１０．Specifications; General Specifications - Melec GDB-5K40 Instruction Manual

１０．Specifications
１０－１．General Specifications
Supply Power
Motor output
current
Input Signal
Output Signal
Functions of
Operating Sections
Operating Ambient
Temperature
Operating Ambient
Humidity
Storing Temperature
Storing Humidity
Altitude
Atmosphere
Withstanding
Vibration
Insulation resistance
Exterior Dimensions
Weight
Input voltage range is DC+24V±10%.
*1
Use a power supply that provides sufficient input current.
*2
DC+24V
*1 (Ripple voltage P-P 2.0V or less)
● Rated input current :
at DRIVE
● Rated input current :
at HOLD
●DRIVE CURRENT 0.30A/phase～1.4A/phase
●HOLD CURRENT Approx. 40% of DRIVE CURRENT (factory-set)
●Drive pulse input
●Motor excitation stop input (M.F)
●Step angle switch input
●Phase signal output
●Overheat alarm output
●MOTOR selection
●STEP TABLE selection
●Step angle selection
●HOLD CURRENT selection
●DRIVE CURRENT selection
●PULSE INPUT TYPE selection
●HOLD switching time selection
●ROTATE MODE SELECT switch
●EXTEND FUNCTION SELECT switch
0℃ ～ +50℃ (No freezing allowed.)
80％RH or less (No condensation allowed.)
-10℃ ～ +55℃ (No freezing allowed.)
80％RH or less (No condensation allowed.)
Up to 1000m above sea level
Indoor (Exposure to direct sun is not allowed.)
Without any explosive, corrosive or inflammable gas, oil mist,
or dust.
No abnormality should be found after a vibration test
DC connector - signal connector - Frame
(Each other)
Ｈ Ｗ Ｄ
65× 75 × 29 (mm)
0.1 kg
-35-
〔DRIVE I.SEL ⇒ No.F set up〕
DC+24V: 2.0A
〔HOLD I.SEL ⇒ Approx. 40％ set up〕
DC+24V: 0.4A
(CW, CCW)
(C.S)
(P.O)
(O.H.A)
(MOTOR SEL)
(S.T SEL)
(STEP SEL)
(HOLD I.SEL)
(DRIVE I.SEL)
(SPI SEL)
(DHT SEL)
(RM SEL)
(OP SEL)
at 10～55Hz, 0.15mm P-P
DC500V 100MΩ or more
GDB-5K40
Instructions Manual
*2
Photo-coupler input
Photo-coupler input
Photo-coupler input
O/C output
O/C output
