Fig.2
GDB-5K40
103F5508-7241(7211)
0.75A/PHASE
TORQUE(N･m)
0.5
HOLD 40% = 0.095N・m
0.4
0.3
PULLOUT TORQUE
0.2
0.1
DRIVER INPUT CURRENT
0.0
0.01 0.1 1
MOTOR ROTATION SPEED(s
0.6 6 60
MOTOR ROTATION SPEED(r/min)
DRIVE I.SEL = No8
MOTOR SEL = OFF
RM1,RM2,RM3,RM4 = OFF, ON, OFF, OFF
DRIVER INPUT CURRENT(A)
5.0
4.0
3.0
2.0
1.0
0.0
fs
10 100
-1 )
600 6000
-46-
