- Page 1 Easy Installation Guide Megapixel Day & Night Outdoor Bullet Network Camera Outdoor Bullet V2 Series English...
- Page 2 Step 1.Check Package Contents a. Network Camera (OB-Series V2) b. Shielding Cover c. Screw bag d. Product CD e. Warranty Card / 2 Water Proof Connectors Easy Installation Guide g. Dry Bag h. High Power POE (Optional) Bracket (Optional) Bracket Assembly Plate (Optional) k.
- Page 3 Step 2.Hardware Installation WARNING - Do not mount the camera on a soft material. The camera may fall and be damaged. This document is for easy installation purpose only; please refer to the user manual for more details. Micro-SD/SDHC Card and 3G SIM Card Installation Remove the Lens cover from the Bullet Camera.
- Page 4 Wall Installation Using the Optional Bracket Using the Bracket plate as a guide, drill three holes into the wall and hammer the supplied plastic anchors into the three holes. Use a screwdriver and the supplied screws to secure the plate to the wall. Attach the Bracket Assembly Plate to the bottom of the camera using two screws.
- Page 5 Connect (1) the POE cable; (2) DIDO, Audio In/Out, RS485 cable; and (3) Antenna cable with the camera. Refer to step 3 for more details installation information. Secure the two screws on the wall mount bracket. Place the wall mount bracket on the plate and attach it using the supplied screws. Adjust the angle of the wall mount bracket towards the area to be monitored.
- Page 6 WiFi or 3G Antenna Extension Cable Connection Pass the Antenna extension cable (1) through and bracket and connect it to the Antenna connector (2)at the bottom of the camera. Water Proof Connector Refer to the installation guide included in the package when installing the Water Proof connector.
- Page 7 Step 3.Install Camera and Network Devices The Outdoor Bullet camera can either be connected to a PoE-enabled switch or a non-PoE switch. If using a PoE-enabled switch: Use a single Ethernet cable to connect the camera to the PoE-enabled switch. If using a non-PoE switch: Use a standard RJ-45 cable to connect the camera to a PoE Injector.
- Page 8 Step 4.Install the EasyConfig Software Insert the CD into the CD-ROM, and follow the instructions of the InstallShield Wizard to finish installation. Step 5.Launch EasyConfig Launch the EasyConfig software, and click on the camera from the survey list to connect. Follow the EasyConfig software to configure the camera’s IP address and EasyLink settings.
