- Page 1 Model 1347MTA Revision 1.2 Updated Julio 17, 2016 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
- Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.
-
Page 4: Table Of Contents
Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Liability ..............................2 Safety Equipment on the Machines ......................3 Protective Eyewear ............................. 4 Important Notices............................5 Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................ -
Page 5: Important Safety Instruction
Mandatory Information All persons operating and/or working on the 1347MTA should read and understand all parts of the Safety Instructions. This applies, in particular, for persons who only operate and/or work on the unit occasionally (e.g. for maintenance and repair). Persons who have difficulty reading must receive particularly thorough instruction. -
Page 6: Liability
Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet. -
Page 7: Safety Equipment On The Machines
Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or... -
Page 8: Protective Eyewear
Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine. -
Page 9: Important Notices
Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated. - Page 10 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.
-
Page 11: Maintenance
Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine. -
Page 12: Repair
Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts. -
Page 13: A Word To The End User
Technical Manual & Parts Lists Starting Machine Movements Read the Instruction Manual carefully to establish which keys and functions start machine movements. A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines. - Page 14 Technical Manual & Parts Lists...
-
Page 15: Assembly Drawings & Parts Lists
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or... - Page 16 Technical Manual & Parts Lists...
-
Page 17: 11347Ma Auto Faux Hemmer, Single Hem
AAC Drawing Number 9004675 Rev 1 NO QTY PART # DESCRIPTION 273-4-405 ROD, STRAIGHT, CRS, 18"LG AR 1347MA-PD PNEUMATIC DRAWING AR 1347MA-WD WIRING DIAGRAM 28201 BLOCK,CROSS,(LARGE) 1330200 REWINDER W/MOUNTING ASSY 1347399 DUAL ROLL HOLDER ASSY 1347468 UNFOLDER ASSY 1347MA 1347554 PREFOLD ASSEMBLY 1347684 WORK STATION,1347MTA... - Page 18 Technical Manual & Parts Lists...
-
Page 19: 1330200 Rewinder1962- W/ Mounting Assembly
Technical Manual & Parts Lists 1330200 Rewinder1962- w/ Mounting Assembly AAC Drawing Number 1330200 Rev 4 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 1961-319 PLATE,NUT,3/8-16@3.00 CTC MM132-1496 PLUG 1 X 2 1961-321 PLATE, ADAPTOR, AIR MM9565K56 PLUG,BLACK, 2" SQ 1961-331 MOUNT, MOTOR MM9600K21... - Page 20 Technical Manual & Parts Lists...
-
Page 21: 1347399 Dual Roll Holder Assy
Technical Manual & Parts Lists 1347399 Dual Roll Holder Assy. AAC Drawing Number 1347399 Rev 0 NO QTY PART # DESCRIPTION 784B-2432 PLATE, ALU 1961-204 ROLLER,15.5L,2 OD,.75 ID 1961-253 HUB, UNWIND STAND 1961-253A HUB, UNWIND STAND 1961-254 DISC 32 DIA. 1961-255 BRACKET, SENSOR MTG 1961-258... -
Page 22: 1347684 Work Station, 1347 Mta
Technical Manual & Parts Lists 1347684 Work Station, 1347 MTA AAC Drawing Number 1347684 Rev 0 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 0411-069B BRKT, THREAD BREAK DETECT 26151 TOOL TRAY, 1X3.5X9 0411-070 CLAMP, SENSOR BRACKET 4003-IS3WT2 SENSOR,THREAD BREAK 1000-6 TENSIO ASBLY, TABLETOP... -
Page 23: 1000-6 Tension Assy, Tabletop
Technical Manual & Parts Lists 1000-6 Tension Assy, Tabletop AAC Drawing Number 9001467 Rev 0 PART # DESCRIPTION 1000 TABLE TOP TENSION 1000500 BRACKET, TENSION MOUNT NNE8-32 NUT,ELASTIC LOCK, 8-32 SSPP90032 SCREW,8-32 PAN HD PHIL WWF8 WASHER, FLAT, #8... - Page 24 Technical Manual & Parts Lists...
-
Page 25: 1347464 Work Station
Technical Manual & Parts Lists 1347464 Work Station AAC Drawing Number 1347464 Rev 5 QTY PART # DESCRIPTION 0411-069B BRKT, THREAD BREAK DETECT 0411-070 CLAMP, SENSOR BRACKET 1000-6 TENSIO ASBLY, TABLETOP 26151 TOOL TRAY, 1X3.5X9 1347364 SEWING HEAD DETAIL 1347400 TABLE &... - Page 26 Technical Manual & Parts Lists...
-
Page 27: 1347685 Sewing Head Assy
Technical Manual & Parts Lists 1347685 Sewing Head Assy. AAC Drawing Number 1347685 Rev 1 NO QTY PART # DESCRIPTION *1 321KIT01 OIL WICK KIT 1888N12S01 FEED DOG 1N 1889N13000 THROAT PLATE, 1 NDL 1325151 NEEDLE CHUCK, 1N, TYP 3300015 PRESSER BER, 1804 YAMATO 4600173 BRKT, PRESSER FOOT... - Page 28 Technical Manual & Parts Lists...
-
Page 29: 1347400 Table Stand Assemblies
Technical Manual & Parts Lists 1347400 Table Stand Assemblies AAC Drawing Number 1347680 Rev 2 NO QTY PART # DESCRIPTION 1278-6161 FOOT SWI TCH MODI FI CATI ON 1335244 ROD THRD,5/16-18 X 8.75 1347683 LOWER TABLE SUPPORT ANG. AR 1347MA-PD PNEUMATI C DI AGRAM AR 1347MA-WD WI RI NG DI AGRAM... - Page 30 Technical Manual & Parts Lists...
-
Page 31: 1347414 Single Fold Modular Hemmer
Technical Manual & Parts Lists 1347414 Single Fold Modular Hemmer AAC Drawing Number 1347414 Rev 6 PART# DESCRIPTION 1278-6206 BLOCK BASE ASSEMBLY 1347416 EDGE GUIDE,END PLATE 1347420 GUIDE ASSY,FOLDER 1347422 FOLDER,FABRIC GUIDE 1347424 FOLDER TONGUE ASSY 1347430 ROD,S/S,1/2X22.0 1347433 ROD, BENT, 90 DEG 1347441 HEM GUIDE 1347539... -
Page 32: 1347443 Flanger Assembly
Technical Manual & Parts Lists 1347443 Flanger Assembly AAC Drawing Number 1347443 Rev 4 QTY PART # DESCRIPTION 1278-6206 BLOCK BASE ASSEMBLY 1335-320B ROD, ST, S/S, 11" L 1347457 FLANGER WELDMENT 1347466 ROD,BENT,SS,.5X9X5 1959-035 ROD, BENT, 90 DEG 23080A BLOCK,CLAMP,EYE 28201 BLOCK,CROSS,(LARGE) ROD CROSS BLOCK... - Page 33 Technical Manual & Parts Lists...
-
Page 34: 1347462 Swing Out Binder Assembly
Technical Manual & Parts Lists 1347462 Swing out Binder Assembly AAC Drawing Number 1347462 Rev 2 NO QTY PART # DESCRIPTION 1347022 GUIDE CLAMP 1347361 MOUNT,BLOCK BINDER 1347459 BINDER PREFOLD BAR 1347460 PREFOLD BINDER BRACKET IID016X160 DOWEL PIN,1/4 X 2-1/2 SSAS016176 SHLDR SCR,1/4X2-3/4,SS SSPS80016 #6-32 X 1/4 LG PAN HD... -
Page 35: 213-005Y Button Assembly
Technical Manual & Parts Lists 213-005Y Button Assembly AAC Drawing Number 290017A Rev 0 QTY PART # DESCRIPTION EE800FMLMP40E3 Push Button EE3X01 Switch, N.C. SPST EE3X10 Switch, N.O. SPST 350-12154 Bracket EEA3L Mounting Latch... -
Page 36: 1347468 Unfolder Assembly
Technical Manual & Parts Lists 1347468 Unfolder Assembly AAC Drawing Number 1347468 Rev 1 PART# DESCRIPTION 11-7080 ROD, STRAIGHT, CRS,1/2 28201 BLOCK,CROSS,(LARGE) 1347467 ROD,BENT,3/8,SS,12X18... -
Page 37: 1347554 Prefold Assembly
Technical Manual & Parts Lists 1347554 Prefold Assembly AAC Drawing Number 1347554 Rev 0 QTY PART # DESCRIPTION 1330217 SPACER, FOLDER 1330219 PLATE,NUT,10-32 X 2 1330221 PLATE,WASHER,#10 X 2 1347553 PREFOLD SCROLL 311-154 MACHINE MOUNT,1/2" HOLE NNK8-32 NUT,KEP,8-32 SST098032 SCREW,THUMB,10-32 X 1/2 TTH32425 HANDLE,THRDED,5/16-18X3/4... -
Page 38: 4000D-500 Control Box, 4000D
Technical Manual & Parts Lists 4000D-500 CONTROL BOX, 4000D AAC Drawing Number 9005195 Rev 2 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 4000D-01 BOX BOTTOM,PLAIN FF700-FEA3TU23 RELAY,TIMER,DIN,ON DELAY 4000D-02 PC BOARD, RELAY FFGFTS-4 BLOCK,4 POLE TERMINAL 4000D-WD4 WIRING DIAGRAM, W/TIMER FFLEDG24V LED,GREEN,24VDC... -
Page 39: 1347Ma-Pd Pneumatic Diagram
Technical Manual & Parts Lists 1347MA-PD Pneumatic Diagram 125296B... -
Page 40: 1347Ma-Wd Wiring Diagram
Technical Manual & Parts Lists 1347MA-WD Wiring Diagram 125297B... - Page 41 Technical Manual & Parts Lists...
- Page 42 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
- Page 43 Declaración de Garantía Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de material y de mano de obra durante un período de ochocientos (800) horas de operación o cien (100) días, cual llegue primero.
- Page 44 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 www.atlatt.com Printed in the USA...
