User Manual
1U LCD Keyboard Drawers
15", 17" and 19" Screen Sizes
ER1 Series
- Optional KVM
ERS Series
- Designed to work with Sun
- 1U 17" or 19" Screen
- Optional KVM
ER1S Shallow Series
- Shallow Depth
- Single Console Only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ER1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CyberView ER1 Series

  • Page 1 User Manual 1U LCD Keyboard Drawers 15", 17" and 19" Screen Sizes ER1 Series - Optional KVM ERS Series - Designed to work with Sun - 1U 17" or 19" Screen - Optional KVM ER1S Shallow Series - Shallow Depth...
  • Page 2: Table Of Contents

    Peripheral Products.............5 Structure Diagram...............5 How to Install “One Man” Installation Slides....6-7 1.10 How to Use The Slides............8 How to Use ER1 Series LCD Keyboard Drawer....9 1.11 ERS Series (Single console) 1.12 ......10 - Use CB-6 to connect to server via USB interface ERS Series (Single console) 1.13...
  • Page 3 Contents Chapter 4 Optional Specifi cation KVM Options..............19 DVI-D Option..............19 BNC + S-Video Option............19 Audio Option..............20 DC Power Options............20 Touchscreen Options............21 Chapter 5 Troubleshooting ............22 Chapter 6 Dimensions ...............23...
  • Page 4: Important Safeguards

    Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. ■...
  • Page 5: Regulatory Notice

    Chapter 1 1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
  • Page 6: Package Contents

    Chapter 1 1.3 Package Contents LCD keyboard drawer x 1 pc CB-6 USB 2-in-1 KVM cable x 1 pc (for “S” series) CE-6 Combo 4-in-1 KVM cable x 1 pc (for RKP series) User manual (As of Sept 2011, all user manuals will be download-only. Physical copies are available upon request) Power cord x 1 pc Auto switch power adapter ( for external power version) x 1 pc Mounting bracket x 2 pcs...
  • Page 7: Before Installation

    Chapter 1 1.4 Before Installation ■ It is very important to locate the LCD Keyboard Drawer in a suitable environment. ■ The surface for placing and fi xing the LCD Keyboard Drawer should be stable and level or mounted into a suitable cabinet.
  • Page 8: Peripheral Products

    Chapter 1 1.7 Peripheral Products Item Model No. Description 16-Cat6-M2X / M3X / M4X Matrix Cat 6 16-Port KVM 16-Cat6-M3X-IP / M4X-IP / M4X-2IP Matrix IP Cat 6 16-Port KVM Matrix Cat6 KVM 32-Cat6-M2X / M3X / M4X Matrix Cat 6 32-Port KVM 32-Cat6-M3X-IP / M4X-IP / M4X-2IP Matrix IP Cat 6 32-Port KVM 8-M2X / M3X / M4X...
  • Page 9: How To Install "One Man" Installation Slides

    Chapter 1 1.9 How to Install "One Man" Installation Slides Install into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■...
  • Page 10: How To Install "One Man" Installation Slides

    Chapter 1 1.9 How to Install "One Man" Installation Slides ■ Attach front left and right mounting ears of the LCD keyboard drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■...
  • Page 11: How To Use The Slides

    Chapter 1 1.10 How to Use the Slides ■ A black arrow release button is located on the outside of each slide. (shown in Figure 1). Figure 1. ■ Pull and hold the black arrow button on either side of the LCD keyboard drawer to unlock. (shown in Figure 2).
  • Page 12: How To Use Er1 Series Lcd Keyboard Drawer

    Chapter 1 1.11 How to Use ER1 Series LCD Keyboard Drawer ■ Press the carry handle button. Gently pull the carry handle toward the front of the LCD shown in Figure 4. Figure 4. Slide the LCD keyboard drawer out after pressing the carry handle button.
  • Page 13: Ers Series (Single Console)

    Chapter 1 1.12 ERS Series (Single Console) - Use CB-6 to connect to server via USB interface Figure 7. Example of connecting CB-6 2-in-1 USB KVM cable to server via USB interface 1.13 ERS Series (Single Console) - Use CB-6 to connect to KVM via USB interface CB-6 KVM Cable Figure 8.
  • Page 14: Er1 Series (Single Console)

    Chapter 1 1.14 ER1 Series (Single Console) - Use CE-6 to connect to server via PS/2 interface Figure 9. Example of connecting CE-6 4-in-1 Combo KVM cable to server via PS/2 interface 1.15 ER1 Series (Single Console) - Use CE-6 to connect to KVM via PS/2 interface CE-6 KVM Cable Figure 10.
  • Page 15: Er1 Series (Single Console)

    Chapter 1 1.16 ER1 Series (Single Console) - Use CE-6 to connect to server via USB interface Figure 11. Example of connecting CE-6 4-in-1 Combo KVM cable to server via USB interface 1.17 ER1 Series (Single Console) - Use CE-6 to connect to KVM via USB interface CE-6 KVM Cable Figure 12.
  • Page 16: On-Screen Display Operation

    Chapter 2 2.1 On-Screen Display Operation 15" LCD membrane 17" & 19” LCD membrane Membrane Switch Function Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen...
  • Page 17: On-Screen Menu

    Chapter 2 2.2 On-Screen Menu OSD Confi guration Page Image: To open the brightness, contrast, color temp, red, green, and blue controls Geometry: To open the auto adjust, H position, V position, phase and clock controls Video: To open the colour, tint, sharpness, noise reduction, DCDi and TV Setup controls Audio: To open volume, bass, treble, balance, AVL and mute controls...
  • Page 18: Specifi Cations

    Chapter 3 3.1 Specifi cations Item Description Form Factor 1U rackmount on slide-out rails LCD Manufacturer Series Diagonal Size 15" TFT 17" TFT 19" TFT 17" TFT 19" TFT 1152 x 900 (Direct) 1152 x 900 (Direct) Max. Resolution 1024 x 768 1280 x 1024 1280 x 1024 1280 x 1024 (Native)
  • Page 19: Keyboard & Mouse

    Chapter 3B 3.2 Keyboard & Mouse ER1 and ER1S Series Supporting layouts N keyboard integrated with touch pad B keyboard integrated with track ball P.16...
  • Page 20: Keyboard & Mouse

    Chapter 3 3.2 Keyboard & Mouse ERS Series Supporting layouts ERS N Keyboard with Touch Pad ■ Incorporates Sun keys including Stop, Cut, Paste, Compose, Copy and Help ■ 104 key notepad keyboard with full numerical pad and Sun function ■...
  • Page 21: How To Use Ers Keyboard

    Chapter 3 3.3 How to Use ERS keyboard ■ The ERS Sun compatible keyboard incorporates Sun-specific command keys ■ Press the Fn/Num button to switch the color the Num LED. Num LED in Off mode Num LED in Green color Keypad operates in Sun Solaris system Keypad behaves as a normal keypad mode administration command mode...
  • Page 22: Kvm Options

    Chapter 4 4.1 KVM Options Our KVM is designed to seamlessly integrate into the rear of our full range of LCD drawer solutions: ■ For KVM operation, please refer to the "All KVM" user manual ■ Options available for multiple consoles via Matrix KVM ■...
  • Page 23: Audio Option

    Chapter 4 4.4 Audio Option Speaker 3-in-1 VGA KB mouse Power Audio console port Internal power version External power version Please Note: ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD 4.5 DC Power Options Model Input rating Input voltage:...
  • Page 24: Touchscreen Options

    Chapter 4 4.6 Touchscreen Options e-Resistive Model -15TRB / -15TRS -17TRB / -17TRS -19TRB / -19TRS Screen size 15" 17" 19" Interface USB / serial Optical transmittance 80% ± 3% Surface hardness ≥3H (JIS K5400) Operating system Windows 98 / 2000 / ME / XP / NT / CE, DOS, Linux e-Capacitive Model -15TCB / -15TCS...
  • Page 25: Chapter 5 Troubleshooting

    We suggest turning off the power to all devices before connecting them. Apply power to connected devices again only after the LCD keyboard receives power. For ER1 Series 1. How do I adjust the resolution? To change monitor resolution, click Start -> Control Panel -> Display. Select Setting tab to adjust the monitor resolution in Desktop Area.
  • Page 26: Chapter 6 Dimensions

    Chapter 6 6.1 Dimensions Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 442 x 650 x 44 mm 589 x 856 x 168 mm 15 kg 21 kg ER1-15 17.4 x 25.6 x 1.73" 23.2 x 33.7 x 6.6"...
  • Page 27 Blank page...
  • Page 28 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2011 Austin Hughes Electronics Ltd. and Eclipse Rackmount, Inc. All rights reserved. CV-RKP1-1209V7...
