Melec GDB-5K40 Instruction Manual page 49

Fig.6
GDB-5K40
PK543-A(B)
0.75A/PHASE
TORQUE(N･m)
0.20
HOLD 40% = 0.054N・m
0.16
0.12
PULLOUT TORQUE
0.08
0.04
DRIVER INPUT CURRENT
0.00
0.01 0.1
MOTOR ROTATION SPEED(s
0.6 6
MOTOR ROTATION SPEED(r/min)
DRIVE I.SEL = No8
MOTOR SEL = OFF
RM1,RM2,RM3,RM4 = OFF, ON, OFF, OFF
DRIVER INPUT CURRENT(A)
5.0
4.0
3.0
2.0
1.0
0.0
fs
1 10 100
-1 )
60 600 6000
-49-
GDB-5K40
Instructions Manual
