１０－５．Torque Characteristics
(1) Representations in the torque characteristics table are made in terms of the
motor rotation (s
Motor rotation (s
Motor rotation(s
(2) The Maximum Starting Pulse Rate is represented as "fs" by the value at zero
inertial load.
(3) Upon operation, provide adequate allowance for torque.
(4) The stepping motor may attain high temperature, depending on the operational
conditions.
Use the stepping motor according to the Instructions Manual produced by
motormakers.
-１
) vs. torque (N・m).
-１
) and drive pulse frequency (Hz) are converted as follows:
360°
-１
) ×
Step angle
-37-
＝ Drive pulse input frequency(Hz)
