Device Appearance Description

< Front & Rear view >
1.
NOTE - The WPS and Privacy buttons must first be enabled through the web GUI in
order to work.
2. (*) These are optional features. Please refer to the Product List for the full list of optional
features available for the product.
Adjustable focal Lens
Light Sensor
Illumination LED
(MB-500Ap/WMB-500Ap)
Built-in Microphone
Speaker
Privacy LED
WPS LED (*)
FW Upgrade LED
Wireless LED (*)
Ethernet LED
- 4 -
Power LED
Ethernet RJ45 Socket
Power Connector
DIDO Terminal I/O Connector
Reset Button
WPS Button (*)
Privacy Button
Micro SD/SDHC slot
USB Port for 3G/4G
* WMB-500Ap / WMB-502Ap*
