Technical Manual & Parts Lists
1315A
Model
Revision 3.1
Updated
Atlanta Attachment Company
362 Industrial Park Drive
Lawrenceville, GA 30046
770-963-7369 • www.atlatt.com
Aug 29, 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1315A and is the answer not in the manual?

Questions and answers

Related Manuals for Atlanta Attachment Company 1315A

Summary of Contents for Atlanta Attachment Company 1315A

  • Page 1 1315A Model Revision 3.1 Updated Aug 29, 2012 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
  • Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.

  • Page 4: Table Of Contents

    Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Liability ..............................2 Safety Equipment on the Machines ......................3 Protective Eyewear ............................. 4 Important Notices............................5 Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................
  • Page 5 Technical Manual & Parts Lists To Oil the Bed Shaft ..........................25 Other Oiling Points ........................... 25 Caution: ..............................25 Setting the Needle ............................. 26 Threading the Machine ..........................27 Tension ..............................28 Needle Thread Tension ..........................28 Looper Thread Tension ..........................28 Pressure ..............................
  • Page 6 1315483 Air Jet Assembly; (Left Side) ....................87 1315498 Push Plate Assembly ........................89 1315502 Table Assembly ......................... 91 1315560 Control Box Assembly ....................... 93 1315603 Sensor Bracket Assembly ......................94 1315610 Touch Screen Assembly ......................95 1315A-PD Pneumatic Diagram ........................ 96 1315A-WD Wiring Diagram ........................97...

  • Page 7: Important Safety Instruction

    Technical Manual & Parts Lists Important Safety Instruction This part of the Instruction Material is provided for the safe use of your equipment. It contains important information to help work safely with the unit and describes the dangers inherent in machinery. Some of these dangers are obvious, while others are less evident.

  • Page 8: Liability

    Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet.

  • Page 9: Safety Equipment On The Machines

    Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or...

  • Page 10: Protective Eyewear

    Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine.

  • Page 11: Important Notices

    Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated.
  • Page 12 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.

  • Page 13: Maintenance

    Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine.

  • Page 14: Repair

    Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts.

  • Page 15: A Word To The End User

    Technical Manual & Parts Lists A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines.

  • Page 16: Component Identification

    Technical Manual & Parts Lists Component Identification...

  • Page 17: General Machine Data

    Technical Manual & Parts Lists General Machine Data Electrical & Pneumatic Specifications Electrical: 220 VAC, 5amp, 50/60 Hz Single Phase Main Air - 80 PSI, 5 SCFM avg. (3/8” supply line) Pneumatic: Belt Tension - 40-50 PSI Sewing Head: Singer 300UX5 Sewing Speed: 3000 RPM Needle (Standard):...
  • Page 18 Technical Manual & Parts Lists corner sewing. This setting ensures that the mattress is tight against the Backstop before the mattress is rotated. After the Edge To Corner Stitch Count is reached, the head switches to a corner sew speed (low), the conveyor moves forward at low speed and the Rotate arm turns on in a forward medium speed.
  • Page 19 Technical Manual & Parts Lists After the flip cycle has been completed the operator uses the High Speed Sew pedal to bring the mattress back to the middle of the conveyor. If the Mattress Flip Location setting is set to "0" the conveyor pedal will move the conveyor in the forward direction or if the setting is set to "1"...

  • Page 20: Efka Control Box

    The functions can be changed upon power up or after a full heal back. The control box has been programmed to operate specifically with the 1315A unit. If the box is later replaced, the new box will need to be programmed according to the included parameter list in order to function properly.

  • Page 21: Electric Eye Sensor Adjustment

    Technical Manual & Parts Lists Electric Eye Sensor Adjustment To adjust the sensor, first remove the clear plastic cover from the end of the sensor. There are two adjusting screws under the cover. One is labeled “GAIN” and is used to set the sensitivity of the sensor.

  • Page 22: Efka Parameter Settings (Sewing Head Motor)

    Technical Manual & Parts Lists Efka Parameter Settings (Sewing Head Motor) Programming Instructions Power on holding down the “P” button until “COD” is displayed. Press “>>” once and enter the number “311” Press “E” once and “2.0.0” is displayed. This is a parameter. Proceed to the parameter to be changed and press “E”.

  • Page 23: Programming Actech Scl/Scm Drive

    Technical Manual & Parts Lists Programming ACTech SCL/SCM Drive The drive is already programmed** with settings specifically for the 1315A unit by Atlanta Attachment Co. These settings are listed in the chart on the following page. Password protection is currently disabled so that control of the parameters is immediately available to the user.

  • Page 24: Conveyor Motor Parameter Menu

    Technical Manual & Parts Lists Conveyor Motor Parameter Menu AAC custom setting shown in last column. FACTORY PARAMETER NAME RANGE OF ADJUSTMENT DEFAULT SETTINGS LINE VOLTAGE HIGH (01), LOW (02) HIGH (01) CARRIER FREQUENCY 4kHz (01), 6 kHz (02), 8 kHz (03), 10 kHz (04) 6 kHz (02) NORMAL (01), START ON POWER UP (02), START WITH DC BRAKE (03),...
  • Page 25 Technical Manual & Parts Lists FACTORY PARAMETER NAME RANGE OF ADJUSTMENT DEFAULT SETTINGS FORWARD ONLY (01), FORWARD ONLY ROTATION FORWARD AND REVERSE (02) (01) ACCELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC DECELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC DC BRAKE TIME 0.0 - 3600.0 SEC 0.0 SEC...

  • Page 26: Rotate Arm Motor Parameter Menu

    Technical Manual & Parts Lists Rotate Arm Motor Parameter Menu AAC custom setting shown in last column. FACTORY PARAMETER NAME RANGE OF ADJUSTMENT DEFAULT SETTINGS LINE VOLTAGE HIGH (01), LOW (02) HIGH (01) CARRIER FREQUENCY 4kHz (01), 6 kHz (02), 8 kHz (03), 10 kHz (04) 6 kHz (02) NORMAL (01), START ON POWERUP(02 START WITH DC BRAKE (03),...
  • Page 27 Technical Manual & Parts Lists FACTORY PARAMETER NAME RANGE OF ADJUSTMENT DEFAULT SETTINGS FORWARD ONLY (01),FORWARD AND FORWARD ONLY ROTATION REVERSE (02) (01) ACCELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC DECELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC DC BRAKE TIME 0.0 - 3600.0 SEC 0.0 SEC DC BRAKE VOLTAGE...

  • Page 28: Speed Setting Controls

    Technical Manual & Parts Lists Speed Setting Controls Use the information below to help select which electrical component to adjust in order to synchronize the following sewing speeds. Side Sewing Speed Controls Sewing head - Side speed pot located on the sewing head console Conveyor Conveyor speed pot located on the sewing head console Corner Sewing Speed Controls...

  • Page 29: Conveyor Belt Tracking Instructions

    Technical Manual & Parts Lists Conveyor Belt Tracking Instructions Turn off the air pressure before making any adjustments. The first step is to make sure the upper conveyor drive roller is perpendicular to the frame. The motor mounted end of the roller is fixed so this is your starting point. The other end of the roller should be adjusted in or out until it is in the same relationship to the frame as the motor mounted end.

  • Page 30: Servicing The Sew Head

    Technical Manual & Parts Lists Servicing the Sew Head Installation Assemble the oil pan to the hangers. Insert the assembled oil pan into the machine cut-out table placing four rubber bushings in the hanger holes as shown in Fig. 1. Attach the oil drain jar to the oil pan as shown in Fig.

  • Page 31: Lubrication

    Technical Manual & Parts Lists Lubrication Machines of Class 300U have a semi-automatic lubricating system comprising of a hollow arm shaft and a hollow bed shaft which act as oil reservoirs. The oil is distributed to all of the principal bearings by centrifugal force through small jets in the shafts when the machine is in operation.

  • Page 32: Setting The Needle

    Technical Manual & Parts Lists Setting the Needle Refer to Fig. 6. Turn the machine pulley over toward the operator until the needle bar is at its highest point. Loosen the needle set screw. Insert the needle into the needle bar and clamp as far as it will go making certain that the scarf of the needle faces toward the left.

  • Page 33: Threading The Machine

    Technical Manual & Parts Lists Threading the Machine Either left twist or right twist thread may be used in the needles and loopers. Rough or uneven thread, or thread which passes through the needle eye with difficulty will interfere with successful operation of the machine.

  • Page 34: Tension

    Technical Manual & Parts Lists Tension Tension on the thread should be as light as possible while still sufficient to set the stitch correctly in material. Needle Thread Tension To regulate the needle thread tension, turn the thumb screw indicated in Fig. 8 as may be required. Important: Regulate the needle thread tension only when the presser foot is down.

  • Page 35: Alternating Presser With Pneumatic Pressure Control

    Technical Manual & Parts Lists Alternating Presser with Pneumatic Pressure Control Adjust the height of the Pressure Cylinder with the presser feet resting on the throat plate. There should be a clearance of 1/4” between the Presser Bar Spring Fork and bottom of the cylinder. To raise the cylinder, loosen the lower lock nut and tighten upper lock nut, see Fig.

  • Page 36: Machine With Puller Feed

    Technical Manual & Parts Lists Machine with Puller Feed The length of the stitch is determined by the stitch gears in the puller feed mechanism. The compound feed stitch length should be set slightly shorter than the stitch length of the puller feed. To change the Puller Feed gears for adjusting stitch length, remove the two cover plate screws and remove the cover plate, Fig.

  • Page 37: Machines With Alternating Pressers

    Technical Manual & Parts Lists Machines with Alternating Pressers The lift of the vibrating and lifting pressers is controlled by an adjustable eccentric. To adjust, remove the arm cover at the rear of the machine. Turn the machine pulley over toward the operator until the feeding presser is down.

  • Page 38: Setting The Height Of Feed Bar

    Technical Manual & Parts Lists Setting the Height of Feed Bar When the feed bar is set at the correct height, the feed lift link clamp will be aligned with the rock shaft timing flat. To adjust, make certain that the feed lifting crank timing screw, Fig. 19, engages the shaft spot correctly.

  • Page 39: Timing The Feed Lift Eccentric

    Technical Manual & Parts Lists Timing the Feed Lift Eccentric When the feed dog is at its highest position, the top of the teeth should be parallel with, and project full depth of the teeth above the upper surface of the throat plate. To adjust, insert screwdriver in the hole in the feed strap and loosen the two set screws, Fig.

  • Page 40: Setting The Distance From The Looper To The Needle

    Technical Manual & Parts Lists Setting the Distance from the Looper to the Needle Sidewise Setting When the looper is correctly positioned, the point of the looper just clears the scarf of the needle on the forward stroke of the looper. To adjust, turn the machine pulley until the looper point is directly opposite of the center of the needle.

  • Page 41: Timing Looper Driving Crank

    Technical Manual & Parts Lists Timing Looper Driving Crank When the looper driving crank is properly timed, the point of the looper will pass above the eye of the needle at the same distance on both the forward and backward strokes of the looper. To adjust when the point of the looper passes higher on the forward stroke, loosen the looper driving crank set screw, Fig.

  • Page 42: Positioning Spreader

    Technical Manual & Parts Lists Positioning Spreader Fig 32 Fig 31 Sidewise and Height Setting When the looper on its forward stroke is passing the spreader a) The point of the spreader should be exactly opposite the top of the thread groove at the left side of the looper.

  • Page 43: Adjusting Needle Thread Tension Releaser

    Technical Manual & Parts Lists Adjusting Needle Thread Take-Up Fig 34 The needle thread take-up and thread guide may be adjusted to increase or decrease the amount of thread drawn at the top of the needle bar stroke. To increase the amount, loosen the thread take-up screw, Fig.
  • Page 44 Technical Manual & Parts Lists...

  • Page 45: Singer® 300Ux6 Assembly Drawings & Parts Lists

    Technical Manual & Parts Lists Singer® 300UX6 Assembly Drawings & Parts Lists Atlanta Attachment Company is the exclusive stocking distributor for Singer Tape Edge Sewing Heads and recommended spare parts for Singer Tape Edge machines. We can also supply proprietary parts in most cases for Cash*, Spuhl*, Porter, United* Tape Edge workstations.
  • Page 46 Technical Manual & Parts Lists...

  • Page 47: Upper Shaft Assembly

    Technical Manual & Parts Lists Upper Shaft Assembly NO. PART # DESCRIPTION NO. PART # DESCRIPTION 32 415077 415138 CRANK, NEEDLE BAR LIFTING ECC FLANGE 32848 BEARING 33 374098 SCREW 2812239 NEEDLE BAR CRANK COMPLETE 34 415081 ECCENTRIC COMP 549024 SCREW 35 268491 LIFTING ECCENTRIC...
  • Page 48 Technical Manual & Parts Lists...

  • Page 49: Front Assembly Sewing Arm

    Technical Manual & Parts Lists Front Assembly Sewing Arm NO. PART # DESCRIPTION NO. PART # DESCRIPTION 25 414545 267617 LINK HINGE PIN SET SCREW 268258 PACKING WICK 26 267657 VIB PRESSER BAR 267627 LIFTING LINK 27 267658 VIBRATING PRESSER BAR HINGE ST 415061 LIFTING CRANK 28 281912...
  • Page 50 Technical Manual & Parts Lists...

  • Page 51: External Parts Sewing Arm #1

    Technical Manual & Parts Lists External Parts Sewing Arm #1 NO. PART # DESCRIPTION 32788 ROCK SHAFT 32788 ROCK SHAFT 32789 ROCK SHAFT 548035 141424 SCREW 267110 NEEDLE BEARING,GBH-78 415065 COLLAR COMP 504020 SCREW (300UX5) 415069 CONN CRANK 414509 SCREW 374362 SUBSTITUTION REQUIRED 267617...
  • Page 52 Technical Manual & Parts Lists...

  • Page 53: Lower Shaft Assembly

    Technical Manual & Parts Lists Lower Shaft Assembly NO. PART # DESCRIPTION NO. PART # DESCRIPTION 34 541197 415176 DRIVE CRANK 374099 SCREW 35 545297 SCREW 500264833 LOOPER DRIVING CRANK SET SCREW 36 415082 ECCENTRIC COMP 268102 COVER, OIL HOLE 37 415073 FEED DRIVING ECC FLANGE 414563...
  • Page 54 Technical Manual & Parts Lists...

  • Page 55: Front Assembly Sewing Bed

    Technical Manual & Parts Lists Front Assembly Sewing Bed NO. PART # DESCRIPTION NO. PART # DESCRIPTION 28 281208 559061 FEED DOG LOOPER COMPLETE WITH GUARD 267665 LOOP DEFLECTOR 29 268382 LOOPER ONLY (ORDER 281207 FOR 412176 LINK, CONN CRANK 30 281207 NEEDLE GUARD 559064...
  • Page 56 Technical Manual & Parts Lists...

  • Page 57: Cross Shaft In Sewing Bed

    Technical Manual & Parts Lists Cross Shaft in Sewing Bed NO. PART # DESCRIPTION 281975 SPREADER 268162 SPREADER POINT 414552 SCREW 547670 WASHER 415196 SPREADER HOLDER 414529 SCREW 268184 SPREADER BAR BRACKET 414524 SCREW 559065 SPREADER BAR 268190 SPREADER DRIVE PIN 415297 BUSHING 415389...
  • Page 58 Technical Manual & Parts Lists...

  • Page 59: External Parts Sewing Arm #2

    Technical Manual & Parts Lists External Parts Sewing Arm #2 NO. PART # DESCRIPTION KE0085 FOOT LIFTER LEVER 201363 SCREW 300W 267707 RELEASING PLATE 543850001 PLATE PIN 414577 HINGE SCREW 543804004 WASHER 541166003 204348 SWITCH SPRING 414570 SCREW 544336 STUD SCREW 267704 LIFTER LEVER ROD 248423...
  • Page 60 Technical Manual & Parts Lists...

  • Page 61: External Parts Sewing Arm #3

    Technical Manual & Parts Lists External Parts Sewing Arm #3 NO. PART # DESCRIPTION 268506 TH GUIDE BRACKET 268111 LOOPER BRACKET 268505 LOOPER TH GUIDE 50169 SCREW (5) 414537 SCREW 544875 PLUG 267971 THREAD TENSION HA046072 TENSION DICS 32572 TENSION DISC (5) 59538 SPRING BUSHING 131741...
  • Page 62 Technical Manual & Parts Lists...

  • Page 63: External Parts Sewing Arm #4

    Technical Manual & Parts Lists External Parts Sewing Arm #4 NO. PART # DESCRIPTION KE0021 FACE PLATE (WITH 268033) 268330 FACE PLATE HINGE STUD 544053 SET SCREW 268033 LOCK STUD 228661 COVER CUSHION 268032 LOCK SPRING 415016 SPRING PLATE 414534 SCREW KE0072 ARM SIDE COVER...
  • Page 64 Technical Manual & Parts Lists...

  • Page 65: External Parts Sewing Arm #5

    Technical Manual & Parts Lists External Parts Sewing Arm #5 NO. PART # DESCRIPTION KE0073 BED PLATE (RIGHT) 414508 SCREW KE0037 BED PLATE (LEFT) 559060 THROAT PLATE 374107001 THROAT PLATE SCREW (BACK) 200100 SCREW KE0075 FEED REGULATING STUD SOCKET 268081 STUD, FEED REG 270026 FEED REG STUD SPR...
  • Page 66 Technical Manual & Parts Lists Accessories NO. PART NO. DESCRIPTION 170 415377 THREADER WIRE 170 021887 WRENCH 270 BENTTWEEZER BENT TWEEZERS, METAL 170 413448001 OILER 160 411201120 NEEDLE, 62X59 170 KE0015 BOLT 170 KE0016 WASHER 170 KE0017 SPRING WASHER...

  • Page 67: Assembly Drawings & Parts Lists

    Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or...
  • Page 68 Technical Manual & Parts Lists...

  • Page 69: 11315A Auto Tape Edge Machine

    Page 95 1315620 GUIDE ROLLER ASSEMBLY 10 WWFS10 WASHER, FLAT #10 Page 69 1315642 COVER, ACCESS HOLE 38 WWFS3/8 WASHER, FLAT, 3/8 *1 1315A-CAB CABLE PACKAGE WWFS5/16 WASHER, FLAT, 5/16 *1 1315A-LAB LABEL PACKAGE WWL1/2 1/2 LW Page 96 *1 1315A-PD...
  • Page 70 Technical Manual & Parts Lists...

  • Page 71: 1315030 Backstop Assembly

    Technical Manual & Parts Lists 1315030 Backstop Assembly AAC Drawing Number 1315030 Rev1 QTY PART # DESCRIPTION 1315023 SHAFT, BACK STOP PIVOT 1315024 WELDMENT, PIVOT BLOCK 1315029 PLATE, ARM COVER 1315059 WELDMENT, BACKSTOP 1315062 BRACKET, BACKSTOP SENSOR AA2201-07 FLOW CONTROL,1/4TX1/4NPT AACCM3110DXP CYLINDER,AIR,DA,W/MAGNET AAEHSKQ...
  • Page 72 Technical Manual & Parts Lists...

  • Page 73: 1315050 Rotate Arm Assembly

    Technical Manual & Parts Lists 1315050 Rotate Arm Assembly AAC Drawing Number 1315050 Rev3 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1315030 BACKSTOP ASSEMBLY MMAGR251430N RAIL,LINEAR, AG SERIES Page 65 1315033 CARRIER, BACK STOP NNE6-32 NUT,ELASTIC LOCK,6-32 1315035 ARM, WELDMENT 10 NNK1/4-20...

  • Page 74: 1315060 Foot Pedal Assembly

    Technical Manual & Parts Lists 1315060 Foot Pedal Assembly AAC Drawing Number 1315060 Rev0 QTY PART # DESCRIPTION 1278-6161 FOOT SWITCH MODIFICATION 1315-010 CABLE, FOOT PEDAL 1315047 PLATE, PEDAL MOUNT 1315048 GUARD, PEDAL AAF1/8 1/8" PLASTIC CLAMP NNE6-32 NUT,ELASTIC LOCK,6-32 SSFC80024 #6-32 X 3/8 FLAT ALLEN...

  • Page 75: 1315620 Guide Roller Assembly

    Technical Manual & Parts Lists 1315620 Guide Roller Assembly AAC Drawing Number 1315620 Rev2 QTY PART # DESCRIPTION 1315418 PLATE, EDGE GUIDE 1315422 MOUNT, EDGE PLATE 1315423 TOP, EDGE GUIDE SS 1315438 MOUNT, AXLE EDGE GUIDE 1315619 POST, ROLLER GUIDE 1315621 ROLL, ASSY 2"OD 24.25"...
  • Page 76 Technical Manual & Parts Lists...

  • Page 77: 1315100 Sew Head Assembly

    Technical Manual & Parts Lists 1315100 Sew Head Assembly AAC Drawing Number 1315100 Rev6 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1315246 BRKT, EYE FFSM312LVQ EYE,ELECTRIC,10-30VDC 1315507 BRACKET, CYLINDER MM1590A13 LATCH, DRAW PULL 1315574 GUIDE, THREAD MMCYR114S FOLLOWER, CAM 1315585 BRKT, MOUNT, THREAD GUIDE...
  • Page 78 Technical Manual & Parts Lists...

  • Page 79: 1315115 Arm Gearbox Assembly

    Technical Manual & Parts Lists 1315115 Arm Gearbox Assembly AAC Drawing Number 1315115 Rev4 QTY PART # DESCRIPTION 1315105 MOUNT, ARM MOTOR WELD 1315110 MOUNT, ARM MOTOR 1315111 MOUNT, SLIDE MOTOR 1315112 PLATE, NUT 1/2-13 2.5 CTC 1315113 BRACKET, MOTOR MOUNT 1315283 HUB, ARM MOTOR 1315372...
  • Page 80 Technical Manual & Parts Lists...

  • Page 81: 1315200 Column Assembly

    Technical Manual & Parts Lists 1315200 Column Assembly AAC Drawing Number 1315200 Rev6 QTY PART # DESCRIPTION 0211-209 PLATE,NUT,10-32@2.25 CTC 1278-6602A TOUCH SWITCH ASSY W/3 PIN 1315129 MOUNT, COLUMN 1315132 MOUNT, CABLETRAK COLUMN 1315276 PLATE, SEWING HEAD MOUNT 1315277 MOUNT, ROD END 1315279 MOUNT, COLUMN FRONT 1315282...
  • Page 82 Technical Manual & Parts Lists...

  • Page 83: 1315300 Console Assembly

    Technical Manual & Parts Lists 1315300 Console Assembly AAC Drawing Number 1315300 Rev3 QTY PART # DESCRIPTION 1315123 MOUNT, EFKA 1315124 COVER, COLUMN 1315125 CONSOLE BASE, WELDMENT 1315128 AXLE, COLUMN 1315130 MOUNT, CONSOLE 1315138 COVER, WELDMENT 1315144 AXEL, PIVOT 1315146 COVER, CONSOLE 1315148 WIPER, COLUMN SHORT...
  • Page 84 Technical Manual & Parts Lists...

  • Page 85: 1315327 Lift Platform Assembly

    Technical Manual & Parts Lists 1315327 Lift Platform Assembly AAC Drawing Number 1315327 Rev2 QTY PART # DESCRIPTION 1315060 ASSY,FOOTPEDAL Page 68 1315339 ROLLER, TOP 1315341 AXLE, TOP ROLLERS 1315354 COVER, TOWER 1315355 BLOCK, PIVOT TOWER 1315380 ASSY, BASE PLATFORM 1315385 RISER, WELDMENT 1315386...
  • Page 86 Technical Manual & Parts Lists...

  • Page 87: 1315400 Flipper Assembly

    Technical Manual & Parts Lists 1315400 Flipper Assembly AAC Drawing Number 1315400 Rev6 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1315318 MOUNT, FLIP MMAGH25CAN LINEAR BEARING 1315397 LINK, FLIP LOWER MMAGR25992M RAIL,LINEAR AG SERIES 1315401 LINK, FLIP UPPER 16 NNC1_4-20 NUT, CAP, 1/4-20 1315408...

  • Page 88: 1315430 Pneumatic Panel

    Technical Manual & Parts Lists 1315430 Pneumatic Panel AAC Drawing Number 1315430 Rev2 QTY PART # DESCRIPTION 1315566 PANEL, PNEUMATIC AA198-508 REGULATOR,0-160 W/GAUGE AA198-5110 FILTER/REGULATOR/LOCKOUT AAE1315-12 SOLENOID ASSY,12 STATION AAQME-3-4 MALE ELBOW 3/8OD TUBE AAQME-4-4 ELBOW, MALE,1/4X1/4NPT AAQME-5-10 ELBOW, MALE,5/32X10-32 AAQUY-3-3 QUICK UNION Y 3/8 X 3/8 AAQUY-4-4...

  • Page 89: 1315595 Head Pusher Assembly

    Technical Manual & Parts Lists 1315595 Head Pusher Assembly AAC Drawing Number 1315595 Rev1 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1315597 MOUNT, CYLINDER BASE NNE5/16-18 NUT,ELASTIC LOCK,5/16-18 1315598 BASE, HEAD PUSHER NNK1/4-20 KEP NUT, 1/4-20 1315600 WELDMENT, HEAD PUSHER RAM SSAS024128 3/8 X 2 X 5/16-18 SHLD, BOLT...

  • Page 90: 1315575 Tape Roll Holder

    Technical Manual & Parts Lists 1315575 Tape Roll Holder AAC Drawing Number 1315575 Rev0 QTY PART # DESCRIPTION 1315570 WELDMENT, ROLL HOLDER 1335-816 ROD,SS, 1/2 X 15.0 L 1349127 ROD, SS, "L", 3/8, 6 X 12 A-4-032 HUB,1/2" ID ALUMINUM ROD CROSS BLOCK MM132-1496 PLUG 1 X 2...

  • Page 91: 1315450 Tape Guide Assembly

    Technical Manual & Parts Lists 1315450 Tape Guide Assembly AAC Drawing Number 1315450 Rev2 QTY PART # DESCRIPTION 1315174 ROD, BENT, 1/2 CRS 1315475 CLAMP, 3/4 ROD 1335-316 ROD, SS, "L", 3/8, 4.0 X 1335-320 ROD,S/S,3/8,6.5L 1338-028 RING,TAPE GUIDE 28201 BLOCK,CROSS,(LARGE) 28202 ROD,STRAIGHT,1018...

  • Page 92: 1315479 Air Jet Assembly; (Right Side)

    Technical Manual & Parts Lists 1315479 Air Jet Assembly; (Right Side) AAC Drawing Number 1315479 Rev1 QTY PART # DESCRIPTION 1315477 BLOCK, CLAMP 3/8 ROD 1315478 ROD, 3/8" AIR JET MOUNT AA3001F-03 FLOW CONT,INLINE,1/4 LINE AAQBC-4-4 BULKHEAD CONN,1/4QUIC MM5329K21 AIR NOZZLE NNE10-32 NUT,ELASTIC LOCK SSSC01048...

  • Page 93: 1315483 Air Jet Assembly; (Left Side)

    Technical Manual & Parts Lists 1315483 Air Jet Assembly; (Left Side) AAC Drawing Number 1315483 Rev0 QTY PART # DESCRIPTION 1315477 BLOCK, CLAMP 3/8 ROD 1315478 ROD, 3/8" AIR JET MOUNT AA3001F-03 FLOW CONT,INLINE,1/4 LINE AAQBC-4-4 BULKHEAD CONN,1/4QUIC MM5329K21 AIR NOZZLE NNE10-32 NUT,ELASTIC LOCK SSSC01048...
  • Page 94 Technical Manual & Parts Lists...

  • Page 95: 1315498 Push Plate Assembly

    Technical Manual & Parts Lists 1315498 Push Plate Assembly AAC Drawing Number 1315498 Rev2 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1315465 ASSY, CYL. MOUNT PUSHER MM18222837 DUCT,WIRE MICROTRAK 1315537 MOUNT, BEARING AND RAIL MM2761 GROMMET,.50 ID X 3/16 GR 1315543 MOUNT,CYLINDER HORZ MMAGH25CAN LINEAR BEARING...
  • Page 96 Technical Manual & Parts Lists...

  • Page 97: 1315502 Table Assembly

    Technical Manual & Parts Lists 1315502 Table Assembly AAC Drawing Number 1315502 Rev4 PART # DESCRIPTION 1315003 BLOCK, ROLLER TAKE-UP 1315004 BOLT, BELT ADJUSTER 1315007 PLATE, ADJUSTABLE BEARING 1315008 BAR, NUT 1315010 ROLLER, CONVEYOR 1315013 PLATE, BEARING MOUNT 1315052 SHAFT,IDLE ROLL 1315054 MOUNT, TENSION ROLL 1315056...
  • Page 98 Technical Manual & Parts Lists...

  • Page 99: 1315560 Control Box Assembly

    DESCRIPTION 1315415 BRKT, AC TECH 1315561 BOX, CONTROL 1315562 DOOR, CONTROL BOX 1315588 CATCH, PNEU. PANEL 1315650 AC POWER DISCONNECT ASSY AR 1315A-WD WIRING DIAGRAM 13459004 MOUNTING BRACKET, CAPACIT 4080-110 MODULE,QUAD INPUT 4080-120 MODULE,DUAL OPTO-ISO 4080-130 MODULE,QUAD OPTO-ISO 4080-140 MODULE,QUAD OUTPUT...

  • Page 100: 1315603 Sensor Bracket Assembly

    Technical Manual & Parts Lists 1315603 Sensor Bracket Assembly AAC Drawing Number 1315603 Rev1 QTY PART # DESCRIPTION 1315015 BLOCK, EYE MOUNT 1315016 BLOCK, SENSOR 1315017 BRACKET, SENSOR MOUNT 1315020 BLOCK, NUT 1315605 BRACKET, SENSOR MTG FFT18FF100Q EYE,FIXED FIELD, 4IN MMAM1-A0-4AM PROX SWITCH,10-30VDC,12MM TTH32426 HANDLE,THRD,5/16-18X1-1/4...

  • Page 101: 1315610 Touch Screen Assembly

    Technical Manual & Parts Lists 1315610 Touch Screen Assembly AAC Drawing Number 1315610 Rev1 QTY PART # DESCRIPTION 1278-6010 START/STOP BUTTON ASSY 1315607 MOUNT, TOUCH SCREEN 1315608 BRACKET, TOUCH SCREEN 4080-003 CONTROLLER,SBUS,V3 SSHC01040 1/4-20 X 5/8 HHCS SSPS90040 #8-32 X 5/8 LG. PAN HD SLOT SSSC80032 #6-32 X 1/2 SOC CAP WWFS1/4...

  • Page 102: 1315A-Pd Pneumatic Diagram

    Technical Manual & Parts Lists 1315A-PD Pneumatic Diagram 125606A...

  • Page 103: 1315A-Wd Wiring Diagram

    Technical Manual & Parts Lists 1315A-WD Wiring Diagram 125605A...
  • Page 104 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
  • Page 105 Declaración de Garantia Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero.
  • Page 106 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 Printed in the USA 770-963-7369 www.atlatt.com...
