- Page 1 1335E Model Revision 3.1 Updated Jun 22, 2012 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
- Page 2 Technical Manual & Parts Lists...
- Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.
-
Page 4: Table Of Contents
Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Mandatory Information ..........................1 Scope of the Instruction Material ........................ 1 Intended Use ............................... 1 Exclusion of Misuse ............................ 1 Liability ............................... 2 Choice and Qualification of Personnel ....................... 2 Training ............................... - Page 5 Puller Drive ............................... 16 General Machine Maintenance ......................... 17 Daily ................................17 Weekly ..............................17 Electric Eye Sensor Adjustment ....................... 17 Reflective Tape Maintenance ........................17 1335M Folder Spacer Reference Chart ..................... 18 1335E Parameter Settings ......................... 19 Spare Parts Kit ............................19...
- Page 6 1335923 Zero-Max Mount Assembly ....................... 43 1335M-113 Foot Pressure Assembly ......................45 1335M-2200 Ruffler Mount Angle Assembly ..................47 1335M-2300B Pivot Assembly......................... 49 1A35M-6000 Footlift Assembly ....................... 51 1335MF-500 Control Box Assembly......................53 1335E-PD Pneumatic Diagram ......................... 54 1335E-WD Wiring Diagram ........................55...
-
Page 7: Important Safety Instruction
Mandatory Information All persons operating and/or working on the 1335E Manual Ruffler Workstation should read and understand all parts of the Safety Instructions. This applies, in particular, for persons who only operate and/or work on the unit occasionally (e.g. for maintenance and repair). Persons who have difficulty reading must receive particularly thorough instruction. -
Page 8: Liability
Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet. -
Page 9: A Word To The Operator
Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or... -
Page 10: Protective Eyewear
Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine. -
Page 11: Important Notices
Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated. -
Page 12: Delivery Of The Machine/Packaging
Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information. -
Page 13: Workplace Environment
Technical Manual & Parts Lists Workplace Environment Our machines are designed for use in enclosed rooms: Permissible ambient temperature approx. 5 - 40 °C (40 - 104 °F). Malfunctions of the control systems and uncontrolled machine movements may occur at temperatures outside this range. Protect against climatic influences, such as electrostatic charges, lightning strikes, hail, storm damage, high humidity, salinity of the air in coastal regions. -
Page 14: Repair
Technical Manual & Parts Lists When scrapping (disassembling) the machine and its assemblies, ensure that these materials are disposed of safely. Either commission a specialist company familiar with the local regulations or note the local regulations when disposing of these materials yourself. Materials should be sorted properly. Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other... -
Page 15: General Liability
Technical Manual & Parts Lists General Liability Liability for machine damage and personal injury is extinguished completely if any unauthorized conversions or modifications are undertaken. The machine must not be modified, enlarged or converted in any way capable of affecting safety without the manufacturer's prior approval. Starting Machine Movements Read the Instruction Manual carefully to establish which keys and functions start machine movements. -
Page 16: Safety Precautions
Technical Manual & Parts Lists Safety Precautions Safety should be a constant concern for everyone. Always be careful when working with this equipment. While normal safety precautions were taken in the design and manufacture of this equipment, there are some potential safety hazards. Everyone involved with the operation and maintenance of this equipment should read and follow the instructions in this manual. -
Page 17: General Machine Data
Technical Manual & Parts Lists General Machine Data Electrical & Pneumatic Specifications Electrical: 220 VAC, 5amp, 50/60 Hz Single Phase Pneumatic: 70-80 PSI, 2 SCFM avg. Sewing Head: Consew 326S Sewing Speed: 3500 RPM Needle (Standard): SNTVX7X140 Stitch Density: 6 SPI Installation &... -
Page 18: Stepper Control Box
Technical Manual & Parts Lists Thumbwheels The first thumbwheel (#1) on the left sets the stitch count for the SLOW START feature after the last ruffle. This reduces the sewing speed for a few stitches to help the material feed to the puller before the machine goes to high speed. The stitch count equals twice the number shown on the thumbwheel. -
Page 19: Efka Control Box
Technical Manual & Parts Lists Efka Control Box The sewing machine is powered by the Efka motor controller located under the table. It has its Fig. 3 own on/off switch which should be left on at all times. It also has some small buttons and LED's on the front to indicate the enabled functions. -
Page 20: Loading And Adjusting The Folder
Technical Manual & Parts Lists Loading and Adjusting the Folder Feed the gusset through the top portion of the folder with the flange to the right and under Fig. 5 the right flange guide. Adjust the left guide to make a snug fit to the gusset width. Adjust the folder left or right as necessary to set the desired stitch margin. -
Page 21: Sewing The Panel With Straight Corners
Technical Manual & Parts Lists Sewing the Panel with Straight Corners Set thumbwheel #5 to "7" for 1 ruffle per side, “8” for 2 ruffles per side, or "9" for 3 ruffles per side. Sew the panel to the corner being sure not to get your hands in the way of the electric eye mounted under the table, which must "see"... -
Page 22: General Machine Adjustments
Technical Manual & Parts Lists General Machine Adjustments Air Pressure Set all air supply pressure regulators (Right to left): Main Pressure: 70 PSI Puller Pressure: 30 PSI Ruffle Blade Pressure: 10 PSI Foot Sew Pressure: 15 PSI Sewing Head See the manufacturer’s manuals for normal adjustments and parts. The presser foot spring pressure should be set very light so that the ruffling blade can feed under the foot while ruffling. -
Page 23: General Machine Maintenance
Technical Manual & Parts Lists General Machine Maintenance Daily Clean machine at the end of every shift Clean lint etc. from the Looper/bobbin area on the sewing head Remove any threads wrapped around moving parts of the handwheel, puller, and ruffler. -
Page 24: 1335M Folder Spacer Reference Chart
Technical Manual & Parts Lists 1335M Folder Spacer Reference Chart... -
Page 25: 1335E Parameter Settings
Technical Manual & Parts Lists 1335E Parameter Settings Spare Parts Kit Part Number Description 1278-7055B Proxy Switch 1335M-2002E Ruffler Blade 5S5-31 Looper 61-04-01/B3 Screw EEFE-RR2 Reflective Tape 12’ FFSM312LV Electric Eye GG150XL075 Gear Belt GG180XL037 Gear Belt GR1999 Needle Guard... - Page 26 Technical Manual & Parts Lists...
-
Page 27: Assembly Drawings & Parts Lists
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or... - Page 28 Technical Manual & Parts Lists...
-
Page 29: 11335E Manual Ruffler
Technical Manual & Parts Lists 11335E Manual Ruffler AAC Drawing Number 9000013 Rev4 PART # DESCRIPTION 1335704 WASHER,3/8L,1.25OD 1335710 SEWING HEAD ASSEMBLY 1335922 STAND & MOTOR ASSY 1335E 1335924 Stepper Box Assembly 1335930 ROLLHOLDER ASSY,OVERHEAD AR 1335E-PD PNEUMATIC DIAGRAM AR 1335E-WD WIRING DIAGRAM 1335M-2000A... - Page 30 Technical Manual & Parts Lists...
-
Page 31: 1335922 Stand & Motor Assembly
1335872 EDGE GUIDE SSFS90128 #8-32 X 2 FLAT SLOTTED 1335E-500 CONTROL BOX ASSY SSFS98112 #10-32 X 1-3/4 FLAT SLOT AR 1335E-PD PNEUMATIC DIAGRAM SSHC01256 1/4-20 X 4 HEX HEAD AR 1335E-WD WIRING DIAGRAM SSPS70048 #4-40 X 3/4 PAN HD SLOT 1975-412A PLATE,NUT,4-40,.95CTC... - Page 32 Technical Manual & Parts Lists...
-
Page 33: 1335924 Stepper Box Assembly
Technical Manual & Parts Lists 1335924 Stepper Box Assembly AAC Drawing Number 1335924 Rev0 PART # DESCRIPTION 1335916 MNT, CTRL BOX 1335M-9010 BRKT, STEPPER BOX BASE 1335M-9011 BOX , SHELF MOTOR AP-28-800Y1 BOX,STEPPER,H.S. (X5) MMSLD-ECH 1/2" DIA RUBBER BUMPER SSFC98032 #10-32 X 1/2 FLAT ALLEN WWL10 #10 LW... - Page 34 Technical Manual & Parts Lists...
-
Page 35: 1335M-2000A Ruffler Assembly
Technical Manual & Parts Lists 1335M-2000A Ruffler Assembly AAC Drawing Number 9000004 Rev3 PART # DESCRIPTION PART # DESCRIPTION 1278-7055D PROX SWITCH W/PLUG,12" NNE1/2-13 ELASTIC LOCK NUT AR 1325-4126 TEFLON TAPE, 1" NNH2-56 #2-56 HEX NUT 1335332 RUFFLER CYL LIFT ASSY NNJ3/8-16 3/8-16 HEX JAM NUT 1335M-001... - Page 36 Technical Manual & Parts Lists...
-
Page 37: 1335183 Stripper Blade Assembly
Technical Manual & Parts Lists 1335183 Stripper Blade Assembly AAC Drawing Number 1335183 Rev0 PART # DESCRIPTION 1335154 PIVOT ROD, STRIP BLADE 1335475 STRIPPER BLADE-1804P 1335624 Block, Mounting 1335627 MOUNT ARM, STRIPPER BLADE 1335M-5001 PLATE,MOUNTING CCSC6F3_8 COLLAR,SET 3/8 RRBEEHIVEH SPRING,HEAVY BEEHIVE SSBC98024 #10-32 X 3/8 BUT HEAD SSFC01032... - Page 38 Technical Manual & Parts Lists...
-
Page 39: 1335184 Puller Assembly
Technical Manual & Parts Lists 1335184 Puller Assembly AAC Drawing Number 1335184 Rev2 QTY PART # DESCRIPTION 1278-7055D PROX SWITCH W/PLUG,12" 1335185 COVER, DRIVE BELT 1335927 YOKE, PULLER 1335M-2034 PLATE, NUT #2-56 1335M-3002 SHAFT,FLAT,60C,.375OD 1335M-3003 SHAFT,FLAT,60C,.375OD 1335M-3007 T-NUT, 10-32 1335M-3008 MTG. - Page 40 Technical Manual & Parts Lists...
-
Page 41: 1335332 Ruffler Cylinder Lift Assembly
Technical Manual & Parts Lists 1335332 Ruffler Cylinder Lift Assembly AAC Drawing Number 1335332 Rev8 PART # DESCRIPTION 1335223 BASE MTG PLT, FOLDER 1335224 BASE MTG PLATE 1335226 MTG PLT LH- RAIL 1335227 SUPPORT-SLIDE, LH SIDE 1335228 SUPPORT, RH 1335229 MTG PLT RH- RAIL 1335230 FOLDER SLIDE ARM... - Page 42 Technical Manual & Parts Lists...
-
Page 43: 1335716 Pneumatic Shelf Assembly
Technical Manual & Parts Lists 1335716 Pneumatic Shelf Assembly AAC Drawing Number 1335716 Rev3 PART # DESCRIPTION AAQME-5-8 QUICK MALE ELBOW AAVS125 SHUTTLE VALVE,1/8"PORT SSSC80064 #6-32 X 1 SOC CAP WWFS6 WASHER, FLAT, #6 1335715 BRACKET, PNEUMATIC AA198-503 0-30PSI AIR GAGE 1/8NPT AA198-5102 REGULATOR W/GAUGE &... - Page 44 Technical Manual & Parts Lists...
-
Page 45: 1335930 Roll Holder Assembly
1335179 ROD,BENT,CRS,1/2 OD 1335664 PIVOT,SWING ARM,UNWINDER 1335667 NUT,PLATE,5/16-18 4X 1335794 NUT,PLATE,5/16-18,2@2.25 1335931 MAIN SUPPORT,UNWINDER 1335932 STABILIZER,UNWINDER,1335E 33008708 BALL BEARING DISC ASSY 8732-0576 ROD, STRAIGHT, SS, 1/2 X 97-1711 TUBE, 3/4 X 30 X 1/8 WALL BBNTA1220 BEARING,THRUST,.750B BBTRA1220 WASHER,THRUST,STEEL CCCL12F... - Page 46 Technical Manual & Parts Lists...
-
Page 47: 1335710 Sewing Head Assembly
Technical Manual & Parts Lists 1335710 Sewing Head Assembly AAC Drawing Number 1335710 Rev5 PART # DESCRIPTION 1278-6364 DISC, TAPE MOUNTING 1335183 STRIPPER BLADE ASY,1335MD 1335184 PULLER ASSEMBLY,326S CONS 1335700 THROAT PLATE, SCON-326S 1335701 BRACKET,L 1335702 BELT GD, 1.88R 1335703 BELT GD, 326S CONSEW 1335712 LIFTING ROD... - Page 48 Technical Manual & Parts Lists...
-
Page 49: 1335923 Zero-Max Mount Assembly
Technical Manual & Parts Lists 1335923 Zero-Max Mount Assembly AAC Drawing Number 1335923 Rev2 PART # DESCRIPTION 1335912 MOUNT, ZERO-MAX, 1335913 HINGE SPACER, 1335E 1335914 BASE, ZERO-MAX, 1335E 1335915 PRESSURE PLATE, 1335E E2SC Z-MAX W/SCR CNTRL,CW MM741-3A HINGE,3 X 3,STANLEY... - Page 50 Technical Manual & Parts Lists...
-
Page 51: 1335M-113 Foot Pressure Assembly
Technical Manual & Parts Lists 1335M-113 Foot Pressure Assembly AAC Drawing Number 192700A Rev1 PART # DESCRIPTION 1335M-106 Pressure Rod 1335M-107 Knob 1335M-108 Lever 1335M-112 Mnt Brkt AA198RR508 Flow Control AAC7DP-.5 Air Cylinder AAFBP-11C Pivot Brkt AAFCT-7 Clevis SSAS020024 Screw, Allen Shoulder SSPP98032 Screw, Pan Head AAFP18... - Page 52 Technical Manual & Parts Lists...
-
Page 53: 1335M-2200 Ruffler Mount Angle Assembly
Technical Manual & Parts Lists 1335M-2200 Ruffler Mount Angle Assembly AAC Drawing Number 192727C Rev1 PART # DESCRIPTION 1335M-2005 Mounting Angle 1335M-2017 Rod End 1335M-2027 Cylinder Mnt 1335M-2028 Cylinder Support 1335M-2046 Nut Plate A-2206A Threaded Rod AA198RA510 Flow Control AAC8DP-.5 Air Cylinder AAFBP-8C Pivot Brkt... - Page 54 Technical Manual & Parts Lists...
-
Page 55: 1335M-2300B Pivot Assembly
Technical Manual & Parts Lists 1335M-2300B Pivot Assembly AAC Drawing Number 192985C Rev3 PART # DESCRIPTION 1335M-2004A Pivot Arm 1335M-2007 Pivot Block 1335M-2009 Drive Link 1335M-2010 Pivot Block 1335M-2011 Pivot Shaft 1335M-2012 Side Link 1335M-2013 Link Shaft 1335M-2014 Link Shaft 1335M-2015 Link Yoke BBNTA815... - Page 56 Technical Manual & Parts Lists...
-
Page 57: 1A35M-6000 Footlift Assembly
Technical Manual & Parts Lists 1A35M-6000 Footlift Assembly AAC Drawing Number 192736C Rev1 PART # DESCRIPTION 1918-073 Footlift Link 32006517 Oil Tray 32006524 Pivot Mnt Brkt AA198RA508 Flow Control AAC6DP-2 Air Cylinder AAFBP-11C Pivot Brkt BBAW-5Z Rod End Bearing CCCL5F Clamp Collar CCSCL7F Clamp Collar... - Page 58 Technical Manual & Parts Lists...
-
Page 59: 1335Mf-500 Control Box Assembly
Lock Washer 0211-705D Cable SSHC01032 Screw, Hex Cap 0411-1906B Cable SSPP80016 Screw, Pan Head FF313005 Fuse SSPS98032 Screw, Pan Head 1335E-WD Wiring Diagram AAE1335-5 Solenoid Assy SSPS90024 Screw, Pan Head 1987-513A Cable 1335MF-LAB1 Label WWFS10 Flat Washer AAF1/8 Plastic Clamp... -
Page 60: 1335E-Pd Pneumatic Diagram
Technical Manual & Parts Lists 1335E-PD Pneumatic Diagram... -
Page 61: 1335E-Wd Wiring Diagram
Technical Manual & Parts Lists 1335E-WD Wiring Diagram... - Page 62 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
- Page 63 Declaración de Garantia Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero.
- Page 64 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 www.atlatt.com Printed in the USA...
