１０－４．Applicable Motors
(1) GDB-5K40 can drive a 5-phase stepping motor with 0.35A/phase～1.4A/phase.
① Examples of applicable motors
SANYO DENKI Co., LTD.
□28mm
103F3505-7441(7411)
103F3515-7441(7411)
□42mm
103F5505-7241(7211)
103F5508-7241(7211)
103F5510-7241(7211)
□60mm
103F7852-8241(8211)
103F7853-8241(8211)
ORIENTAL MOTOR Co., Ltd.
□28mm
PK523PA(B)
PKP523N12A(B)
PK525PA(B)
PKP525N12A(B)
□42mm
PK543-A(B)
PK544-A(B)
PK545-A(B)
□60mm
PK564H-A(B)
PK564-A(B)
PK566-A(B)
PK566H-A(B)
PK569-A(B)
Factory Setting
( ) : Both axis
● Please contact us if you want to use the motor other than the above to our office.
Setting
Current
DRIVE I.SEL
(A/phase)
switch No.
0.75 8
0.75 8
0.75 8
0.75 8
0.75 8
1.4 F
1.4 F
Setting
Current
DRIVE I.SEL
(A/phase)
switch No.
0.35 2
1.2 D
0.35 2
1.2 D
0.75 8
0.75 8
0.75 8
1.4 F
0.75 8
0.75 8
1.4 F
1.4 F
F
-43-
Setting Setting RM SEL
MOTOR SEL
switch
switch
4 3
OFF OFF OFF
OFF OFF OFF OFF ON
OFF OFF OFF
OFF OFF OFF ON OFF
OFF OFF OFF
OFF OFF ON OFF OFF
OFF OFF ON
Setting
Setting RM SEL
MOTOR SEL switch
switch
4 3
OFF OFF OFF OFF
OFF OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF OFF OFF ON
OFF OFF OFF ON
OFF OFF OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF ON
OFF OFF ON OFF
OFF OFF ON OFF OFF
OFF OFF ON OFF
OFF OFF ON OFF OFF
OFF OFF OFF OFF OFF
GDB-5K40
Instructions Manual
Torque Data
Fig. No.
2 1
OFF ON -
Fig.1
ON OFF -
Fig.2
ON OFF -
Fig.3
OFF OFF -
Torque Data
Fig. No.
2 1
ON Fig.4
Fig.5
ON -
-
OFF Fig.6
-
OFF -
ON -
OFF -
-
OFF Fig.7
-
－
