3.Name and Function of Each Section
3-1.Signal I/O Connector(J1)
ADB-2F45U
J1
1
CW+
2
CW-
3
CCW+
4
CCW-
5
M.F+
6
M.F-
7
P.O
8
R.GND
9
O.H.A
10
R.GND
CW drive pulse signal input terminal
●Directs the motor to operate CW.
CCW drive pulse signal input terminal
●Directs the motor to operate CCW.
Motor excitation stop signal input terminal
●Shuts off output current to drive the motor.
Phase signal output terminal
●Outputs the signal when the motor-excitation
state is the excitation home position.
GND terminal for P.O signal.
Overheat alarm signal output terminal
●Outputs the signal when internal temperature
of the driver has reached approx. 70℃ or more.
GND terminal for O.H.A signal.
