Atlanta Attachment Company 1335MHB Technical Manual & Parts Lists

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Technical Manual & Parts Lists
1335MHB
Model
Revision 4
Updated
Atlanta Attachment Company
362 Industrial Park Drive
Lawrenceville, GA 30046
770-963-7369 • www.atlatt.com
Aug 22, 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1335MHB and is the answer not in the manual?

Questions and answers

Related Manuals for Atlanta Attachment Company 1335MHB

Summary of Contents for Atlanta Attachment Company 1335MHB

  • Page 1 1335MHB Model Revision 4 Updated Aug 22, 2012 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
  • Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.

  • Page 4: Table Of Contents

    Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Liability ..............................2 Safety Equipment on the Machines ......................3 Protective Eyewear ............................. 4 Important Notices............................5 Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................
  • Page 5 A-2216W56 Folder Assembly ........................64 3200PMD Marking Module Assembly ..................... 66 3200PME Marking Module Assembly ..................... 68 33008708 Ball Bearing Disc Assembly ....................69 4059-FP301D Foot Pedal Assembly ......................70 1335MHB-PD Pneumatic Diagram ......................71 1335MHB-WD Wiring Diagram ......................72...

  • Page 6: Important Safety Instruction

    Mandatory Information All persons operating and/or working on the 1335MHB Border Frame Ruffler should read and understand all parts of the Safety Instructions. This applies, in particular, for persons who only operate and/or work on the unit occasionally (e.g. for maintenance and repair). Persons who have difficulty reading must receive particularly thorough instruction.

  • Page 7: Liability

    Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet.

  • Page 8: Safety Equipment On The Machines

    Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or...

  • Page 9: Protective Eyewear

    Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine.

  • Page 10: Important Notices

    Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated.
  • Page 11 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.

  • Page 12: Maintenance

    Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine.

  • Page 13: Repair

    Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts.

  • Page 14: A Word To The End User

    Technical Manual & Parts Lists A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines.

  • Page 15: General Machine Data

    Technical Manual & Parts Lists General Machine Data Electrical & Pneumatic Specifications Electrical: 220 VAC, 5amp, 50/60 Hz Single Phase Pneumatic: 70-80 PSI, 2 SCFM avg. Sewing Head: Yamato VM1804P Sewing Speed: 3500 RPM Needle (Standard): SN62X5721 Stitch Density: 6 SPI Installation &...

  • Page 16: Operating Instructions

    Technical Manual & Parts Lists Operating Instructions Touch Screen Operation The graphics images presented on the touch screen show "3-dimensional" buttons, which may be pressed to access other screens, change counters and timers, or actuate hardware. Areas lacking the "3- dimensional" border contain information only. Counters are identified with the "+"...
  • Page 17 Technical Manual & Parts Lists Press EXIT to lower the foot, etc., and return to the main screen. The HOME button takes you to the main screen without resetting the machine. Back on the main screen press the SETUP button to access the setup screen: This allows setup of the ruffle quantity and stitches, access to SECURITY, SYSTEM INFORMATION, ADVANCED SETUP, and the SHOW ALL SETTINGS matrix screen.
  • Page 18 Technical Manual & Parts Lists Press the top arrow buttons to access the second SETUP screen in BORDER mode for enabling or disabling the ruffler and markers and accessing the ADVANCED SETUP screens. Note: when a button has a white background the function is on or enabled. A dark background indicates off or disabled.
  • Page 19 Technical Manual & Parts Lists This screen has an additional button for adjusting the PANEL STOP COUNT that controls where the panel stops for turning the corners and a ROUND CORNER button for selecting the corner mode. When the ROUND CORNER button has a WHITE background the machine is in the ROUND CORNER mode.
  • Page 20 Technical Manual & Parts Lists Press EXIT to return to SETUP screen. The ADVANCED SETUP button accesses the advanced machine settings and functions not normally accessible by the operator. After power on or a master reset, a pass code must be entered to access these screens.
  • Page 21 Technical Manual & Parts Lists Pressing the top arrows will display the Advanced Setup 2 page. Ruffling Speed is the sewing speed while ruffling. Seam Allowance is the stitch margin for closing the border. Marker time is the on time of the markers. Unwinder Time is the minimum run time of the unwinder motor after the loop eye activates the motor.
  • Page 22 Technical Manual & Parts Lists Press MANUAL to access the manual run page and enable the foot switches for manual sewing and foot lift functions. You can turn on the ruffle cycle for testing and access the advanced manual pages for testing inputs and outputs.
  • Page 23 Technical Manual & Parts Lists Press the EDIT NEW ORDER button to change to a different size border and edit the size settings. Use the Border Quantity button to set the number of borders to be run consecutively without stopping. Press SELECT NEW STYLE to change sizes. Select the desired style and the machine will return to the EDIT ORDER screen.
  • Page 24 Technical Manual & Parts Lists Press EDIT STYLES to input or change the styles menu. The top arrows take you to additional screens. Select the button for the style you wish to edit or create. Example: select style "5":...
  • Page 25 Technical Manual & Parts Lists The EDIT STYLE 5 page is displayed. To change or create names press the NAME button. The NAME entry screen appears: The left and right arrows move the cursor one character. The arrows with the vertical bar Move to the start or end of the text.

  • Page 26: Machine Operation

    Technical Manual & Parts Lists Other screens display whenever there is a machine error or other condition that prohibits the operation of the machine. Simply follow the instruction on the screens to resolve the problem. Machine Operation Turn on the main power circuit breaker Fig.

  • Page 27: Stepper Control Box

    Technical Manual & Parts Lists Stepper Control Box There is a stepping motor box located under the table. The Ruffler box has three thumbwheels on the front Fig. 2 which are set to synchronize the Ruffler to the sewing head. The number is proportional to the stitch length and is not affected by sewing speed.

  • Page 28: Loading And Adjusting The Folder

    Technical Manual & Parts Lists Loading and Adjusting the Folder Activate the folder up switch to raise the folder. Feed the border through the top portion of the folder; heal the treadle to raise the measuring wheel, feed the border through the bottom of the folder and under the presser foot and puller.

  • Page 29: Adjusting The Corner Ruffles

    Technical Manual & Parts Lists continue to sew straight as it makes the ruffles. After the last ruffle is finished on the first side of the corner the machine will stop with the presser foot lifted. Turn the panel 90 degrees.

  • Page 30: Initial Set-Up Of Border Mode

    Technical Manual & Parts Lists Initial Set-Up of Border Mode: Initial set-up of border mode settings should be done in the following order: 1. Using a Twin border style, set the border length and corner position. 2. Compensate the machine so it is measuring correctly. 3.

  • Page 31: Unwinder Assembly

    Technical Manual & Parts Lists Unwinder Assembly The Unwinder is belt driven from a right angle gear motor. The motor and bearings are permanently lubricated and require no regular maintenance. Check the belt tension periodically and adjust if necessary. Check the gear pulley and bearing set screws for tightness.

  • Page 32: Parameter Settings For Efka Controller

    Technical Manual & Parts Lists Parameter Settings for Efka Controller...

  • Page 33: 1335M Folder Spacer Reference Chart

    Technical Manual & Parts Lists 1335M Folder Spacer Reference Chart...
  • Page 34 Technical Manual & Parts Lists...

  • Page 35: Assembly Drawings & Parts Lists

    Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or...
  • Page 36 Technical Manual & Parts Lists...

  • Page 37: 11335Mgba-Uw Border Frame Ruffler

    UNWINDER ASSY, HEAVY DUTY Page 34 1335575 ROLL HOLDER ASBLY Page 36 1335588 EXTENSION BKT, MARKER 1335699 GENERIC CONSOLE Page 38 AR 1335MHB-PD DIAGRAM, PNEUMATIC Page 71 AR 1355MHB-WD DIAGRAM, WIRING Page 72 3200PMD MARKING MODULE,EXT MOUNT Page 66 4059-FP301D...
  • Page 38 Technical Manual & Parts Lists...

  • Page 39: 1335145 Unwinder Assembly

    Technical Manual & Parts Lists 1335145 Unwinder Assembly AAC Drawing Number 1335145 Rev 12 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1325-346 HOLDER,ROD,1/2 D,SLOT MNT EEDF1X1 DUCT,WIRE,1X1 1334383 ROD, SS 1/2 OD X 18.0 LG FFQM42VN6A EYE,ELECTRIC,10-30VDC 1335108 DRIVE ROLLER ASSEMBLY GG157L050...
  • Page 40 Technical Manual & Parts Lists...

  • Page 41: 1335575 Roll Holder Assembly

    Technical Manual & Parts Lists 1335575 Roll Holder Assembly AAC Drawing Number 1335575 Rev 3 QTY PART # DESCRIPTION 1325-346A HOLDER, ROD, 3/4", SLOT 1335598 ROD, SS BENT, 90 DEG 265155A HOLDER, EYE, 1/2 BORE 28201 BLOCK,CROSS,(LARGE) 28201B LARGE PIVOT BLOCK 786B12-2.2 DISC &...
  • Page 42 Technical Manual & Parts Lists...

  • Page 43: 1335699 Base Console Assembly

    Technical Manual & Parts Lists 1335699 Base Console Assembly AAC Drawing Number 1335699 Rev 2 QTY PART # DESCRIPTION 0411-069D BRKT, THREAD BRK DETECTIO 0411-070 CLAMP, SENSOR BRACKET 1335-407A PLATE, MOUNTING, SEWING H 1335-408 STUD, THREADED, 1/4-20 1335294B RUFFLER ASSY Page 44 1335531 STAND &...
  • Page 44 Technical Manual & Parts Lists...

  • Page 45: 1335531 Stand & Motor Assembly

    STEPPER BOX ASSY SSFC98032 #10-32 X 1/2 FLAT ALLEN AR 1335M-LAB LABELS SSHC01032 1/4-20 X 1/2 HEX HEAD Page 71 AR 1335MHB-PD DIAGRAM, PNEUMATIC SSHC01048 1/4-20 X 3/4 HEX HEAD AR 1335MHB-WD DIAGRAM, PNEUMATIC SSHC10048 5/16-18 X 3/4 HEX HEAD...
  • Page 46 Technical Manual & Parts Lists...

  • Page 47: 1335505 Stripper Blade Assembly

    Technical Manual & Parts Lists 1335505 Stripper Blade Assembly AAC Drawing Number 1335505 Rev3 QTY PART # DESCRIPTION 1335474 PIVOT ROD, STRIP BLADE 1335475 STRIPPER BLADE-1804P 1335476 EDGE GUIDE, STRIP BLADE 1335489 PIVOT WEARPLATE 1335493 BLOCK, SWINGOUT PLATE 1335506 PIVOT BLOCK, STRIPPER BLA 1335508 PIVOT PLATE WELD'T 1335732...
  • Page 48 Technical Manual & Parts Lists...

  • Page 49: 1335294B Ruffler Assembly

    Technical Manual & Parts Lists 1335294B Ruffler Assembly AAC Drawing Number 192110B Rev 2 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1278-7055D Prox Switch SSAS024024M Screw, Allen Shoulder 1335M-2006 Trunion Block WWL8 Lock Washer 1335410 Pivot Plate SSFC01040 Screw, Flat Allen 1335M-2016...
  • Page 50 Technical Manual & Parts Lists...

  • Page 51: 1335298A Ruffler Mount Assembly

    Technical Manual & Parts Lists 1335298A Ruffler Mount Assembly AAC Drawing Number 9000931 Rev 5 QTY PART # DESCRIPTION 1278-7055D PROX SWITCH W/PLUG,12" 1335315A BASE PLATE, RUFFLER MTG 1335325 MTG. BRKT. SENSOR 1335334 CYL. MOUNT 1335401 REAR MOUNT, 1335MH 1335407 MNT BRKT,LOCK PIN CYL.
  • Page 52 Technical Manual & Parts Lists...

  • Page 53: 1335690 Ruffler Cylinder Lift Assembly

    Technical Manual & Parts Lists 1335690 Ruffler Cylinder Lift Assembly AAC Drawing Number 1335690 Rev 2 QTY PART # DESCRIPTION 1335223 BASE MTG PLT, FOLDER 1335224 BASE MTG PLATE 1335227 SUPPORT-SLIDE, LH SIDE 1335228 SUPPORT, RH 1335229 MTG PLT RH- RAIL 1335335 MTG PLT- HEAVY DUTY 1335336...
  • Page 54 Technical Manual & Parts Lists...

  • Page 55: 1335M-2300A Pivot Assembly

    Technical Manual & Parts Lists 1335M-2300A Pivot Assembly AAC Drawing Number 9000972 Rev 4 QTY PART # DESCRIPTION 1335373 SPACER, RUFFLER PIVOT 1335409 PIVOT ARM 1335411 DRIVE LINK, 11335MH, 300U 1335M-2007 PIVOT BLOCK 1335M-2010 BLOCK, DRIVE LINK PIVOT 1335M-2011 PIVOT SHAFT 1335M-2012 SIDE LINK 1335M-2013...
  • Page 56 Technical Manual & Parts Lists...

  • Page 57: 1335A-10B Sewing Head Assembly

    Technical Manual & Parts Lists 1335A-10B Sewing Head Assembly AAC Drawing Number 9001052 Rev 4 QTY PART # DESCRIPTION 1335-110B FOOTLIFT ASSY. Page 55 1335-403C BED PLATE, LEFT, MOD 1335-404 PLATE, THROAT 1335-405A PLATE, BED, RIGHT, RUFFLE 1335051 Cover, Rear 1335054A Standoff, Puller Plate 1335055A...
  • Page 58 Technical Manual & Parts Lists...

  • Page 59: 1335370 Control Box Assembly

    Technical Manual & Parts Lists 1335370 Control Box Assembly AAC Drawing Number 1335370 Rev 8 QTY PART # DESCRIPTION 1335370CAB CABLE PACKAGE 1335372 CONTROL BOX, SBUS AR 1335MFB-WD WIRING DIAGRAM Page 72 40-320 AC POWER DISCONNECT ASSY 4080-110 MODULE,QUAD INPUT 4080-120 MODULE,DUAL OPTO-ISO 4080-130...

  • Page 60: 1335-110B Footlift Assembly

    Technical Manual & Parts Lists 1335-110B Footlift Assembly AAC Drawing Number 9000989 Rev 7 QTY PART # DESCRIPTION 1317307 CYLINDER END, FOOT LIFT 1335910 BRACKET, CYLINDER AA198RA508 Body AAC5DP-2 AIR CYLINDER, SMC CCSCL7F CLAMP COLLAR- 7/16 NNHM5X0.8 M5 X 0.8 HEX NUT...

  • Page 61: 1335140B Puller Assembly

    Technical Manual & Parts Lists 1335140B Puller Assembly AAC Drawing Number 9000449 Rev 2 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1335053A PLATE,NUT,"L",10-32,3 PL CCCL10F CLAMP COLLAR- 5/8 ID 3517 WASHER,THRUST,BRONZE CCCL6F CLAMP COLLAR- 3/8 1335134 YOKE,PULLER,CENTER DRIVE GG150XL037U BELT,GEAR,1/5P,3/8W 1335143...
  • Page 62 Technical Manual & Parts Lists...

  • Page 63: 1335573 Puller Motor Assembly

    Technical Manual & Parts Lists 1335573 Puller Motor Assembly AAC Drawing Number 1335573 Rev 1 QTY PART # DESCRIPTION 011-020 MOTOR, STEPPER W/PLUG 1335-116 SHAFT,FLATTED,60C,.375 1335-119 BLOCK,BEARING 3517 WASHER,THRUST,BRONZE 1335572 MOUNT, MOTOR 1335574 GUARD, MOTOR BELT BBB-66 BEARING,NEEDLE,.375B CCCL6F CLAMP COLLAR- 3/8 GG100XL037 BELT,GEAR,1/5P,3/8W NNH10-32...
  • Page 64 Technical Manual & Parts Lists...

  • Page 65: 1335659 Guide Roller Assembly

    Technical Manual & Parts Lists 1335659 Guide Roller Assembly AAC Drawing Number 1335659 Rev 2 QTY PART # DESCRIPTION 1278-6310 CYLINDER MOUNT 1335161 ROLLER KNURLT, .5W 1335164 SHAFT, FLATTED 1335167 YOKE, LOWER ROLLER 1335654 MOUNT, GUIDE ROLLER 1335655 SUPPORT, LOWER 1335656 BLOCK, PIVOT 1335657...
  • Page 66 Technical Manual & Parts Lists...

  • Page 67: 1335674 Encoder Assembly

    Technical Manual & Parts Lists 1335674 Encoder Assembly AAC Drawing Number 1335674 Rev 3 QTY PART # DESCRIPTION 1335637 MOUNT, CYL CLEVIS 1335675 BRACKET, SIDE, ENCODER 1335676 COVER, ENCODER, 8" CAP. 1335M-2502 MOUNT,BASE1335M-2500 1335M-2503 PLATE,TENSION 1981A-271 WHEEL,ENCODER 1981A-272 CABLE,PIGTAIL,OPTICAL AA198RR508 FLOW CONTROL,5/32 X 1/8"...
  • Page 68 Technical Manual & Parts Lists...

  • Page 69: A-2216W56 Folder Assembly

    Technical Manual & Parts Lists A-2216W56 Folder Assembly AAC Drawing Number 9000005 Rev 1 QTY PART # DESCRIPTION 1335642 SEAM GUIDE, 9/16 X 1W 1335645 SPACER, ENCODER, 1/2" 1335652 GUIDE, SEAM, RIGHT 1335653 GUIDE, SEAM, LEFT 1335659 GUIDE ROLLER ASSEMBLY Page 60 1335672 PLATE,FOLDER,CONTIENTAL...
  • Page 70 Technical Manual & Parts Lists...

  • Page 71: 3200Pmd Marking Module Assembly

    Technical Manual & Parts Lists 3200PMD Marking Module Assembly AAC Drawing Number 9000107 Rev 1 QTY PART # DESCRIPTION 3200302 PEN CAP 3200303 PLATE, CAM 3200305 BRACKET, CYL ROD MOUNT 3200310 BRACKET, MOUNT 3200311 MOUNTING BRKT., LONG 3200312 GUIDE PIN, THREADED 3200PM-3001 HOLDER, PIN AA198RA510...
  • Page 72 Technical Manual & Parts Lists...

  • Page 73: 3200Pme Marking Module Assembly

    Technical Manual & Parts Lists 3200PME Marking Module Assembly AAC Drawing Number 9000645 Rev 1 QTY PART # DESCRIPTION 3200302 PEN CAP 3200303 PLATE, CAM 3200304 MOUNTING BRKT. 3200305 BRACKET, CYL ROD MOUNT 3200312 GUIDE PIN, THREADED 3200PM-3001 HOLDER, PIN AA198RA510 FLOW CONTROL,5/32X10-32 AAC8D-2...

  • Page 74: 33008708 Ball Bearing Disc Assembly

    Technical Manual & Parts Lists 33008708 Ball Bearing Disc Assembly AAC Drawing Number 9000904 Rev 4 QTY PART # DESCRIPTION 33008604 CONE, SPOOL 33008602 HUB, FLANGE 3/4 BORE SEE CHART SEE CHART 33008601 HUB, CENTER, 3/4 SHAFT BB23216-88 BEARING,BALL,1.0B RRLC026B1 SPRING,COMP .026X.18X.25 JJ012 3/16 DIA.

  • Page 75: 4059-Fp301D Foot Pedal Assembly

    Technical Manual & Parts Lists 4059-FP301D Foot Pedal Assembly AAC Drawing Number 9000033 Rev 3 QTY PART # DESCRIPTION 26058 ROD, STRAIGHT, 1018 4059-2-22A REMOTE ACTUATOR 4059030 PEDAL, FOOT PEDAL,12X18 4059033 FOOT PEDAL WELDMENT A3502-4 FOOT PEDAL, BRACKET MM94807A029 PUSHNUT,ROUND,1/4 DIA NNJ3/8-16 3/8-16 HEX JAM NUT SSFC98024...

  • Page 76: 1335Mhb-Pd Pneumatic Diagram

    Technical Manual & Parts Lists 1335MHB-PD Pneumatic Diagram 125714C...

  • Page 77: 1335Mhb-Wd Wiring Diagram

    Technical Manual & Parts Lists 1335MHB-WD Wiring Diagram 125715C...
  • Page 78 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
  • Page 79 Declaración de Garantia Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero.
  • Page 80 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 www.atlatt.com Printed in the USA...
