Introduction
Feature
Lifting capacity:
Lifting height:
Lifting speed:
Brake:
Control:
Unpacking
．Winch assembly
．Wire rope 8 mm x 130 m w/hook
．Low voltage control ass'y LV-320
．Pendant switch PB-306 w/cord 1.25 mm
Read this manual carefully
You should carefully read and understand this manual before operating it.
Careless winch operation may result in personal injury hazards or property
damage.
Information requesting or parts ordering
Please specify the followings information:
．Winch PN
．Serial number
．Part description
．Replacement part number
．Quantity for each part
500 kg wire rope top layer
127 m
19-34 m/min at 50Hz
Electromagnetic spring-applied failsafe brake
Pendant switch powers the winch
CWG-500TH
Model:
2
x 3C x 3 m
Electric Winch
PN:155510 380V50Hz
155520 400V50Hz
155580 415V50Hz
1pc
1pc
1pc
1pc
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Comeup CWG-500TH
Summary of Contents for Comeup CWG-500TH
- Page 1 Electric Winch CWG-500TH Model: PN:155510 380V50Hz 155520 400V50Hz 155580 415V50Hz Introduction Feature Lifting capacity: 500 kg wire rope top layer Lifting height: 127 m Lifting speed: 19-34 m/min at 50Hz Brake: Electromagnetic spring-applied failsafe brake Control: Pendant switch powers the winch Unpacking ．Winch assembly...
- Page 2 Installation Before using the winch, make sure all electrical components have no corrosion or damaged; the environment should be clear and dry. Performance Winch Model CWG-500TH Motor kw x p 3.7 x 2 Size (mm) Recommend Wire Rope Breaking (kg)
- Page 3 Warning ． The winch is not intended to be used in any manner for the movement or lifting of personnel. ． The lifting capacity shown is based on the top layer of rope on the drum. ． The rope winding on the drum shall remain 5 wraps from the drum. Parts List Item Description...
- Page 4 Winch Assembly...
