Device Appearance Description

Status LED
Microphone
Power Connector (AC24V in)
(*)
Power Connector (DC12V in)
Auto Iris Connector (*)
SD/SDHC Card Slot (*)
Reset Button
NOTE
1. The WPS buttons must first be enabled through the web GUI in order to work. See page
54 for details on how to enable the WPS Button.
2. (*) These are optional features. Please refer to the Product List for the full list of optional
features available for the product.
<Front Panel>
Built-in
<Rear Panel>
Microphone/Line
In
Light Sensor
WPS LED (*)
Ethernet RJ45 10/100 Socket
(Link/Power LED embedded)
Audio Out
3
Detachable Antenna
(*)
WPS Button (*)
Extension I/O
Terminal Block
Monitor Output
Connector
(FB-130A only)
