Lists Contents Important Safety Instruction ........................0 Liability ..............................1 Safety Equipment on the Machines ......................2 Protective Eyewear ............................. 3 Important Notices............................4 Maintenance ..............................6 Repair ................................7 A Word to the End User..........................8 Safety Precautions ............................ -
Page 5: Important Safety Instruction
Technical Manual & Parts Lists Important Safety Instruction This part of the Instruction Material is provided for the safe use of your equipment. It contains important information to help work safely with the unit and describes the dangers inherent in machinery. Some of these dangers are obvious, while others are less evident. -
Page 6: Liability
Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet. -
Page 7: Safety Equipment On The Machines
Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or... -
Page 8: Protective Eyewear
Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine. -
Page 9: Important Notices
Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated. -
Page 10: Transport Damage
Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information. -
Page 11: Maintenance
Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine. -
Page 12: Repair
Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts. -
Page 13: A Word To The End User
Technical Manual & Parts Lists A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines. -
Page 14: Machine Specifications
Technical Manual & Parts Lists Machine Specifications... -
Page 15: Motor Parameter Settings
Technical Manual & Parts Lists Motor Parameter Settings There are two models of Efka controllers. The older FP220 had a three digit display. The newer AB221 has a four-digit display. Depending on the Efka Controller model, different instructions apply. Instructions for the FP220 with three digit display When replacing or installing a new Efka Controller, perform a master reset of the parameters using the following instructions. -
Page 16: Instructions For The Ab221 With Four Digit Display
Technical Manual & Parts Lists Parameter 702 sets the deceleration speed step in RPM / sec which controls the slowdown of the motor independent of how fast the knee pad is pushed in. Min is 1000, max is 9990, default is 9990 (999 displayed). Parameter 703 sets the max normal corner carriage speed in RPM. - Page 17 Technical Manual & Parts Lists Parameter 111 sets the max straight sew head speed in RPM. Min is 200, max is 9900, default is 3000. Parameter 701 sets the acceleration speed step in RPM / sec which limits the speed up of the sew motor independent of how fast the knee pad is let out.
-
Page 18: Gear Box Maintenance
Technical Manual & Parts Lists Gear Box Maintenance 1) Frequently check the oil level of the reducer. If oil level is low, add proper lubrication until it comes out the oil level check. 2) Inspect vent plug often to insure it is clean and operating. 3) Always check proper oil level. -
Page 19: Assembly / Adjustment Instructions
Technical Manual & Parts Lists Assembly / Adjustment Instructions 1. Position the column assy (item A) with the lower edge below the bottom of the slide support bracket (item B). DO NOT ADJUST WITHT THE COLUMN OR TABLE IN THE "UP"... -
Page 20: Assembly Drawings & Parts Lists
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or... -
Page 21: 11345-5P Tape Edge Machine
Technical Manual & Parts Lists 11345-5P Tape Edge Machine AAC Drawing Number 9004204 Rev 0 QTY PART# DESCRIPTION QTY PART# DESCRIPTION 311-129 SLEEVE TAPE 134553000A CARRIAGE 1345-5WD1 DIAGRAM MMCCF3/4SB FOLLOWER HEAD,MOD,GE 1345LAB2 LABEL,TABLE SPF5625-657-02M N,TAPE 1/4-20 X 3/4 1345152 SUPPORT SSHC01048GR8 HEX CAP 4-40 X 5/8,... -
Page 22: 13452500A Table Assembly
Technical Manual & Parts Lists 13452500A Table Assembly AAC Drawing Number 9001366 Rev 11 QTY PART # DESCRIPTION 13451000 BASE ASSY LIFT TABLE TAPE 13451200 TABLE TOP ASSY,QUEEN 13452000D COLUMN, LIFT ASSY 13452027 LINK, CABLE ASSY,TWIN BBTRA613 WASHER,THRUST,STL, .375B NNJ5/16-18 NUT,JAM,5/16-18 PPP2217 WIRE CLAMP, .337I.D. -
Page 23: 13451000 Table Base Assembly
Technical Manual & Parts Lists 13451000 Table Base Assembly AAC Drawing Number 9001365 Rev 7 QTY PART # DESCRIPTION 0411-1063 ROD, THREADED, 5/8-11 X 5 1345027 FRAME, WELDMENT TAPE EDGE 13451019 GEAR RACK, SHORT 13451020 GEAR RACK, LONG 13451021 GEAR RACK, CORNER 13451029 PAD, RUBBER 13459500... -
Page 24: 13453800 Gear Lock Assembly
Technical Manual & Parts Lists 13453800 Gear Lock Assembly AAC Drawing Number 9001130 Rev 1 QTY PART # DESCRIPTION 13453801 SUPPORT GEAR LOCK ASSY. IIS012X096 SPRING PIN, 3/16X1.5 MM61095K53 KNOB, BALL,3/8-16 TAP RRLC0742HJ SPRING, COMP. .072X.66X3 13453804 MANDREL,GEAR LOCK... - Page 25 Technical Manual & Parts Lists...
-
Page 26: 13459500 Control Box
Technical Manual & Parts Lists 13459500 Control Box AAC Drawing Number 9001947 Rev 1 PART# DESCRIPTION 13459004A MOUNTING BRACKET, CAPACIT 13459501 PANEL,HIGH VOLTAGE 13459503 COVER, ELECTRICAL PANEL 40-322 BOTTOM, AC POWER LOCKOUT 40-323 TOP, AC POWER LOCKOUT EEAK42BS RIVET, BLIND 1/8 DIA ALUM. EECA491024 CONTACTOR, MINI, 240V EECLIPFIX... - Page 27 Technical Manual & Parts Lists...
-
Page 28: 13452000D Column Lift Assembly
Technical Manual & Parts Lists 13452000D Column Lift Assembly AAC Drawing Number 9002809 Rev 4 ITEM NO. QTY. PART NUMBER DESCRIPTION 1345093 BKT,EDGE GUIDE 1345130 TOP MOD.,SLIP RING 1345131 PLATE,SLIDE, ADJ 1345132 BAR, BRACE,.25 THK 1345134 SPACER,COLUMN CONCAVE 1345135 PLATE, SLIDE 1345136 BKT,LOW ER GIB STOP 1345231... - Page 29 Technical Manual & Parts Lists...
-
Page 30: 134553000A Carriage Assembly
Technical Manual & Parts Lists 134553000A Carriage Assembly AAC Drawing Number 9001641 Rev 6... - Page 31 Technical Manual & Parts Lists...
-
Page 32: 134533300A Top Carriage Assembly
Technical Manual & Parts Lists 134533300A Top Carriage Assembly AAC Drawing Number 9001479 Rev 17 ITEM PART ITEM PART DESCRIPTION DESCRIPTION NUMBER NUMBER 029-003A PLATE, NUT, 1/4-20 @ 1.50 FFUZP101 PROX. SWITCH 0211-209 PLATE,NUT,10-32@2.25 CTC K-235 CONNECTOR,ROMEX,1/2" 1961-126 PLATE, NUT, 6-32, 1PL MM9307K69 GROMMET,5/8,1.125,.125GV 1975-412A... - Page 33 Technical Manual & Parts Lists...
-
Page 34: 1345100 Knee Switch Assembly
Technical Manual & Parts Lists 1345100 Knee Switch Assembly AAC Drawing Number 1345100 Rev 5 QTY PART # DESCRIPTION 1345101 PLATE,TRANSDUCER END 1345102 MOUNT, TRANSDUCER 1345103 PLATE,SPRING,TRANSDUCER 1345104 CLAMP,TRANSDUCER 13453306 BLOCK,RAIL STOP 13453309 RAIL BKT ASBLY 13453337 BRACKET,RAIL SUPPORT 13453361 BRKT, SPRING TENSION FF002304A LINEAR TRANSDUCER ASBY... - Page 35 Technical Manual & Parts Lists...
-
Page 36: 13453400A Carriage Guide Assembly
Technical Manual & Parts Lists 13453400A Carriage Guide Assembly AAC Drawing Number 9001193 Rev 6 QTY PART # DESCRIPTION 13453401A CARRIAGE GUIDE FRAME ASSY 13453404 ROLLER YOKE ASSY 13453408 GUIDE ARM ASSY. 13453411 STUD, ROLLER BEARING 13453413 ROLLER, GUIDE 13453414 HUB, ROLLER GUIDE 13453415 PLATE, CABLE HOLDER... - Page 37 Technical Manual & Parts Lists...
-
Page 38: 134539000B Control Box Assembly
Technical Manual & Parts Lists 134539000B Control Box Assembly AAC Drawing Number 9001397 Rev 3 PART# DESCRIPTION 1345-5WD1 DIAGRAM, WIRING 1345LAB1 LABEL 13459001B SUB PANEL, CARRIAGE -3&4B 13459004A MOUNTING BRACKET, CAPACIT 13459006 CONTROL BOX 11345 AAF3/16 CLAMP, BLACK PLASTIC FF1N4937 DIODE,FAST 200NS,1A FF264-341 TERMBLK,WAGO,TOP,DUAL,GRY... - Page 39 Technical Manual & Parts Lists...
-
Page 40: 13453500E Gear Box Assembly
Technical Manual & Parts Lists 13453500E Gear Box Assembly AAC Drawing Number 9003675 Rev 0... - Page 41 Technical Manual & Parts Lists...
-
Page 42: Spf5625-657-02M Sewing Head
Technical Manual & Parts Lists SPF5625-657-02M Sewing Head AAC Drawing Number 9002943 Rev 4 NO QTY PART # DESCRIPTION 1* 91-149-219- FOOT,PRESSER,LI FTI NG,MOD 311-129 SLEEVE TAPE MOUNT ADJUST 1278-7055D PROX SWI TCH W/PLUG,12" 1345-004 BLOCK, STOP FOR BI NDER 1345-009B SLEEVE,.25 ODX.19 I DX.5LS 1345-025... -
Page 43: Spf5625-65702A Head, Pfaff Tape Edge
Technical Manual & Parts Lists SPF5625-65702A Head, Pfaff Tape Edge AAC Drawing Number 9004887 Rev 1 NO QTY PART # DESCRIPTION 91-149-219-91M1 FOOT,PRESSER,LI FTI NG,MOD 1345-004 BLOCK, STOP FOR BI NDER 1345-009B SLEEVE,.25 ODX.19 I DX.5LS 1345142 PLATE,ADAPTER,SWI NG OUT 1345147 PLATE,TOP MOD. -
Page 44: 134539300A Control Button Panel
Technical Manual & Parts Lists 134539300A Control Button Panel AAC Drawing Number 9001396 Rev 2 QTY PART # DESCRIPTION 13453LAB1 LABEL,SWITCH PANEL 13459008A CABLE, POT, IK, 4 FT. 13459301E PANEL, CONTROL BUTTON 2 EE15Y PLATE, LEGEND, YELLOW EE3X01 BLOCK,P.B. CONTACT, N.C. EE3X10 BLOCK,P.B. -
Page 45: 1345-5Wd1 Wiring Diagram
Technical Manual & Parts Lists 1345-5WD1 Wiring Diagram... - Page 46 Technical Manual & Parts Lists...
-
Page 47: Terms And Conditions
Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months. -
Page 48: Declaración De Garantía
Declaración de Garantía Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero. - Page 49 Technical Manual & Parts Lists Atlanta Attachment Company Printed in the USA 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 www.atlatt.com...
