- Page 1 User Manual ERW Series 1U Widescreen LCD Console Drawer Options Available: - SDI - HDMI / BNC / Audio - Full Range KVM - DC Power Designed/Manufactured by Austin Hughes and Distributed by Eclipse Rackmount, Inc. Manual ML07V02A -- Generation 4 -- www.EclipseRackmount.com...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > ERW-19 Package Contents Structure Diagram & Dimensions P.1 - 2 Installation P.3 - 5 Connection P.6 - 7 < Part. 2 > Specifications / OSD Product Specif cations P.8 - 9 Keyboard / Mouse Specifications P.10 On-Screen Display Operation ( OSD ) P.11 - 12... - Page 4 Contents < Part. 4 > Integrated KVM Part Numbers Ending In: Matrix Local Remote 8-port 16-port 32-port Cat6 KVM 16-Cat6-M3X-IP 32-Cat6-M3X-IP 16-Cat6-M4X-2IP 32-Cat6-M4X-2IP 16-Cat6-M2X 32-Cat6-M2X 16-Cat6-M3X 32-Cat6-M3X 16-Cat6-M4X 32-Cat6-M4X Part Numbers Ending In: Combo Local Remote 8-port 16-port 32-port Cat6 KVM 8-Cat6-IP 16-Cat6-IP 32-Cat6-IP...
- Page 5 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 6: Part. 1 > Erw-19
< Part 1 > < 1.1 > Package Contents ERW-19 unit X 1 - CAX-6 6ft DVI-D console cable X 1 ( Alternative : CAU-6 6ft VGA console cable ) - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. - Page 7 < 1.2 > Dimensions ERW-19 Front View UNIT : mm Side View 1mm = 0.03937 inch Top View Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 441.6 x 460 x 44 mm 590 x 823 x 140 mm 11.5 kg 16.3 kg...
-
Page 8: Installation
< 1.3 > Installation - How to install Installation Slides Step ■ Insert the left and right rear mounting brackets into the LCD console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. Step Complete the installation ■... - Page 9 < 1.3 > Installation - How to install 2 Post Brackets* ERW-19 Step ■ Release front mounting ears before applying 2 post r ack brackets. ■ Insert rear mounting brackets into the LCD console drawer. * Requires Part #: MB-751-12 Step ■...
- Page 10 < 1.3 > Installation - Using the Drawer ■ Hold the handle and slide out the drawer. ■ Lift the LCD to a suitable angle. ■ Operate the LCD console drawer. Page 10 -- ML07V02A -- www.EclipseRackmount.com...
-
Page 11: Connection
< 1.4 > Connection to USB Server via CAX-6 cable ERW-19 LCD Console Drawer Power DVI-D CAX-6 DVI-D console cable DVI-D USB server < 1.4 > Connection to External KVM via CAX-6 cable LCD Console Drawer Power DVI-D KVM CAX-6 DVI-D console cable DVI-D DVI console KVM... - Page 12 < 1.4 > Connection to USB Server via CAU-6 cable LCD Console Drawer Power CAU-6 VGA console cable USB server < 1.4 > Connection to External KVM via CAU-6 cable LCD Console Drawer Power CAU-6 VGA console cable USB console KVM Caution : The LCD console drawer is hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable.
- Page 13 < Part 2 > < 2.1 > Product Specifications ERW-19 Manufacturer Panel Panel Size ( diagonal ) 19-inch Widescreen TFT color LCD Display pixel ( dots x lines ) 1440 x 900 Brightness ( typ. ) Contrast Ratio ( typ. ) 1000:1 Color 16.7 M...
- Page 14 Environmental Operating Temperature 0 to 50°C degree Conditions Humidity 20~90%, non-condensing Storage Temperature -5 to 60°C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Physical Product ( W x D x H ) 441.6 x 460 x 44 mm Specification 17.4 x 18.1 x 1.73 inch Packing ( W x D x H )
-
Page 15: Keyboard / Mouse Specifications
< 2.2 > Keyboard / Mouse Specifications ERW-19 G keyboard integrated with touch pad G keyboard integrated with track ball Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time Software support MS Windows 7 / 2008 / 2003 / 2000 / XP / ME / 98 / DOC Linux / Mac Supporting layouts... -
Page 16: On-Screen Display Operation ( Osd )
< 2.3 > On-Screen Display Operation ( OSD ) Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control Exit the OSD screen Go back to the previous on-screen sub-menu or main menu... - Page 17 < 2.3 > On-Screen Display Operation ( OSD ) ERW-19 OSD Conf guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: for volume, bass, treble, balance, AVL and mute Misc:...
- Page 18 < Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input The SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberV iew Full HD 1080p and ultra high resolution 1920 x 1200 LCD displays, the board provides a SDI input module without using additional space or power and it comes standard with a 2-year warranty.
- Page 19 < 3.2 > Options : ERW-19 - HDMI ( HDMI 1.1, CEA-861-D ) - BNC ( S-Video + Composite, BNC ) - Audio ( 3.5mm audio jacks for audio in & out, and 2W + 2W speakers ) ( 1 ) Either HDMI or DVI-D can be selected. ( 2 ) For the above options, casing depth will be extended from 460mm ( 18.1"...
- Page 20 < 3.3 > Options : DC Power Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA...
- Page 21 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2013 Austin Hughes Electronics Ltd. & Eclipse Rackmount, Inc. All rights reserved. Manual ML07V02A -- www.EclipseRackmount.com...
