SuperServer 1019D-FRN8TP User's Manual

1.3 System Features

The following table provides an overview of the main features of the 1019D-FRN8TP. Refer
to Appendix C for additional specifications.
Motherboard
X11SDV-8C-TP8F
Chassis
SC515-R407
CPU
Intel® Xeon® D-2146NT SoC with a TDP of up to 80W
Socket Type
Embedded Processor
Memory
Supports up to 256 GB of ECC RDIMM or 512 GB of ECC LRDIMM DDR4 memory with speeds of up to
2133 MHz speed and up to 128 GB size at 1.2V in four (4) slots
Chipset
System on a Chip
Expansion Slots
The motherboard supports the following expansion slots:
•
One (1) PCI-E 3.0 x16 slot
•
One (1) PCI-E 3.0 x8 slot
•
One (1) Mini PCI-E 3.0 x1 slot
•
One (1) M.2 PCI-E 3.0 x4 slot
•
One (1) M.2 PCI-E 3.0 x2 slot
Hard Drives
Up to two (2) 2.5" fixed with bracket
Cooling
Up to two (2) mid-chassis mounted cooling fans
Power
400W Low Noise AC-DC power supply module with PFC (p/n PWS-406P-1R)
Form Factor
1U rackmount
Dimensions
(WxHxD) 17.2 x 1.7 x 16.9 in. (437 x 43 x 429 mm)
System Features
