Model
WVOC-2HFG
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
304963
2M-
p/n
Rev. E
WELLS BLOOMFIELD, LLC
10 Sunnen Dr., St. Louis, MO 63143
telephone: 888-356-5362
IMPORTANT: DO NOT DISCARD THIS MANUAL
fax: 314-781-2714
www.wells-mfg.com
OWNERS MANUAL
WVOC-2 SERIES
CONVECTION OVEN
COMBINATION COOK
UNIVERSAL HOOD
MODELS:
WVOC-2HFG
WVOC-2HSG
VO2HFGG1R208
INSTALLATION
EXPLODED VIEW
WIRING DIAGRAM
505
and
CENTER
with
Includes
USE & CARE
PARTS LIST
10
M505
0914
